Поз.
Артикул
Описание
5
ELECTRIC CABLE ENGINE CABLE HARNESS
5
ELECTRIC CABLE ENGINE CABLE HARNESS
11
PIN BUSHING HOUSING STOP LIGHT SWITCH
14
PIN BUSHING HOUSING AIR CLEANER INTAKE PIPE, ONLY ON RETROFIT/CATALYST VEHICLES
17
GASKETTO 124 540 13 81, ONLY ON RETROFIT/CATALYST VEHICLES
20
PIN BUSHING HOUSING MICRO-SWITCH
23
PIN BUSHING HOUSING 7-POLE
26
COVER (TRIMMER PLUG)
29
ROUND PIN BUSHING2.5 MM2
35
PIN BUSHING HOUSING TELL-TALE LAMP ASD
41
PIN BUSHING HOUSING ENGINE CABLE HARNESS CENTRAL ELECTRICAL SYSTEM, 8-POLE
44
PIN BUSHING HOUSING DIAGNOSIS BOX
47
PIN BUSHING HOUSING CENTRAL ELECTRICAL SYSTEM
50
ROUND PIN BUSHING LIGHT SWITCH 2,5 MM
53
ROUND PIN BUSHING LIGHT SWITCH
65
PIN BUSHING HOUSING UNIPOLAR, HEAT SENSOR CONNECTION
68
PIN BUSHING HOUSING REFRIGERANT COMPRESSOR
71
PIN BUSHING HOUSING OVERLOAD PROTECTOR
74
PIN BUSHING HOUSING FUSE BOX
77
PIN BUSHING HOUSING COMPRESSOR CONTROL UNIT, 12-POLE
80
PIN BUSHING HOUSING , 10/20 UP TO CHASSIS 4 411810,50/60 UP TO CHASSIS 4 414810
83
COVER , 10/20 UP TO CHASSIS 4 411810,50/60 UP TO CHASSIS 4 414810
86
PIN BUSHING HOUSING SPEED TRANSMITTER
95
ROUND PIN BUSHING WITH DETENT AND WITH CATCH FOR HOUSING 2.5 MM2
98
PIN BUSHING HOUSING UNIPOLAR, FROM CHASSIS:107.023 000429 107.043 006834 107.044 004104
101
COVERTO 011 545 10 28
104
PIN BUSHING HOUSING ELECTRIC CHANGE-OVER VALVE
107
CAP , Replaced By: A0125450428, +001A0125450528
107
COVERTO 008 545 08 28,008 545 09 28
113
ROUND PIN BUSHING4 MM2
115
PLUG HOUSING
116
PLUG PIN
119
PLUG HOUSING MAIN CABLE HARNESS
122
COVERTO 011 545 10 28
125
PLUG PIN
128
PLUG WARM-UP SENDER,COLD START VALVE,AIRFLOW SENSOR PLATE CONTACT OR AIR SLIDE
131
CONTACT SPRING , Replaced By: A0035450226
131
CONTACT SPRING1-2.5 MM2
134
BOOTTO 116 540 01 81
134
BOOT TIMING VALVE
146
PIN BUSHING RADIO SET
149
INSULATING SLEEVETO 000 546 43 40
152
INSULATING HOSE PRESSURE REGULATOR,CONNECTION "3", ORDER BY THE METER5 148812
175
TRIMMER PLUGARA 220 OHM
175
TRIMMER PLUGARA 0 OHM
176
SERIES RESISTOR
182
SHEET METAL SCREW PRE-GLOW TIME RELAY TO STEERING COLUMN JACKET TUBE CONSOLE
188
SCREW ELECTRIC CABLE TO HORN
191
LOCK WASHER T-FITTING TO BRACKET
194
CLIP PLUG TO REAR PILLAR
197
SCREW , Replaced By: N304017006016
203
SCREW COVER PLATE TO COVER PLATE M 6 X 10
203
SCREW , Replaced By: N304017006034
206
SPRING WASHER LICENSE PLATE TO BRACKET
225
SENDER UNIT ADJUSTMENT TO ALTITUDE, FROM MODEL YEAR'86
228
BRACKET
231
SHEET METAL SCREW ANTENNA CABLE TO REAR INSIDE PILLAR
