Поз.
Артикул
Описание
5
BRAKE VALVE SERVICE BRAKE KNORR
5
BRAKE VALVE SERVICE BRAKE WABCO
8
LOCKTO 345 431 70 05
8
LOCK RINGTO 345 431 71 05
11
SPRINGTO 345 431 70 05
11
SPRINGTO 345 431 70 05
11
SPRINGTO 345 431 71 05
14
PISTONTO 345 431 70 05
14
PISTONTO 345 431 71 05
17
LOCK RINGTO 345 431 71 05
20
LOCK RING
23
LOCK RING PLANETARY CARRIER
26
REPAIR KIT SMALL SCOPE TO 345 431 70 05
26
REPAIR KIT SMALL SCOPE TO 345 431 71 05
26
REPAIR KIT LARGE SCOPE TO 345 431 70 05
26
REPAIR KIT , Replaced By: A0014300460
29
GASKET BRAKE SHOE WITH LINING
32
NUT BATTERY CASE
35
SPRING WASHER BRAKE SHOE WITH LINING
72
ROD FROM FITTING TO CLUTCH BOOSTER
74
YOKE
77
HEXAGON NUT. NUT BRACKET TO SIDE MEMBER M 12X1,5
80
HOLLOW SCREW FRONT AXLE REGULATING SOLENOID VALVE, CONNECTION: "10",K 009079
86
HOLLOW SCREW FITTING LEFT AND RIGHT COMBINATION CYLINDERS, CONNECTION: "11,12",5 356525
92
SCREW PLUG
92
SCREW PLUG RELAY VALVE,CONNECTION "20",RIGHT
95
SEAL RING LOAD/NO-LOAD VALVE,CONNECTION: "20"
132
SCREW BRACKET TO SIDE MEMBER M10X30
133
NUT BRACKET TO SIDE MEMBER,XB209706
999
ROD , Replaced By: A3842927032, +001A3849967001, +001N000934012009
999
ROD , Replaced By: A3844207074
