Поз.
Артикул
Описание
62
HOSE , Replaced By: A0009872827
62
PLASTIC PIPE FUEL LINE 12X1,5 MM, ORDER BY THE METER
74
BANJO UNION HOSE WIDTH, / I.D., 9/16 MM
77
BANJO UNION FROM BULKHEAD FITTING TO PRESSURE REGULATOR
104
HOSE LEAK LINE, ORDER BY THE METER
107
HOSE LEAK LINE 4X6 MM, ORDER BY THE METER
107
PLASTIC PIPE RISING PIPE 4X6 MM
108
FITTING (PARTS KIT),LINE RUPTURE,5 909352K 169122
110
UNION NUT
113
GLAND , Replaced By: A0019901667
113
SEAL CONE
116
SLEEVE LEAK LINE
506
RESERVOIR40L,246 MM,8.5 BAR
506
RESERVOIR , Replaced By: A0034322301
509
LOCK (PROTECTION AGAINST TORSION),5 934167
512
SCREW PLUG LOAD/NO-LOAD VALVE,CONNECTION: "21"
512
SCREW PLUG , Replaced By: N000908022011
515
FITTING REAR AXLE REGULATING SOLENOID VALVE, CONNECTIONS: "10"
518
FITTING AIR RESERVOIR,CONNECTION: "11"
524
HOLLOW SCREW FRONT AXLE REGULATING SOLENOID VALVE, CONNECTION: "10",K 009079
527
SEAL RING LOAD/NO-LOAD VALVE,CONNECTION: "20"
530
ELBOW FITTING AIR RESERVOIR,CONNECTIONS: "31,32"
533
O-RING CHECK VALVE TO AIR RESERVOIR
536
THRUST RING CHECK VALVE TO AIR RESERVOIR
536
THRUST RING , THE OLD PART MUST NO LONGER BE INSTALLED, Replaced By: A0009940203
539
NUT CHECK VALVE TO AIR RESERVOIR
560
STRAP SERVICE BRAKE AIR RESERVOIR
563
BASE AIR RESERVOIR,STRAP
566
SCREW END PIECE TO EXHAUST PIPE M 10X25
569
NUT STRAP TO BRACKET
569
NUT , Replaced By: N910113010000
572
VALVE DRAIN, Replaced By: A0004322107
572
VALVE DRAIN, Replaced By: A0004322407
572
VALVE. DRAIN VALVE DRAIN
575
O-RING CHECK VALVE TO AIR RESERVOIR
578
THRUST RING , THE OLD PART MUST NO LONGER BE INSTALLED, Replaced By: A0009940203
578
THRUST RING CHECK VALVE TO AIR RESERVOIR
999
HOLLOW SCREW FOUR-CIRCUIT PROTECTIVE VALVE, CONNECTION: "24"
999
SEAL RING , Replaced By: N007603012121
999
UNION NUT LINE CONNECTION
999
NUT , Replaced By: N910113010000
999
NUT , Replaced By: N913004008001
999
NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET, Replaced By: N910113008003
999
HEXAGON NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET
999
SCREW PLUGROCKINGER,TYP 59 U150
999
SCREW PLUGROCKINGER TYP 59 G140,59 G150, Replaced By: N007604012105
999
SEAL RING LOAD/NO-LOAD VALVE,CONNECTIONS: "20,21",5 727400
999
SEAL RING LINE CONNECTION
999
SEAL RING DOUBLE BRAKE LINE COUPLING, CONNECTIONS: "11,12"
999
BULKHEAD FITTING THROUGH SIDE MEMBER
999
CONNECTION FITTING ENGINE AIR COMPRESSOR,CONNECTION: "15"
999
CLAMPING SLEEVEKNORR
999
WASHER STRAP TO SUPPORT
999
NUT COMPRESSED AIR LINE THRU FRAME,5 395034
999
WASHER COMPRESSED AIR LINE TO BRACKET
999
WASHER COMPRESSED AIR LINE TO BRACKET, Replaced By: N000125006449
999
REPAIR KIT. TS SEALING RING COMPRESSED-AIR-LINE PLUG-CONNECTION TO M 22
999
STRAP AIR RESERVOIR III,5 088362
999
STRAP AIR RESERVOIR TO BRACKET
999
FITTING , FIRST EXHAUST STOCK OF OLD PARTS UP TO IDENT NO. 4 847992, Replaced By: A6174310073
999
BRAKE HOSE , FIRST EXHAUST STOCK OF OLD PARTS UP TO IDENT NO. 4 847992, Replaced By: A6174310073
999
ADHESIVE FOIL GUIDE SIGN
999
CONNECTOR , Replaced By: A0004310735
999
SEAL RING , Replaced By: A0009870746
999
SEAL RING , Replaced By: A0049972248
999
VALVE (FOUR-CIRCUIT PROTECTIVE VALVE) WABCO
999
REPAIR KITTO 002 430 98 81,99 81,KNORR
999
GASKET KIT FOUR-CIRCUIT PROTECTIVE VALVE GRAU,000 2
999
FITTING AIR DEHYDRATOR,CONNECTION: "10",5 433280
999
ELBOW FITTING ,5 433281
999
ELBOW FITTING ,5 181111 10/50 616.121,122,131,1325 208196 20/60 616.121,122,131,1325 297633 616.024,026,027,028,065
999
ELBOW FITTING ,5 181111 10/50 616.121,122,131,1325 208196 20/60 616.121,122,131,1325 297633 616.024,026,027,028,065
999
PRESSURE REGULATORKNORR,5 7999995 800000 - 5 8127305 900000 - 5 936365
999
REPAIR KIT. BRAKE CYLINDER DIAPHRAGM PART TO 007 420 42 18, KNORR
999
REPAIR KIT SPRING LOAD ACCUMULATOR PART KNORR,K 262627
999
ELBOW FITTING AIR RESERVOIR,CONNECTION: "13", PLUG CONNECTION
999
ELBOW FITTING COMPRESSED-AIR-LINE PLUG-CONNECTION
999
T-FITTING LEFT AND RIGHT BRAKE HOSES
999
PROTECTIVE CAPKNORR
999
REPAIR KIT PRESSURE REGULATOR WABCO
999
PLUG
999
HANDLEKNORR
999
SCREW. UNION SCREW LINE CONNECTION
999
LOCK COMPRESSED-AIR-LINE PLUG-CONNECTION
999
SEAL RING COMPRESSED-AIR-LINE PLUG-CONNECTION
999
CONNECTOR REPAIR SIZE
999
RING DRAIN VALVE TO 000 432 08 07, NOT USED
999
PISTONTO 001 431 83 05,WABCO
999
VALVEWABCO
999
BREATHER PIPETO 001 431 83 05,WABCO
999
REPAIR KIT FOUR-CIRCUIT PROTECTIVE VALVE WABCO
999
REPAIR KIT VALVE BOSCH
999
REPAIR KITTO 002 431 83 06, KNORR 90309
999
REPAIR KITTO 000 429 26 95,KNORR
999
REPAIR KIT , Replaced By: A0004300207
999
MUFFLER , FIRST EXHAUST STOCK OF OLD PARTS UP TO IDENT NO. 4 847992, Replaced By: A6174310073
999
REPAIR KIT BRAKE POWER REGULATOR TO 002 431 05 12,KNORR
999
ADAPTER FITTING LINE CONNECTION TO ENGINE
999
FILTER ELEMENTTO 000 429 28 95,GRAU
