Поз.
Артикул
Описание
3
CROSS MEMBERNO.1,B 868311
6
GUSSET PLATE FRONT TOP AND BOTTOM
9
SCREW ANGLE TO CROSS MEMBER M 10X30
12
NUT GUSSET PLATES AND REAR CROSS MEMBER TO SIDE MEMBERS
14
ENGINE CROSS MEMBER FRONT
22
BRACKET
24
SCREW , Replaced By: N304017010040
24
SCREW ANGLE TO CROSS MEMBER M 10X30
26
NUT GUSSET PLATES AND REAR CROSS MEMBER TO SIDE MEMBERS
28
CONSOLE REAR RUBBER MOUNTING
30
SCREW SUPPORT TO SIDE MEMBER M 12X1.5X30
33
NUT ALTERNATOR TO SUPPORT
36
REINFORCEMENT LEFT,FRONT SPRING FRONT BRACKET
36
REINFORCEMENT RIGHT,FRONT SPRING FRONT BRACKET
39
FRONT SPRING BRACKET FRONT
42
FRONT SPRING BRACKET FRONT AND REAR
45
WASHER
48
SCREW , Replaced By: N308676014012
48
SCREWM 14X14X24X42
51
NUT , Replaced By: N910113014000
54
BEARING BRACKET FRONT SPRING FRONT BRACKET
57
SCREW BATTERY CASE
57
SCREW SUPPORT TO FRAME M12X1,5X35,D 127794
60
NUT ALTERNATOR TO SUPPORT
60
NUT , Replaced By: N910113014000
63
STAY
66
STAY FRONT SPRING STOP
69
ANGLE AT RIGHT SIDE MEMBER
72
CROSS MEMBER , Replaced By: A3843127225
75
REINFORCEMENT RIGHT,FRONT SPRING REAR BRACKET
75
REINFORCEMENT LEFT,FRONT SPRING REAR BRACKET
