Поз.
Артикул
Описание
5
STEERING SUPPORT
8
SCREW BEARING BRACKET AND PLATE TO FRAME M 16X1.5X40
11
LOCK WASHER TRANSMISSION TO BELL HOUSING
14
FITTED SCREW STEERING TO STEERING COLUMN BRACKET
17
NUT ,4 179001
20
SCREW BRACKET TO SIDE MEMBER
23
NUT , Replaced By: N910113014000
26
PITMAN ARM
29
NUT PITMAN ARM TO STEERING BOX ASSEMBLY
32
COTTER PINROCKINGER TYP 260 G140
35
TRUNNION BEARING
35
TRUNNION BEARING STEERING INTERMEDIATE ARM
38
STEERING INTERMEDIATE ARM
41
TAPERED ROLLER BEARING FRONT
44
SPACER WASHER INTERMEDIATE LEVER TO BEARING BRACKET
47
SEAL RING
50
TAPERED ROLLER BEARING INTERMEDIATE LEVER TO BEARING BRACKET
53
THRUST WASHER STEERING INTERMEDIATE ARM BEARING
56
NUT
59
COTTER PINROCKINGER TYP 260 G140
62
CAP AT STEERING INTERMEDIATE ARM
65
GREASE NIPPLE
68
SCREW BRACKET TO SIDE MEMBER
71
SHIM PIVOT BEARING TO SUBSTRUCTURE
74
LOCK WASHER BRACKET TO SIDE MEMBER,5 703114
77
77
98
JOINT
101
DUST CAPTO 345 460 81 05,376 460 01 05
104
CLAMPING RING FIXED PART OF JOINT TO 345 460 86 05, USED WITH AIR BRAKE, 341.041,042,044 FROM CHASSIS A 059729 ALSO INSTALLED ON A 059166,A 059217,A 059218,A 059268,A 059276,A 059356-A 059359,A 059411,A 059418,A 059419,A 059425,A 059426,A 059594,A 059613, A 059625,A 059626,A 059647,A 059648.
107
CLAMPTO 364 460 72 05,364 460 73 05
110
SCREW CLAMP TO DRAG LINK TO 344 338 73 45
113
NUT BRACKET TO SIDE MEMBER,XB209706
116
DRAG LINK FROM INTERMEDIATE LEVER TO STEERING ARM
116
DRAG LINK FROM INTERMEDIATE LEVER TO STEERING ARM
119
JOINT
122
DUST CAPTO 345 460 81 05,376 460 01 05
125
CLAMPING RING FIXED PART OF JOINT TO 345 460 86 05, USED WITH AIR BRAKE, 341.041,042,044 FROM CHASSIS A 059729 ALSO INSTALLED ON A 059166,A 059217,A 059218,A 059268,A 059276,A 059356-A 059359,A 059411,A 059418,A 059419,A 059425,A 059426,A 059594,A 059613, A 059625,A 059626,A 059647,A 059648.
125
CLAMPING RINGTO 345 460 86 05
128
SPACER RING SCREWED PART OF JOINT TO 345 460 86 05, USED WITH AIR BRAKE, 341.041,042,044 FROM CHASSIS A 059729 ALSO INSTALLED ON A 059166,A 059217,A 059218,A 059268,A 059276,A 059356-A 059359,A 059411,A 059418,A 059419,A 059425,A 059426,A 059594,A 059613, A 059625,A 059626,A 059647,A 059648.
131
CLAMPTO 364 460 72 05,364 460 73 05
134
SCREW CLAMP TO DRAG LINK TO 344 338 73 45
137
NUT BRACKET TO SIDE MEMBER,XB209706
140
NUT
143
COTTER PINROCKINGER TYP 260 G140
146
SHOCK ABSORBER"COFAP", ONLY APPLICABLE TO VEHICLES EQUIPPED WITH CATALYTIC CONVERTER, Replaced By: A6344600066
146
SHOCK ABSORBER , Replaced By: A3644607466
146
SHOCK ABSORBER
146
SHOCK ABSORBER , Replaced By: A0004636132
146
SHOCK ABSORBER"MONROE"
146
STEERING SHOCK ABSORBER"COFAP"
146
SHOCK ABSORBER , FIRST EXHAUST STOCK OF OLD PARTS UP TO IDENT NO. 373163-10-217767 / 373195-10-217917, Replaced By: A0004636432
149
RUBBER RING TOP AND BOTTOM TO A 6883260200
149
RUBBER RINGTO 344 460 70 66
149
RUBBER RING
152
BUSHINGTO 364 460 72 66,73 66,74 66
152
BUSHINGTO 344 460 70 66, NOT CARRIED AS A SPARE PART
152
BUSHING
158
CLAMPING RINGTO 364 460 71 66
161
CLAMPING RINGTO 364 460 71 66
162
BOOTLEMFOERDER
164
BRACKET STEERING SHOCK ABSORBER
167
SCREW CROSS MEMBER TO CONSOLE M 12X1.5X90,D 132899D 154054
170
NUT SUPPORT TO SIDE MEMBER
173
SCREW ARTICULATED ROD TO LEVER
176
NUT BRACKET TO BATTERY CASE
179
NUT STEERING SHOCK ABSORBER TO STEERING ARM
182
COTTER PIN
