Поз.
Артикул
Описание
7
PLASTIC PIPE FUEL LINE 12X1,5 MM, ORDER BY THE METER
7
HOSE , Replaced By: A0009872827
11
FITTING (PARTS KIT),LINE RUPTURE
11
FITTING , Replaced By: A0029906171
15
BANJO UNION HOSE WIDTH, / I.D., 9/16 MM
15
BANJO UNION , Replaced By: N915052009009
19
PLASTIC PIPE. HOSE AERATION 6X8 MM, ORDER BY THE METER
23
FITTING , Replaced By: A0029905971
23
FITTING (PARTS KIT),LINE RUPTURE
27
BANJO UNION HOSE WIDTH, / I.D., 6/16 MM
27
BANJO UNION HOSE WIDTH, / I.D., 6/12 MM
31
FITTING REAR AXLE REGULATING SOLENOID VALVE, CONNECTIONS: "10"
35
THRUST RING , THE OLD PART MUST NO LONGER BE INSTALLED, Replaced By: A0009940203
35
THRUST RING CHECK VALVE TO AIR RESERVOIR
39
O-RING CHECK VALVE TO AIR RESERVOIR
43
HOLLOW SCREW FRONT AXLE REGULATING SOLENOID VALVE, CONNECTION: "10",K 009079
47
SEALING RING. SEAL RING DELIVERY LINE TO STEERING
51
RESERVOIR10 L, 206 MM,5 934168
51
RESERVOIR E P S AND CLUTCH BOOSTER 10 L, Replaced By: A0034320801
51
RESERVOIR , Replaced By: A0034324801
51
RESERVOIR ,5 934167, Replaced By: A0034324701
51
RESERVOIR10L,206 MM,8.5 BAR
55
BRACKET CLUTCH BOOSTER AIR RESERVOIR
59
SUPPORT AIR RESERVOIR TO FRAME
63
SCREW. HEXAGON HEAD BOLT VALVE TO BRACKET
63
SCREW , Replaced By: N308676012012
67
NUT SUPPORT TO SIDE MEMBER
71
PAD , Replaced By: A3879870070
71
ADHESIVE TAPE60 MM, ORDER BY THE METER
71
RUBBER SECTION , Replaced By: A6559890285
75
STRAP CLUTCH BOOSTER AIR RESERVOIR 520 MM
75
STRAP AIR RESERVOIR TO BRACKET
79
NUT BRACKET TO SUPPORT AND TO END PIECE
83
FITTING AIR RESERVOIR,CONNECTION: "13"
87
FITTING REAR AXLE REGULATING SOLENOID VALVE, CONNECTIONS: "10"
91
SCREW PLUG LOAD/NO-LOAD VALVE,CONNECTION: "21"
91
SCREW PLUG , Replaced By: N000908022011
95
VALVE DRAIN, Replaced By: A0004322107
95
VALVE DRAIN, Replaced By: A0004322407
95
VALVE. DRAIN VALVE DRAIN
99
THRUST RING CHECK VALVE TO AIR RESERVOIR
99
THRUST RING , THE OLD PART MUST NO LONGER BE INSTALLED, Replaced By: A0009940203
103
O-RING CHECK VALVE TO AIR RESERVOIR
107
NON-RETURN VALVE. VALVE WITH CHECK VALVE WABCO,5 433388
111
VALVE SEAT RINGWABCO,5 433388
115
BUSHINGWABCO,5 433388
119
LOCK RINGWABCO,5 433388
123
FITTING REAR AXLE REGULATING SOLENOID VALVE, CONNECTIONS: "10"
127
THRUST RING , THE OLD PART MUST NO LONGER BE INSTALLED, Replaced By: A0009940203
127
THRUST RING CHECK VALVE TO AIR RESERVOIR
131
O-RING CHECK VALVE TO AIR RESERVOIR
135
HOLLOW SCREW FRONT AXLE REGULATING SOLENOID VALVE, CONNECTION: "10",K 009079
139
SEALING RING. SEAL RING DELIVERY LINE TO STEERING
