Поз.
Артикул
Описание
20
BRACKET MOUNTING USED FOR COMPRESSED AIR LINES
24
SCREW PLUG SOCKET TO FRAME
28
WASHER TRAILER PLUG SOCKET TO BRACKET
32
LOCK WASHER RAIL TO BATTERY SUPPORT
36
NUT LEVER TO SHIFTING SHAFT
40
CLAMP
40
CLAMP , Replaced By: A3129952420
44
SCREW CAP TO BRACKET
48
LOCK WASHER EXTENSIBLE BRAKE VALVE TO CAB
52
NUT
56
FITTING PRESSURE REGULATOR,CONNECTION "2.1",4 967998
56
T-FITTING , Replaced By: N074317000100
60
NUT CHECK VALVE TO AIR RESERVOIR
64
THRUST RING CHECK VALVE TO AIR RESERVOIR
64
THRUST RING , THE OLD PART MUST NO LONGER BE INSTALLED, Replaced By: A0009940203
68
O-RING CHECK VALVE TO AIR RESERVOIR
98
VALVE"BOSCH DO BRASIL
98
VALVE"BOSCH"
108
DIAPHRAGMTO 344 429 73 44
116
LOCK WASHER TAIL LAMP TO BRACKET
118
NUT , Replaced By: N304032008006
120
SCREW LINES TO BRACKET
122
LOCK WASHER TAIL LAMP TO BRACKET
124
SCREW BRACKET TO INTAKE MANIFOLD
140
THRUST RING BUTT SCREW CONNECTION
142
SEAL RING , Replaced By: N007603012121
146
CONNECTOR MOUNTING USED FOR COMPRESSED AIR LINES
148
CONNECTOR MOUNTING USED FOR COMPRESSED AIR LINES
150
ELBOW FITTING CHECK VALVE TO AIR RESERVOIR
150
FITTING AIR RESERVOIR
152
NUT CHECK VALVE TO AIR RESERVOIR
154
THRUST RING , THE OLD PART MUST NO LONGER BE INSTALLED, Replaced By: A0009940203
154
THRUST RING CHECK VALVE TO AIR RESERVOIR
156
O-RING CHECK VALVE TO AIR RESERVOIR
164
LINE FROM AIR RESERVOIR TO BRAKE BOOSTER, "SUPPLY" 15X1.5 MM
164
LINE FROM AIR RESERVOIR TO HAND BRAKE VALVE 15X1.5 MM
164
LINE FROM AIR RESERVOIR TO BRAKE BOOSTER, "SUPPLY" 15X1.5 MM
166
LINE FROM AIR RESERVOIR TO HAND BRAKE VALVE 15X1.5 MM
194
BRACKET LINE TO BRAKE BOOSTER
196
CLAMP , Replaced By: N916016008200
196
CLAMP ,K 147121, Replaced By: N000000000319
196
CLAMP , Replaced By: A3604300143
198
SCREW CAP TO BRACKET
200
NUT
202
WASHER , Replaced By: N009021006208
204
LOCK WASHER EXTENSIBLE BRAKE VALVE TO CAB
230
VALVE , THIS NOTE OF REPLACEMENT APPLIES ONLY TO THE ITEM LISTED OPPOSITE, Replaced By: A3454307481
230
VALVE , Replaced By: A3454307581
230
VALVE , Replaced By: A3454307581
230
VALVE HAND BRAKE VALVE WABCO
238
REPAIR KIT , Replaced By: A0034301081
238
PINTO 345 430 75 81
238
REPAIR KITTO 345 430 75 81
238
REPAIR KIT IN ITS PLACE,YOU MAY ALSO USE MERCEDES-BENZ PART NO.: 000 586 23 43,
240
FITTING
240
FITTING LINE CONNECTION, Replaced By: N000000006446
240
SCREW-IN FITTING LINE CONNECTION
242
SEAL RING
244
BRACKET HAND BRAKE VALVE
246
SCREW PLUG SOCKET TO FRAME
248
LOCK WASHER RAIL TO BATTERY SUPPORT
250
SCREW POWER CYLINDER TO BEARING BRACKET
252
LOCK WASHER RAIL TO BATTERY SUPPORT
254
NUT LEVER TO SHIFTING SHAFT
838
BRACKET FUEL LINES
999
DIAPHRAGMTO 000 429 00 44
999
THRUST WASHERTO 000 429 00 44
999
LOCKTO 000 429 00 44
999
SPRING RETAINERTO 000 429 00 44
999
VALVE NIPPLETO 000 429 00 44
999
SPRINGTO 000 429 00 44
999
SPRINGTO 000 429 00 44
999
VALVE
999
REPAIR KIT CONTROL VALVE TO 002 431 28 05
999
REPAIR KITTO 001 430 23 81, NOT USED
999
HANDLETO 001 430 23 81, NOT USED
999
HANDLETO 345 430 75 81
999
SEAL RING
999
THRUST RING LOCKING VALVE
999
CLAMP
999
CLAMP , Replaced By: A1109950401
999
BRACKET PRESSURE REGULATOR TO AIR RESERVOIR
999
LINE FROM DOUBLE FITTING TO AIR RESERVOIR 15X1.5 MM
999
LINE CONTROL VALVE,CONNECTION "1" 15X1.5 MM
999
LINE FROM FITTING TO RIGHT SHUT-OFF COCK 15X1.5 MM
999
LINE FROM BRAKE BOOSTER TO TWO-WAY VALVE 15X1.5 MM, B03543/06/08 UP TO IDENT NO.: 549429
999
LINE FROM CONTROL VALVE TO SHUT-OFF COCK 15X1.5 MM
999
LINE FROM CONTROL VALVE TO SHUT-OFF COCK 15X1.5 MM
999
LINE FROM AIR RESERVOIR TO TRUCK-TRACTOR BRAKE VALVE 15X1.5 MM, INAPPLICABLE TO SUPERCHARGING SYSTEM376448609835
999
CLAMP COMPRESSED AIR LINE MOUNTING
999
BRACKET LINE MOUNTING
999
LINE FROM FITTING TO SHUT-OFF COCK 15X1.5 MM
999
LINE FROM FITTING TO SHUT-OFF COCK
999
LINE FROM CONTROL VALVE TO SHUT-OFF COCK
999
LINE FROM CONTROL VALVE TO SHUT-OFF COCK
999
LINE FROM AIR RESERVOIR TO BRAKE BOOSTER, "SUPPLY" 15X1.5 MM, 001,002,003,021,024,025 FROM CHASSIS 002984,005,006,007,008,033 FROM CHASSIS 000864 USED WITH HYDRAULIC BRAKE,345.000-008,021,024,025,033 UP TO IDENT NO. FB588185
999
LINE FROM AIR RESERVOIR TO BRAKE BOOSTER, "SUPPLY" 15X1.5 MM, 001,002,003,021,024,025 FROM CHASSIS 002984,005,006,007,008,033 FROM CHASSIS 000864 USED WITH HYDRAULIC BRAKE,345.000-008,021,024,025,033 UP TO IDENT NO. FB588185
999
LINE FROM AIR RESERVOIR II TO HAND BRAKE VALVE 15X1.5 MM, 001,002,003,021,024,025 FROM CHASSIS 002984,005,006,007,008,033 FROM CHASSIS 000864 USED WITH HYDRAULIC BRAKE,345.000-008,021,024,025,033 UP TO IDENT NO. FB588185
999
LINE FROM AIR RESERVOIR II TO HAND BRAKE VALVE 15X1.5 MM, 001,002,003,021,024,025 FROM CHASSIS 002984,005,006,007,008,033 FROM CHASSIS 000864 USED WITH HYDRAULIC BRAKE,345.000-008,021,024,025,033 UP TO IDENT NO. FB588185
999
ELBOW FITTING
999
LINE FROM AIR RESERVOIR TO OVERFLOW VALVE
999
LINE FROM PRESSURE REGULATOR TO AIR RESERVOIR
999
LINE FROM PRESSURE REGULATOR TO AIR RESERVOIR 15X1.5 MM
999
LINE FROM AIR RESERVOIR TO OVERFLOW VALVE
999
LINE FROM FITTING TO RIGHT SHUT-OFF COCK 15X1.5 MM
999
BRACKET
999
VALVE OVERFLOW VALVE
999
LINE FROM FITTING TO SHUT-OFF COCK 15X1.5 MM
999
LINE AIR COMPRESSOR 18X1.5 MM,511032
999
LINE FROM PRESSURE REGULATOR TO AIR RESERVOIR 15X1.5 MM,511032
999
LINE FROM AIR RESERVOIR TO T-FITTING 15X1.5 MM
999
LINE FROM T-FITTING TO BRAKE BOOSTER 15X1.5 MM
999
LINE FROM T-FITTING TO FITTING 8X0.7 MM
999
LINE FROM AIR RESERVOIR TO OVERFLOW VALVE 15X1.5 MM
999
NUT LOCKING VALVE TO TRAILER CONTROL VALVE,CONNECTION: "42"
999
SCREW CABLE TO ALTERNATOR
