Поз.
Артикул
Описание
5
AIR CLEANERMANN & HUMMEL,5 586475
5
AIR CLEANER ,5 586474, Replaced By: A0160948402, +001A6795280040, +002N000125013008, +002N000961012151, +002N913004012008
5
AIR CLEANERMANN & HUMMEL,5 586475
5
AIR CLEANER ,5 586474, Replaced By: A0160948402, +001A6795280040, +002N000125013008, +002N000961012151, +002N913004012008
11
FILTER ELEMENT AIR CLEANER KNECHT
11
FILTER ELEMENT AIR CLEANER
17
INTAKE PIPEKNECHT
23
NUT
23
NUT AIR CLEANER ELEMENT
23
NUT , Replaced By: N913002010001
29
SEAL RING AIR CLEANER BOWL KNECHT
29
GASKET AIR CLEANER BOWL
32
COVER LOWER PART
47
SCREW CONSOLE TO FRAME
47
SCREW , Replaced By: N308676016020
56
WASHER BRACKET TO FRAME
56
WASHER , Replaced By: N000125017016
62
NUT COMBINATION CYLINDER TO BEARING BRACKET
62
NUT COMBINATION CYLINDER TO BEARING BRACKET, Replaced By: N910113016002
68
MUFFLER (INTAKE MUFFLER)
71
RUBBER MOUNTING BRACKET TO BEARING BRACKET
74
BRACKET INTAKE MUFFLER
74
BRACKET , FIRST EXHAUST STOCK OF OLD PARTS UP TO IDENT NO. 5 494909, Replaced By: A6735282440
77
SCREW PIPE CLAMP
77
SCREW , Replaced By: N304017008021
80
WASHER EXHAUST MUFFLER TO STRAP
80
WASHER , Replaced By: N000125008443
83
NUT , Replaced By: N913004008001
86
RUBBER MOUNTING INTAKE MUFFLER TO BRACKET
89
SPACER TUBE PUMP TO FRAME SIDE MEMBER 12X21 MM
92
HEXALOBULAR BOLT. SCREW MANUAL PUMP BRACKET TO FENDER BRACKET
92
SCREW. HEXAGON HEAD BOLT , Replaced By: N910143008005
92
SCREW BRACKET TO SIDE MEMBER
92
SCREW , Replaced By: N304017008040
95
WASHER EXHAUST MUFFLER TO STRAP
95
WASHER , Replaced By: N000125008443
98
RETAINER INTAKE MUFFLER TO BRACKET
101
NUT , Replaced By: N913004008001
104
SCREW EXHAUST PIPE TO BRACKET
107
NUT STRAP TO BRACKET
107
NUT , Replaced By: N910113010000
122
AIR INTAKE PIPE
125
BUFFER REFRIGERANT LINE TO CAB
125
BUFFER , THE OLD PART MUST NO LONGER BE INSTALLED, Replaced By: A6739880511
128
WASHER BRACKET TO LEFT SIDE MEMBER
128
WASHER , Replaced By: N009021008213
131
NUT , Replaced By: N913004008001
134
PLUG AIR INTAKE PIPE
137
BOOT AIR INTAKE
137
BOOT , FIRST EXHAUST STOCK OF OLD PARTS UP TO IDENT NO. K 034532, Replaced By: A0005280091
140
CLAMP BOOT TO INTAKE PIPE
143
CLAMP BOOT TO AIR CLEANER,K 034532
146
SCREW BOOT TO AIR DUCT AND TO AIR CLEANER
149
NUT BOOT TO AIR DUCT AND TO AIR CLEANER
152
HOSE TO OIL BATH AIR CLEANER
158
CLAMP FROM AIR CLEANER TO HOT AIR INTAKE PIPE
188
CAP INTAKE MUFFLER FITTING
191
LOOM TIE LINE MOUNTING 280 MM
209
HOSE FROM MUFFLER TO ENGINE
214
CLAMP HOSE TO RADIATOR,PIPE ELBOW,AND WATER PUMP 82 - 105 X 15.8 MM
214
CLAMP , Replaced By: A0059972990
214
CLAMP , Replaced By: N000000000675
217
CLAMP FROM AIR CLEANER TO HOT AIR INTAKE PIPE
217
CLAMP FROM AIR CLEANER TO HOT AIR INTAKE PIPE
999
BRACKET AT SIDE MEMBER
999
SCREW CONSOLE TO SIDE MEMBER
