Поз.
Артикул
Описание
5
CABLE HARNESS BURGLARY ALARM SYSTEM
5
CABLE HARNESS BURGLARY ALARM SYSTEM AND INFRARED CLOSING SYSTEM, USED WITHOUT IMMOBILISERF 290566
5
CABLE HARNESS ANTITHEFT WARNING SYSTEM AND ANTI-TOW-AWAY SYSTEM, ONLY USED WITH IMMOBILISER
5
CABLE HARNESS USED WITH INFRA-RED CLOSING SYSTEM, ONLY USED WITH IMMOBILISER
5
CABLE HARNESS USED WITH INFRA-RED CLOSING SYSTEM
5
CABLE HARNESS ANTITHEFT WARNING SYSTEM AND ANTI-TOW-AWAY SYSTEM, USED WITHOUT IMMOBILISER
5
CABLE HARNESS BURGLARY ALARM SYSTEM AND INFRARED CLOSING SYSTEM,F 290565
8
PIN BUSHING HOUSING CONTROL UNIT, 14-POLE
9
COVERTO 019 545 29 28
12
PIN BUSHING HOUSING SENSOR
13
COVERTO 009 545 16 28
16
PIN BUSHING HOUSING OUTBOARD TEMPERATURE INDICATOR
17
ROUND PIN BUSHING2.5 MM2
20
PIN BUSHING HOUSING CONTROL UNIT OF COMFORT CONTROL
23
PIN BUSHING HOUSING SOLENOID VALVE,F 051968
24
PIN BUSHING HOUSING TELL-TALE LAMP ASD
25
ROUND PIN BUSHING LIGHT SWITCH 2,5 MM
27
PLUG ADAPTERTO 014 545 04 28
28
PLUG ADAPTER. PLUG HEATING WATER VALVE, 4-POLE
29
PIN BUSHINGTO 000 821 19 26
32
PLUG HOUSING UNIPOLAR
33
FLAT PIN BUSHINGTO 002 545 92 26,1.5-2.5 MM 2
33
FLAT PIN BUSHING0.5-1.0 MM2
36
INSULATING SLEEVE. PLUG HOUSING DOOR CONTACT SWITCH
37
PLUGTO 000 546 12 45
38
PIN BUSHING HOUSING UNIPOLAR, HEAT SENSOR CONNECTION
39
PLUG TEST PLUG
40
PLUG TEST PLUG
41
CABLE HARNESS REAR END, USED WITH INFRARED REMOTE CONTROL
41
CABLE HARNESS REAR END
42
PLUG PIN
43
PLUG HOUSINGTO 124 540 97 13
44
CABLE HARNESS DECLUTCHING START UNIT
44
CABLE HARNESS DECLUTCHING START UNIT
49
CLIP BELT LOCK TO SEAT RAIL
55
SCREW ELECTRIC CABLE TO HORN
58
LOCK WASHER T-FITTING TO BRACKET
61
CLAMP ELECTRIC CABLE TO DOOR INTERIOR PLATE
64
GROMMET ELECTRIC CABLE THRU FIRE WALL
67
SWITCH DOOR CONTACT
70
BRACKET ENGINE HOOD CONTACT TO FRONT WHEELHOUSE
73
CONTROL UNIT USED WITHOUT INFRA-RED CLOSING SYSTEM,01.10.92 (B 20537)
73
CONTROL UNIT USED WITHOUT INFRA-RED CLOSING SYSTEM, INAPPLICABLE TO SWITZERLANDF 245489
73
CONTROL UNIT USED WITH INFRA-RED CLOSING SYSTEM, INAPPLICABLE TO SWITZERLAND
73
CONTROL UNIT USED WITH INFRA-RED CLOSING SYSTEM
79
BRACKET CABLE CONNECTOR TO LEFT AND RIGHT FRONT DOORS
79
BRACKET RIGHT DOOR LOCK, 126.021 024131 EXCEPT FOR 024568-024856126.022,023 082491 EXCEPT FOR 085384-086403126.032,033 042922 EXCEPT FOR 043448-043816126.036,037 031318 EXCEPT FOR 032054-032495126.120 042493 EXCEPT FOR 043412-044100
82
HORN
85
NUT BRACKET TO PARTITION PANEL,1.9.89 B 065822 F 122353
88
SCREW ELECTRIC CABLE TO HORN
94
SHEET METAL SCREW
97
BRACKET SWITCH TO REAR PANEL DOOR
106
CONTROL UNIT ASS TOWING PROTECTION
109
SCREW PROTECTIVE PLATE, FROM IDENT NO. 5 419107-5 757662 ALS INSTALLED ON 5 800000-5 806588
