Поз.
Артикул
Описание
6
BEARING
11
GASKET , 000,001,004,010,016 FROM CHASSIS 079284, 100,101,104,110,116 FROM CHASSIS 124610
15
BRACKET GEAR INDICATOR BOWDEN CABLE, 016 UP TO CHASSIS 027622 EXCEPT FOR, SEE GROUP 22/24, FOOTNOTE 6, 018 UP TO CHASSIS 028985 EXCEPT FOR, SEE GROUP 22/24, FOOTNO TE 7, 019 UP TO CHASSIS 029325
19
SHEET METAL SCREW TYPE PLATE TO FIRE WALL
23
NUT RETAINER , Replaced By: A0019906791
23
NUT RETAINER REGULATOR AND CUT-OUT, FOR VEHICLES HAVING LOW CAB 344 ON CAB 344
43
PEDAL , 000,001,004,010,016 FROM CHASSIS 064106 ALSO INSTALLED ON, SEE FOOTNOTE 5, 100,101,104,110,116 FROM CHASSIS 099642 ALSO INSTAL LED ON, SEE FOOTNOTE 6, EXCEPT FOR 099892
49
BUSHING BRAKE PEDAL
49
BUSHING , Replaced By: A1242920050
62
PEDAL , 000,001,004,010,016 FROM CHASSIS 064106 ALSO INSTALLED ON, SEE FOOTNOTE 5, 100,101,104,110,116 FROM CHASSIS 099642 ALSO INSTAL LED ON, SEE FOOTNOTE 6, EXCEPT FOR 099892
66
BUSHING , Replaced By: A1242920050
66
BUSHING BRAKE PEDAL
70
BUSHING
75
PAD BRAKE
79
PIN PEDAL TO SUPPORT, 000,001,004,010,016 FROM CHASSIS 064106 ALSO INSTALLED ON, SEE FOOTNOTE 5, 100,101,104,110,116 FROM CHASSIS 099642 ALSO INSTAL LED ON, SEE FOOTNOTE 6, EXCEPT FOR 099892
83
LOCK WASHER COMPRESSED AIR LINE TO BRACKET
87
NUT SHIFT LEVER HANDLE TO SHIFT LEVER
98
BUSHING
104
NUT
107
NUT
114
SPRING RETAINER SPRING TO PUSH ROD
123
SPRING RETAINER , Replaced By: A3092910091
126
SPRING RETAINER , Replaced By: A3092910091
130
WASHER PUSH ROD TO PEDAL, 000,001,004,010,016 FROM CHASSIS 064106 ALSO INSTALLED ON, SEE FOOTNOTE 5, 100,101,104,110,116 FROM CHASSIS 099642 ALSO INSTAL LED ON, SEE FOOTNOTE 6, EXCEPT FOR 099892
130
WASHER MOUNTING PLATE TO BODY FLOOR
134
LOCK PUSH ROD TO PEDAL, 000,001,004,010,016 FROM CHASSIS 064106 ALSO INSTALLED ON, SEE FOOTNOTE 5, 100,101,104,110,116 FROM CHASSIS 099642 ALSO INSTAL LED ON, SEE FOOTNOTE 6, EXCEPT FOR 099892
139
WASHER 2.0 MM
143
STOP CLUTCH PEDAL
148
SPRING
162
SNAP RING
165
BOOT
174
CONNECTOR
178
BLEEDER VALVE
182
PROTECTIVE CAP ,5 962906
182
PROTECTIVE CAP , Replaced By: A0004217187
194
BUSHING , 021245
198
WASHER , 021245
202
LOCK , 021245
206
ROD , 000,001,004,010,016 FROM CHASSIS 064106 ALSO INSTALLED ON, SEE FOOTNOTE 5, 100,101,104,110,116 FROM CHASSIS 099642 ALSO INSTAL LED ON, SEE FOOTNOTE 6, EXCEPT FOR 099892
210
BUSHING
214
SCREW , UP TO CHASSIS: 023 101126 072 103733 073 106943, Replaced By: A1152950172, +001N000137008202, +001N000933008131
214
NUT ROD TO LEVER,526440
218
LOCK WASHER
222
NUT , 000,001,004,010,016 FROM CHASSIS 064106 ALSO INSTALLED ON, SEE FOOTNOTE 5, 100,101,104,110,116 FROM CHASSIS 099642 ALSO INSTAL LED ON, SEE FOOTNOTE 6, EXCEPT FOR 099892
230
STRAINER
250
CLAMPING SCREW , FROM CHASSIS 045294, ALSO INSTALLED ON, SEE GROUP 26, FOOTNOTE 24
254
LOCK WASHER CONTROL LEVER TO INJECTION PUMP LEVER
258
NUT BALL PIVOT TO LEVER
266
HOSE FROM RESERVOIR TO MASTER CYLINDER, ORDER BY THE METER
266
HOSE FROM RESERVOIR TO MASTER CYLINDER
270
INTERMEDIATE PIECE FROM RESERVOIR TO MASTER CYLINDER, FROM CHASSIS 001859 ALSO INSTALLED ON 001473,001548,001702,001722,001786,001797,001801,001804,001853-001857
274
LINE , FROM CHASSIS 094171
279
SCREW PLUG
282
HOSE , 10/50 FROM CHASSIS 094171, 20/60 FROM CHASSIS 093900
999
NUT
999
HOSE30 MM, ORDER BY THE METER
999
CLAMP , 000,001,004,010,016 FROM CHASSIS 130558, 100,101,104,110,116 FROM CHASSIS 225648
999
SHEET METAL SCREW PRE-GLOW TIME RELAY TO STEERING COLUMN JACKET TUBE CONSOLE
999
SHEET METAL SCREW , 000,001,004,010,016 FROM CHASSIS 130558, 100,101,104,110,116 FROM CHASSIS 225648
999
LOCK PLATE PUSH ROD TO CLUTCH PEDAL
999
NUT , Replaced By: N304032008006
999
SCREW TORSION BAR TO REAR AXLE
999
SCREW
999
WASHER BRACKET TO CROSS MEMBER
999
SPRING WASHER GROUND CABLE TO TRANSMISSION
999
SPRING WASHER LICENSE PLATE TO BRACKET
999
WASHER , FROM CHASSIS: 005,007,008,015,017 10/50,12/52 009573, ALSO INSTALLED ON: 009319,009323,009404,009444,009449,009450,009454-009456,009458,009459,009461-009472,009475-009477, 009479-009494,009496-009571. 010 10/50,12/52 013397, ALSO INSTALLED ON: 013289,013348,013354,013356,013358,013361-013367,013370-013381,013384-013388,013390-013395. 005,007,008,015,017 20/60,22/62 012727 010 20/60,22/62 015672
999
SPRING
999
BRACKET
999
BRACKET , 10/50 FROM CHASSIS 094171, 20/60 FROM CHASSIS 093900
999
BRACKET , 021245
999
ROD
999
RESERVOIR , UP TO CHASSIS: 023 100513 072 102501 073 103666
999
EXPANSION PLUG ELECTRIC CABLE THRU FIRE WALL,4 9400475 187082
999
LINE
999
LINE FROM CONNECTING HOSE TO SLAVE CYLINDER, 000,001,004,010,016 FROM CHASSIS 064106 ALSO INSTALLED ON, SEE FOOTNOTE 5, 100,101,104,110,116 FROM CHASSIS 099642 ALSO INSTAL LED ON, SEE FOOTNOTE 6, EXCEPT FOR 099892 TO BE ADAPTED DURING ASSEMBLY
999
LINE , Replaced By: A1132901713
999
EXPANSION PLUG , Replaced By: A1139870044
999
PIN PEDAL TO SUPPORT, 000,001,004,010,016 FROM CHASSIS 064106 ALSO INSTALLED ON, SEE FOOTNOTE 5, 100,101,104,110,116 FROM CHASSIS 099642 ALSO INSTAL LED ON, SEE FOOTNOTE 6, EXCEPT FOR 099892
999
BEARING , 000,001,004,010,016 FROM CHASSIS 064106 ALSO INSTALLED ON, SEE FOOTNOTE 5
999
GASKET , 016 FROM CHASSIS 027623, ALSO INSTALLED ON, SEE GROUP 22/24, FOOTNOTE 6, 018 FROM CHASSIS 028986, ALSO INSTALLED ON, SEE GROUP22/24, FOOTNOTE 7, 019 FROM CHASSIS 029326
999
PIN PEDAL TO SUPPORT, 016 FROM CHASSIS 027623, ALSO INSTALLED ON, SEE GROUP 22/24, FOOTNOTE 6, 018 FROM CHASSIS 028986, ALSO INSTALLED ON, SEE GROUP22/24, FOOTNOTE 7, 019 FROM CHASSIS 029326
999
LINE , Replaced By: A1123205753
999
BRACKET , 016 FROM CHASSIS 027623, ALSO INSTALLED ON, SEE GROUP 22/24, FOOTNOTE 6, 018 FROM CHASSIS 028986, ALSO INSTALLED ON, SEE GROUP22/24, FOOTNOTE 7, 019 FROM CHASSIS 029326
999
PEDAL , 016 FROM CHASSIS 027623, ALSO INSTALLED ON, SEE GROUP 22/24, FOOTNOTE 6, 018 FROM CHASSIS 028986, ALSO INSTALLED ON, SEE GROUP22/24, FOOTNOTE 7, 019 FROM CHASSIS 029326
999
BEARING , 016 FROM CHASSIS 027623, ALSO INSTALLED ON, SEE GROUP 22/24, FOOTNOTE 6, 018 FROM CHASSIS 028986, ALSO INSTALLED ON, SEE GROUP22/24, FOOTNOTE 7, 019 FROM CHASSIS 029326
999
PEDAL , 016 FROM CHASSIS 027623, ALSO INSTALLED ON, SEE GROUP 22/24, FOOTNOTE 6, 018 FROM CHASSIS 028986, ALSO INSTALLED ON, SEE GROUP22/24, FOOTNOTE 7, 019 FROM CHASSIS 029326
999
GROMMET
999
CLIP TRIMMER PLUG
999
HOSE ORDER BY THE METER, 016 UP TO CHASSIS 027622 EXCEPT FOR, SEE GROUP 22/24, FOOTNOTE 6, 018 UP TO CHASSIS 028985 EXCEPT FOR, SEE GROUP 22/24, FOOTNO TE 7, 019 UP TO CHASSIS 029325
999
CLIP
999
REPAIR KIT , UP TO CHASSIS: TO 000 295 51 06 021: 10/50 007951 022: 10/50 019872
999
MASTER CYLINDER , 021245
999
MASTER CYLINDER
999
HOSE , 016 FROM CHASSIS 027623, ALSO INSTALLED ON, SEE GROUP 22/24, FOOTNOTE 6, 018 FROM CHASSIS 028986, ALSO INSTALLED ON, SEE GROUP22/24, FOOTNOTE 7, 019 FROM CHASSIS 029326
999
HOSE , 000,001,004,010,016 FROM CHASSIS 173244, 100,101,104,110,116 FROM CHASSIS 315651
