Поз.
Артикул
Описание
1
FUEL TANK
6
GASKET
7
SPRING WASHER ALTERNATOR CONNECTION D+
8
NUT TACHOGRAPH TO BRACKET
12
REINFORCEMENT
13
REINFORCEMENT
15
HOSE
20
GAUGE SENDER UNIT
21
FUEL STRAINER
23
SEAL RING
30
HOSE DE-AERATION B8X12,5 218304 ORDER BY THE METER
33
WASHER PROTECTIVE PLATE TO BRACKET,5 502998
35
NUT SWITCH TO FLOOR PLATE
43
LOCKING CAP
44
FILLER CAP , Replaced By: A0004700730
50
SEAL RING
65
LINE FEED, FRONT, UP TO CHASSIS: 005,007,008,015,017 150223 011 021485 060 016385 062 013292
80
LINE FEED,REAR
85
LINE RETURN, FRONT
86
LINE RETURN, REAR
100
HOSE DE-AERATION B8X12,5 218304 ORDER BY THE METER
106
SCREW LINES UNDER FUEL TANK
107
DAMPING STRIP
108
RUBBER SECTION20 MM, ORDER BY THE METER
112
RUBBER RING SIGNAL LAMP TO ROOF
113
CLAMP , 116.020 071390 ALSO INSTALLED ON 071392,071396,071400,071402,071416. 116.024,025 068051 ALSO INSTALLED ON 068099,068265 EXCEPT FOR 055714,055888,057629,058694,066624,066628,066632,066803,067088,067089,067410,067542,067578-067580, 067860-067862,067865,067924,067928-067943,067945,067948,067952,067953,067955-067969,067971-068001, 068005,068007-068019,068024,068026-068029,068031-068033,068035-068048,068050.
115
NUT BATTERY MOUNTING
115
NUT CYLINDER TO BRACKET TO0002902112
120
RUBBER SECTION20 MM, ORDER BY THE METER
121
RUBBER SECTION15MM, ORDER BY THE METER
152
GROMMET
153
HOSE4.5X10X900MM
154
CLIP
156
BOOT
157
CLIP (HOSE LINE TO BRAKE BOOSTER)
160
VALVE , 100.012,014,016 001960 108.018 077634 114.011 006504 114.023 003979 115.010 076258, Replaced By: A1074700493, +002A1074711615, +002A1144710223, +001A1144710341, +001A0009870044, +002A0199977582, +004A0019976990, +005N007976004211
165
VALVE
166
FILTER , 100.012,014,016 001961 108.018 077635 114.011 006505 114.023 003980 115.010 076259
167
COVER , 100.012,014,016 001961 108.018 077635 114.011 006505 114.023 003980 115.010 076259
168
BRACKET , 100.012,014,016 001961 108.018 077635 114.011 006505 114.023 003980 115.010 076259
169
SHEET METAL SCREW , 100.012,014,016 001961 108.018 077635 114.011 006505 114.023 003980 115.010 076259
172
EXPANSION PLUG , 100.012,014,016 001961 108.018 077635 114.011 006505 114.023 003980 115.010 076259
175
PLASTIC PIPE AERATION, ORDER BY THE METER
175
PLASTIC PIPE. HOSE AERATION 6X8 MM, ORDER BY THE METER
176
LINE
177
HOSE DE-AERATION B8X12,5 218304 ORDER BY THE METER
178
PLASTIC PIPE AERATION, ORDER BY THE METER
178
PLASTIC PIPE. HOSE AERATION 6X8 MM, ORDER BY THE METER
179
LINE
180
HOSE DE-AERATION B8X12,5 218304 ORDER BY THE METER
184
PLASTIC PIPE AERATION, ORDER BY THE METER
184
PLASTIC PIPE. HOSE AERATION 6X8 MM, ORDER BY THE METER
186
LINE
190
HOSE DE-AERATION B8X12,5 218304 ORDER BY THE METER
195
DAMPING STRIP , 107.022 005201 ALSO INSTALLED ON 005190-005192,005194-005199. 107.023 012497 107.024 021804 ALSO INSTALLED ON 021794,021804
196
HOSE HAND BRAKE VALVE BLEEDING, ORDER BY THE METER
200
DAMPING STRIP
200
RUBBER PAD , Replaced By: A1104760084
201
CLAMP
202
CLAMP , FROM CHASSIS: 010 115422 110 307703 017,117 000001
203
CLAMP PLASTIC LINE ON CONTROL LINE
205
GROMMET
999
CLAMP
999
CLAMP HOSE TO PARKING BRAKE VALVE
999
CLAMP , THIS NOTE OF REPLACEMENT APPLIES ONLY TO THE ITEM LISTED OPPOSITE, Replaced By: A0059972790
999
LOCK WASHER CONTROL LEVER TO INJECTION PUMP LEVER
999
CLAMP TO CONNECT THE FUEL LINES, 740810
999
CLAMP , 018 FROM CHASSIS 030632, 019 FROM CHASSIS 030489
999
CLAMP FUEL HOSE TO FUEL LINE, FROM ENGINE 063637 UP TO CHASSIS 303382
999
CLAMP
999
SHEET METAL SCREW VALVE TO WINDOW SILL
999
SHEET METAL SCREW BRACKET TO CAB FLOOR, EXHAUST STOCK OF OLD PARTS NUMBER FIRST UP TO CHASSIS 5 180559
999
HOSE , Replaced By: A1149971882
999
CLAMP FORKED SUPPORT,TOP
999
CLIP , UP TO CHASSIS: 005,017 011937 015 217835 105,107,108,117,119 022526 110 415753 115 221429
999
HOSE CLAMP HOSE FASTENING 9/13MM
999
GROMMET ,D 314239
999
CLIP CABLE HARNESS TO ROOF RAIL
