Поз.
Артикул
Описание
5
RESERVOIR RESERVOIR, 415 5 014669 416 5 000516 417 4 972024
8
LOCKING CAP
11
SEAL RING
14
STRAINER
17
CAP RESERVOIR DE-AERATION
20
BRACKET RESERVOIR
23
SHEET METAL SCREW COVER PLATE TO CAB REAR PANEL
26
SCREW OIL DELIVERY LINE TO BRACKET
29
LOCK WASHER CONTROL LEVER TO INJECTION PUMP LEVER
32
WASHER , Replaced By: N009021006208
35
HOSE FROM RESERVOIR TO MASTER CYLINDER, ORDER BY THE METER
38
GROMMET CLUTCH LINE THRU CAB WINDOW SILL,4 797365
77
LINE FROM CLUTCH MASTER CYLINDER TO SHUTTLE VALVE 700 MM
80
GROMMET TEMPERATURE GAUGE SENDER UNIT
83
BRACKET BRACKET TO ENGINE,REAR
86
CLAMP , Replaced By: A3604300143
86
CLAMP , Replaced By: N916016008200
86
CLAMP ,K 147121, Replaced By: N000000000319
89
SCREW LONGITUDINAL DIFFERENTIAL LOCK VALVE TO BRACKET,5 963747
92
NUT LONGITUDINAL DIFFERENTIAL LOCK BRACKET,5 963747
95
BRACKET HYDRAULIC LINE TO CAB FLOOR
98
SCREW , Replaced By: N304017006016
101
LOCK WASHER CONTROL LEVER TO INJECTION PUMP LEVER
104
HOSE FROM BRACKET UNDER CAB FLOOR TO OIL TANK BRACKET 555 MM
107
BRACKET AT OIL TANK BRACKET
110
SCREW , Replaced By: N304017006016
113
NUT , Replaced By: N913004006001
116
LINE FROM FAN SHROUD BRACKET TO FITTING 2500 MM
119
BRACKET HYDRAULIC LINE TO SIDE MEMBER,OUTSIDE CENTRAL,5 178595
122
SCREW HYDRAULIC CYLINDER TO BEARING BRACKET M 12X22
125
NUT FRONT SPRING FRONT BRACKET TO SIDE MEMBER
128
CLAMP ,K 147121, Replaced By: N000000000319
128
CLAMP , Replaced By: A3604300143
128
CLAMP , Replaced By: N916016008200
131
SPACER TUBE , Replaced By: A4082910153
134
SCREW , Replaced By: N304017006016
137
NUT LONGITUDINAL DIFFERENTIAL LOCK BRACKET,5 963747
143
ANGLE LINE MOUNTING
146
CLAMP , Replaced By: A3604300143
146
CLAMP , Replaced By: N916016008200
146
CLAMP ,K 147121, Replaced By: N000000000319
149
SCREW , Replaced By: N304017006016
152
NUT LONGITUDINAL DIFFERENTIAL LOCK BRACKET,5 963747
158
161
SCREW BRACKET TO SIDE MEMBER
164
NUT , Replaced By: N910113014001
170
HOSE FROM REAR ENGINE-MOUNTING BRACKET TO TRANSMISSION BRACKET 350 MM
173
BRACKET HYDRAULIC LINE TO TRANSMISSION
176
LINE FROM VALVE TO CONNECTION FITTING 1500 MM, TO BE ADAPTED DURING ASSEMBLY
176
LINE HYDRAULIC HOSE TOWARDS CLUTCH BOOSTER 800 MM,5 401291 TO BE ADAPTED DURING ASSEMBLY
176
179
MOUNTING PLATE FROM EXPANSION TANK TO RADIATOR
179
BRACKET. LOCK , Replaced By: A6525040038
999
REPAIR KIT CLUTCH SLAVE CYLINDER TO 001 295 91 07,96 07,384 295 72 07
