Поз.
Артикул
Описание
5
BRACKET , Replaced By: A6754600835
5
BRACKET OIL TANK,K 055088
15
BRACKET OIL TANK,K 055089
20
BRACKET OIL TANK,5 389664K 055088
20
BRACKET OIL TANK
25
SCREW , Replaced By: N304017010028
25
HEXAGON HEAD BOLT RUBBER MOUNTING TO SIDE MEMBER AND TO SUPPORT M10X20
30
SCREW CENTRAL LOCK TO CAB M 10X16
35
LOCK WASHER BRACKET TO SUPPORT AND TO END PIECE
40
LINE , Replaced By: A0004291601
40
LINE (SUCTION LINE),FROM HOSE TO OIL PUMP
40
LINE (SUCTION LINE),FROM HOSE TO OIL PUMP
40
LINE (SUCTION LINE),FROM HOSE TO OIL PUMP
40
LINE (SUCTION LINE),FROM HOSE TO OIL PUMP
40
LINE (SUCTION LINE),FROM OIL TANK TO PUMP
40
LINE (SUCTION LINE),FROM OIL TANK TO PUMP,K 136986
40
LINE , Replaced By: A0004291601
40
LINE (SUCTION LINE),FROM OIL TANK TO PUMP,K 055044K 136985
50
LINE HIGH PRESSURE, FROM HOSE TO STEERING,K 055018
50
LINE HIGH PRESSURE, FROM HOSE TO STEERING,K 017689K 055017
50
LINE HIGH PRESSURE, FROM HOSE TO STEERING,K 017689K 055017
50
LINE , EXHAUST STOCK OF OLD PARTS UP TO IDENT NO. 5 949264, Replaced By: A6754601088
50
LINE HIGH PRESSURE, FROM HOSE TO STEERING,K 055017
50
LINE (DELIVERY LINE) FROM HIGH PRESSURE HOSE TO STEERING BOX,K 055044
50
LINE (DELIVERY LINE) FROM HIGH PRESSURE HOSE TO STEERING BOX,K 055044
70
UNION NUT LINE CONNECTION
70
UNION NUT LINE CONNECTION, Replaced By: N000000006239
75
SEAL CONE LINE CONNECTION
75
GLAND , Replaced By: A0019901967
80
HOSE (DELIVERY LINE),FROM PUMP TO STEERING
80
HOSE (DELIVERY LINE),FROM PUMP TO STEERING
80
HOSE (DELIVERY LINE),FROM PUMP TO STEERING
85
HOSE FROM OIL TANK TO SUCTION LINE
85
HOSE , Replaced By: A6254660381
95
FITTING DELIVERY LINE TO PUMP
95
FITTING DELIVERY LINE TO PUMP
95
FITTING DELIVERY LINE TO PUMP
95
FITTING DELIVERY LINE TO PUMP
105
FITTING (DELIVERY LINE),FROM PUMP TO STEERING
105
FITTING (DELIVERY LINE),FROM PUMP TO STEERING
105
FITTING RETURN LINE TO STEERING
105
FITTING (DELIVERY LINE),FROM PUMP TO STEERING, Replaced By: A9329970772
110
SEAL RING SOLENOID VALVE A 18X24
110
SEAL RING SOLENOID VALVE A 18X24
110
SEAL RING SOLENOID VALVE A 18X24
115
LINE RETURN LINE TO STEERING,K 055018
120
UNION NUT LINE CONNECTION, Replaced By: N000000006239
125
GLAND , Replaced By: A0019901967
125
SEAL CONE LINE CONNECTION
130
HOSE RETURN, FROM STEERING TO OIL TANK
130
HOSE RETURN, FROM STEERING TO OIL TANK
140
BRACKET DELIVERY AND SUCTION LINES TO ENGINE, FRONT
140
BRACKET DELIVERY AND SUCTION LINES TO ENGINE, FRONT
145
BRACKET DELIVERY AND RETURN LINES,K 055018
145
BRACKET OIL LINE MOUNTING
145
BRACKET OIL LINE MOUNTING
150
BRACKET DELIVERY AND RETURN LINES,5 529814K 055043
150
BRACKET DELIVERY AND RETURN LINES,5 529814K 055043
150
BRACKET DELIVERY AND RETURN LINES,5 529814K 055043
155
BRACKET DELIVERY AND SUCTION LINES TO FRAME,K 017689
160
CLAMP DELIVERY AND SUCTION LINES TO ENGINE, FRONT
999
STEERING SUPPORT (STEERING BRACKET),5 426402
999
BRACKET OIL TANK,5 424631
999
STEERING BRACKET
999
PITMAN ARM ,K 055089
999
PITMAN ARM ,K 055088
999
STEERING SUPPORT ,K 055088
999
STEERING SUPPORT , THE OLD PART MUST NO LONGER BE INSTALLED, Replaced By: A6754612340
999
DRAG LINKEHRENREICH,5 424631K 054643
999
STEERING SHAFT
999
DRAG LINKEHRENREICH,5 424631K 054643
999
DRAG LINKLEMFOERDER,5 424631K 054643
999
DRAG LINKLEMFOERDER,5 424631K 054643
999
STEERING BRACKET
999
STEERING SHAFT ,5 426402
999
LINE (SUCTION LINE),FROM OIL TANK TO PUMP,5 163366
999
PITMAN ARM , Replaced By: A6754632201, +001A6754603605, +001A6764600129, +001A6754600835
999
LINE (RETURN LINE),FROM STEERING TO OIL TANK,5 163366
999
DRAG LINKLEHMFOERDER,5 426402
999
LINE (DELIVERY LINE) FROM HIGH PRESSURE HOSE TO STEERING BOX,5 163366
999
LINE , Replaced By: A0004292301
999
SCREW STEERING TO STEERING BRACKET,K 244309
999
BRACKET AIR INTAKE PIPE
999
STEERING SUPPORT (STEERING BRACKET),K 244309
999
LINE , Replaced By: A0004291001
999
STEERING BRACKET
999
CLAMP DELIVERY AND SUCTION LINES TO ENGINE, TOP
999
CLAMP LINE MOUNTING
999
HOSE
999
BOOT SCREWED PART OF JOINT
999
BOOT FIXED PART OF JOINT
999
BOOT FIXED PART OF JOINT
