Поз.
Артикул
Описание
5
EXHAUST SYSTEM , PART IS ONLY OR ALSO SUPPLIED AS RECONDITIONED PART
10
CATALYTIC CONVERTER SYS. , PART IS ONLY OR ALSO SUPPLIED AS RECONDITIONED PART
20
SEAL RING UPSTREAM OF PARTICULATE FILTER
30
CLAMP EXHAUST LINE TO EXHAUST PIPE, FRONT
40
SCREW CLAMP ON BRACKET
50
DIESEL PARTICULATE FILTER , PART IS ONLY OR ALSO SUPPLIED AS RECONDITIONED PART
60
BRACKET TO PARTICULATE FILTER
65
BRACKET
65
BRACKET AT OIL PAN
70
BASE PLATE BRACKET TO FRONT EXHAUST PIPE
75
HEXAGON NUT SCREENING PLATE,5 163561
80
SCREW BRACKET TO SIDE MEMBER M8X20
92
NUT VALVE TO BRACKET
93
NOX SENSOR , J 20130507 V 00009320130628
93
NOX SENSOR , J 20130507 V 00009220130628
94
ELECTRICAL WIRING HARNESS FRONT NOX SENSOR CONNECTOR
95
OXYGEN SENSOR
96
TEMPERATURE SENSOR
98
TEMPERATURE SENSOR UPSTREAM OF PARTICULATE FILTER
98
TEMPERATURE SENSOR TEMPERATURE SENSOR CATALYST, A 15889720090528
100
FLANGE GASKET FRONT
115
BOLT CATALYST TO BRACKET M8X20
120
BRACKET TO PRE-CATALYST
120
BRACKET TO THREE-WAY CATALYTIC CONVERTER
125
HEXALOBULAR BOLT. SCREW LINE MOUNTING M 6X30
125
HEXALOBULAR BOLT COVER PANEL FASTENING M8 X 16
125
HEXALOBULAR BOLT RIGHT BRACKET TO CYLINDER HEAD COVER M6X18
130
PRESSURE LINE UPSTREAM OF PARTICULATE FILTER
130
PRESSURE LINE UPSTREAM OF PARTICULATE FILTER
135
BRACKET ATTACHMENT DELIVERY LINE
140
PRESSURE LINE DOWNSTREAM OF PARTICULATE FILTER
140
PRESSURE LINE DOWNSTREAM OF PARTICULATE FILTER
150
SHACKLE UPPER PART
155
SCREW. HEXAGON HEAD BOLT RELAY TO BRACKET M5X16
170
EXHAUST HOSE TO PRESSURE SENSOR
170
EXHAUST GAS HOSE TO PRESSURE SENSOR
175
LOOM TIE , A 358832 EXCEPT FOR A 331465 - A 358832 WITH CODE 057
175
LOOM TIE13,5 X 6 MM
180
EXHAUST HOSE TO PRESSURE SENSOR
180
EXHAUST GAS HOSE TO PRESSURE SENSOR
185
HOSE CLAMP HOSE ATTACHMENT
185
LOOM TIE13,5 X 6 MM
190
BRACKET FASTENING, EXHAUST HOSES
195
NUT BRACKET TO BODY SHELL M6
200
PRESSURE SENSOR PARTICLE FILTER
200
PRESSURE SENSOR
200
PRESSURE SENSOR AT SPLASH WALL
205
HEXALOBULAR BOLT. SCREW LINE MOUNTING M 6X30
220
BRACKET NOX SENSOR
222
NUT VALVE TO BRACKET
223
CLAMP BOWDEN CABLE TO CAB
225
CLAMP FRONT EXHAUST PIPE TO REAR EXHAUST PIPE 76 MM
260
BRACKET O2 SENSOR GUIDE
260
BRACKET SENSOR LINE FASTENING, A 02506420110818
265
BRACKET TO SHIELD
