Поз.
Артикул
Описание
8
LINE FROM MASTER CYLINDER TO FRONT LEFT BRAKE HOSE, 000 193701 003 097469 086 006508 093 007717 102,103 209243 183 013349 190 020074 193 000014 200 006559 283 001514 INAPPLICABLE TO ANTI-LOCK BRAKING SYSTEM (ABS)
8
LINE , Replaced By: A1234207028
8
LINE , 000 193700 003 097468 086 006507 093 007716 102,103 209242 183 013348 190 020073 193 000013 200 006558 283 001513, Replaced By: A1234203828, +001A1234203928
14
LINE , Replaced By: A1234205828
14
LINE FROM SPRING LOAD ACCUMULATOR TO RIGHT DISTRIBUTOR
20
LINE FROM MASTER CYLINDER TO ADAPTER FITTING, 000 193701 003 097469 086 006508 093 007717 102,103 209243 183 013349 190 020074 193 000014 200 006559 283 001514 INAPPLICABLE TO ANTI-LOCK BRAKING SYSTEM (ABS)
20
LINE , Replaced By: A1234207228
23
ADAPTER FITTING BETWEEN THE LINES
26
LINE FROM ADAPTER FITTING TO DISTRIBUTOR,126.021 005796, 126.022,023 020032, 126.032,033 008371, 126.036,037 007212
26
LINE FROM ADAPTER FITTING TO DISTRIBUTOR
29
LINE , Replaced By: A1234205628
29
LINE FROM DISTRIBUTOR TO REAR LEFT BRAKE HOSE
32
LINE FROM DISTRIBUTOR TO REAR RIGHT BRAKE HOSE
32
LINE , Replaced By: A1234206428
35
DISTRIBUTOR
38
SHEET METAL SCREW , NOT USED
41
BRAKE HOSE FRONT, 000 158335 003 079228 007 064176 083 004326 086 003285 093 004195 EXCEPT FOR 002924,002958,002959,002981,003004,003013,003017,003025,003114,003171,003282-003298,003300-003332. 102,103 150314 105 165147 183 007370 EXCEPT FOR 003196,003355,003552,003818,003865,004180,004186-004202,004204,004207-004220,004222-004375. 190 011092 EXCEPT FOR 006378,006494,006605,006668,006953,007353-007383,007386-007421.
41
BRAKE HOSE , 000 158336 003 079229 007 064177 083 004327 086 003286 093 004196 ALSO INSTALLED ON 002924,002958,002959,002981,003004,003013,003017,003025,003114,003171,003282-003298,003300-003332. 102,103 150315 105 165148 183 007371 ALSO INSTALLED ON 003196,003355,003552,003818,003865,004180,004186-004202,004204,004207-004220,004222-004375. 190 011093 ALSO INSTALLED ON 006378,006494,006605,006668,006953,007353-007383,007386-007421.
41
BRAKE HOSE , Replaced By: A1294280035
44
BRAKE HOSE
44
BRAKE HOSE , Replaced By: A1264280335
47
RETAINING SPRING BRAKE HOSE TO BRACKET
53
DAMPING STRIP BRAKE LINE TO FIRE WALL, 000 130186 003 066451 007 053318 083 002304 086 001762 093 001874 102,103 113215 105 135079 183 004049 190 005029
53
RUBBER PAD , 000 130185 003 066450 007 053317 083 002303 086 001761 093 001873 102,103 113214 105 135078 183 004048 190 005028, Replaced By: A1234280085, +001A1239950222
59
CLAMP , Replaced By: A1119950042
59
CLAMP BRAKE LINE TO FIRE WALL, 000 130186 003 066451 007 053318 083 002304 086 001762 093 001874 102,103 113215 105 135079 183 004049 190 005029
62
SHEET METAL SCREW BRACKET TO CAB FLOOR, EXHAUST STOCK OF OLD PARTS NUMBER FIRST UP TO CHASSIS 5 180559
65
GROMMET , UP TO CHASSIS123.A 182585 F 027779 126.A 087563
