Поз.
Артикул
Описание
275
SUPPORT REFRIGERANT COMPRESSOR
278
SLEEVE
281
SCREENING
283
SPACER TUBE FRONT AXLE REGULATING SOLENOID VALVE
283
SPACER TUBE , Replaced By: A1801550053
285
SCREW , Replaced By: N304014008001
285
SCREW , Replaced By: N304014008009
285
SCREW 3/2-WAY VALVE TO BRACKET
285
SCREW FRONT AXLE REGULATING SOLENOID VALVE M 8X75
287
SCREWM 8X60
287
SCREW , Replaced By: N007984008041
289
SPRING WASHER , Replaced By: N000137008212
289
SPRING WASHER PROTECTIVE PLATE TO EXHAUST MUFFLER
299
SCREW REAR AXLE REGULATING SOLENOID VALVE M 8X95
302
WASHER EXHAUST MUFFLER TO STRAP
302
WASHER , Replaced By: N000125008443
304
BRACKET BRACKET TO TIMING CASE COVER
306
CLAMP BOWDEN CABLE TO CAB
306
CLAMP , Replaced By: A0009956044
308
COMBINATION BOLT , Replaced By: N304017006016
308
COMBINATION BOLT
310
BRACKET REFRIGERANT COMPRESSOR TO SUPPORT
311
BRACKET REFRIGERANT COMPRESSOR TO SUPPORT
312
SCREW , Replaced By: N304017008021
312
SCREW PIPE CLAMP
313
SCREW , Replaced By: N000912008219
313
SCREW , Replaced By: N000912008200
313
SCREW SPRING STOP
316
WASHER
318
BELT TIGHTENER PULLEY. BELT TIGHTENER REFRIGERANT COMPRESSOR
320
SCREW SHEAVE PULLEY TO BRACKET M8X40
320
SCREW , Replaced By: N006912008014
322
COVER TIGHTENER PULLEY SA 22400
334
SUCTION LINE REFRIGERANT LINE
334
SUCTION LINE , Replaced By: A6032301656
336
VALVE , NOT USED
336
VALVE
338
CAP
338
CAP , NOT USED
340
SEAL RING HOSE TO CONDENSER 14 MM
999
SUCTION LINE REFRIGERANT LINE, NOT USED
