Поз.
Артикул
Описание
20
SHOCK ABSORBER , USED WITHOUT H.D. SPRINGS FASTENING PARTS NOT PART OF DELIVERY SPEC., PLEASE ORDER SEPARATELY
20
DAMPER STRUT , Replaced By: A1243205830
20
DAMPER STRUT , Replaced By: A1243204430, +002A1249900299
23
RUBBER BUFFER STOP BUFFER, A 862989
26
BOOT
29
RETAINING STRAP
38
SCREW DAMPER STRUT TO STEERING KNUCKLE, BOTTOM
41
WASHER DAMPER STRUT TO STEERING KNUCKLE
44
NUT STEERING SUPPORT TO FRAME,D 523394
50
SCREW DAMPER STRUT TO STEERING KNUCKLE,TOP
56
WASHER DAMPER STRUT TO STEERING KNUCKLE
62
NUT STEERING SUPPORT TO FRAME,D 523394
68
RUBBER MOUNTING FRONT DAMPER STRUT TO FRAME, A 650726
71
WASHER , Replaced By: N000125008443
74
NUT , Replaced By: N913004008001
80
STOP (REBOUND STOP)
86
WASHER DAMPER STRUT TO STEERING KNUCKLE
89
NUT BRACKET TO SIDE MEMBER
95
MOUNTING PARTS KIT DAMPER STRUT MOUNTING,FRONT, A 922700
95
REPAIR KIT , Replaced By: A1249900299
98
BRACKET ELECTRIC CABLE TO LEFT SHOCK ABSORBER LEG BRACKET
98
BRACKET ELECTRIC CABLE TO RIGHT SHOCK ABSORBER LEG BRACKET
101
WASHER COMPRESSED AIR LINE TO BRACKET, Replaced By: N000125006449
101
SCREW
101
WASHER COMPRESSED AIR LINE TO BRACKET
