Поз.
Артикул
Описание
10
REVERSE IDLER SHAFT , FROM TRANSMISSION: 023 496842 UP TO TRANSMISSION: 023 766040 UP TO CHASSIS: 009860
15
COUNTERSHAFT , FROM TRANSMISSION: 023 669558 UP TO TRANSMISSION: 023 766040 UP TO CHASSIS: 009860
16
KEY , UP TO CHASSIS 017058 UP TO TRANSMISSION 766040
19
SPACER WASHER , UP TO CHASSIS 017058 UP TO TRANSMISSION 766040
20
CYLINDR. ROLLER BEARING , UP TO CHASSIS 017058 UP TO TRANSMISSION 766040
20
BALL BEARING , Replaced By: A0049814201
23
NUT , UP TO CHASSIS 017058 UP TO TRANSMISSION 766040
27
OIL RING , UP TO CHASSIS 017058 UP TO TRANSMISSION 766040
29
CYLINDR. ROLLER BEARING , UP TO CHASSIS 017058 UP TO TRANSMISSION 766040
29
BALL BEARING , Replaced By: A0049814201
33
SNAP RING , UP TO CHASSIS 017058 UP TO TRANSMISSION 766040
35
SPACER RING , UP TO CHASSIS 017058 UP TO TRANSMISSION 766040
37
SNAP RING AS REQUIRED 1.9 MM
40
SPACER WASHER AS REQUIRED 0.1 MM
44
MAIN SHAFT , UP TO CHASSIS 017058 UP TO TRANSMISSION 766040
46
GEAR (GEAR SET),3RD SPEED, UP TO CHASSIS 017058 UP TO TRANSMISSION 766040
48
NEEDLE BEARING , UP TO CHASSIS 017058 UP TO TRANSMISSION 766040
50
SYNCHRONIZER RING 5TH SPEED
52
THRUST WASHER , UP TO TRANSMISSION: 023 766040 UP TO CHASSIS: 009860
53
SYNCHRONIZER BODY 3RD AND 4TH SPEED
55
SYNCHRONIZER BODY , UP TO TRANSMISSION: 023 766040 UP TO CHASSIS: 009860
59
BALL HOUSING,FRONT
60
FOLLOWER
61
SPRING , UP TO TRANSMISSION: 023 766040 UP TO CHASSIS: 009860
62
SLIDING COLLAR , UP TO TRANSMISSION: 023 766040 UP TO CHASSIS: 009860
63
NEEDLE BEARING
65
NUT
67
NEEDLE BEARING , UP TO CHASSIS 017058 UP TO TRANSMISSION 766040
70
GEAR
73
SYNCHRONIZER RING
74
THRUST WASHER 4.0 MM
76
SYNCHRONIZER BODY
78
SYNCHRONIZER BODY , NO LONGER AVAILABLE
81
BALL HOUSING,FRONT
82
FOLLOWER , UP TO CHASSIS 017058 UP TO TRANSMISSION 766040
84
SLIDING COLLAR , NO LONGER AVAILABLE
85
SPRING
86
GEAR , 669557
89
THRUST WASHER AS REQUIRED 3.8 MM, FROM TRANSMISSION 005986-766040
91
SPACER RING
92
NEEDLE BEARING , UP TO CHASSIS 017058 UP TO TRANSMISSION 766040
94
BALL BEARING
96
REVERSE IDLER GEAR , FROM TRANSMISSION: 023 669558 UP TO TRANSMISSION: 023 766040 UP TO CHASSIS: 009860
97
SNAP RING AS REQUIRED 1.9 MM
99
SPACER WASHER AS REQUIRED 0.1 MM
102
RETAINING RING
103
SPRING WASHER
104
SCREW
107
CYLINDR. ROLLER BEARING , UP TO CHASSIS 017058 UP TO TRANSMISSION 766040
107
BALL BEARING , Replaced By: A0049814201
111
GEAR , UP TO CHASSIS 017058 UP TO TRANSMISSION 766040
115
DRIVE GEAR
115
GEAR
116
BUSHING , UP TO CHASSIS 017058 UP TO TRANSMISSION 766040
117
SHIFTING ROD , UP TO CHASSIS 017058 UP TO TRANSMISSION 766040
118
FOLLOWER , UP TO CHASSIS 017058 UP TO TRANSMISSION 766040
119
CLAMPING SLEEVE , UP TO CHASSIS 017058 UP TO TRANSMISSION 766040
999
NUT
999
SEAL RING SOLENOID VALVE A 18X24
999
CLAMPING SLEEVE ,002440
999
NUT TACHOGRAPH TO BRACKET
999
SPACER WASHER 0.50 MM
999
SPACER WASHER 0.25 MM
999
SNAP RING 2.05 MM
999
SNAP RING , Replaced By: A1369940935
999
SPACER WASHER 0.3 MM
999
SPACER WASHER 0.2 MM
999
BOOT
999
SNAP RING AS REQUIRED 2.1 MM, UP TO CHASSIS: 000,002,010 111709 015 143890 100,102,103,110,112 295608 115 151032 FROM CHASSIS SEE UNIT MICROFISCHE,359
999
SNAP RING AS REQUIRED 2.18 MM, UP TO CHASSIS: 000,002,010 111709 015 143890 100,102,103,110,112 295608 115 151032 FROM CHASSIS SEE UNIT MICROFISCHE,359
999
BUSHING GEAR SELECTOR LEVER
999
BUSHING , 114.005,007,015 037181 114.010 033492 114.021 001931 114.022 002382 115.000,002,010 037475 115.015 035971 115.100,102,110 085311 115.115 039087
999
NUT , UP TO CHASSIS 017058 UP TO TRANSMISSION 766040
999
SCREW , 003878
999
NUT , UP TO CHASSIS: 007,008,015,017 219402 011 104137 060 107833 062 104360
999
SEAL RING , Replaced By: A0119976447
999
KNOB
999
BUSHING , FROM CHASSIS: 000,002,010 056142 015 060262 100,102,103,110,112 139361 115 065086 UP TO CHASSIS: 000,002,010 095001 015 115530 100,102,103,110,112 244262 115 122227
999
KNOB , FROM CHASSIS: 000,002,010 007281 015 004404 100,102,103,110,112 017471 115 007979 UP TO CHASSIS: LESS POWER STEERING 000,002,010 12/52 086674 015 12/52 101861 100,102,103,110,112 12/52 220489 115 12/52 109121 UP TO CHASSIS: WITH POWER STEERING 000,002,010 12/52 083150 015 12/52 097114 100,102,103,110,112 12/52 211905 115 12/52 104333 UP TO CHASSIS: LESS POWER STEERING 000,002,010 22/62 087646 015 22/62 103161 100,102,103,110,112 22/62 222275 115 22/62 110304 UP TO CHASSIS: WITH POWER STEERING 000,002,010 22/62 086763 015 22/62 101811 100,102,103,110,112 22/62 220494 115 22/62 109109
999
BUSHING , UP TO CHASSIS: 000,002,010 056141 015 060261 100,102,103,110,112 139360 115 065085 FROM CHASSIS: 000,002,010 095002 015 115531 100,102,103,110,112 244263 115 122228
999
BUSHING , 003 110321 007 099338 086 007514 093 011074 105 267871 190 025455
999
COUNTERSHAFT , 669557
999
REVERSE IDLER GEAR , 669557
999
REVERSE IDLER SHAFT , 496841
999
SYNCHRONIZER RING 3RD AND 4TH SPEED, UP TO CHASSIS: 000,002,010 111709 015 143890 100,102,103,110,112 295608 115 151032 FROM CHASSIS SEE UNIT MICROFISCHE,359
999
SYNCHRONIZER RING 1ST AND 2ND SPEED, UP TO CHASSIS: 000,002,010 111709 015 143890 100,102,103,110,112 295608 115 151032 FROM CHASSIS SEE UNIT MICROFISCHE,359
999
THRUST WASHER AS REQUIRED 4.2 MM, FROM TRANSMISSION: 000,002,010,015 005986 100,102,103,110,112,115 000037 UP TO CHASSIS: 000,002,010 111709 015 143890 100,102,103,110,112 295608 115 151032 FROM CHASSIS SEE UNIT MICROFISCHE,359
999
THRUST WASHER AS REQUIRED 4.1 MM, FROM TRANSMISSION: 000,002,010,015 005986 100,102,103,110,112,115 000037 UP TO CHASSIS: 000,002,010 111709 015 143890 100,102,103,110,112 295608 115 151032 FROM CHASSIS SEE UNIT MICROFISCHE,359
999
THRUST WASHER AS REQUIRED 4.0 MM, FROM TRANSMISSION: 000,002,010,015 005986 100,102,103,110,112,115 000037 UP TO CHASSIS: 000,002,010 111709 015 143890 100,102,103,110,112 295608 115 151032 FROM CHASSIS SEE UNIT MICROFISCHE,359
999
THRUST WASHER AS REQUIRED 3.9 MM, FROM TRANSMISSION: 000,002,010,015 005986 100,102,103,110,112,115 000037 UP TO CHASSIS: 000,002,010 111709 015 143890 100,102,103,110,112 295608 115 151032 FROM CHASSIS SEE UNIT MICROFISCHE,359
999
GEAR 1ST SPEED, FROM CHASSIS: 000,002,010 098306 115.015 121866 100,102,103,110,112 255529 115 128219 UP TO CHASSIS: 000,002,010 111709 015 143890 100,102,103,110,112 295608 115 151032 FROM CHASSIS SEE UNIT MICROFISCHE,359
999
GEAR , Replaced By: A1152621611, +001A1152623662
999
GASKET
999
GASKET , UP TO CHASSIS: 000,002,010 111709 015 143890 100,102,103,110,112 295608 115 151032 FROM CHASSIS SEE UNIT MICROFISCHE,359 INCLUDED IN REPAIR KIT 115 586 00 26
999
SHIFTING TUBE , FROM CHASSIS: 000,002,010 053750 015 057120 100,102,103,110,112 132391 115 061803 005,017,105,107,108,117,119 000001
999
SHIFTING TUBE , UP TP CHASSIS: 000,002,010 053749 015 057119 100,102,103,110,112 132390 115 061802, Replaced By: A1152606682, +001A1099900238, +001N000934005004
999
TRANSMISSION , UP TO CHASSIS: 000,002,010 111709 015 143890 100,102,103,110,112 295608 115 151032 FROM CHASSIS SEE UNIT MICROFISCHE,359 PART IS ONLY OR ALSO SUPPLIED AS RECONDITIONED PART
999
TRANSMISSION CASE COVER
999
SUPPORT FRONT
999
SHIFT LEVER , FROM CHASSIS: 000,002,010 095002 015 115531 100,102,103,110,112 244263 115 122228 UP TO CHASSIS: 000,002,010 117631 015 154063 100,102,103,110,112 315098 115 161611, Replaced By: A1152604439, +001A1152670114, +001A1152680172
999
TRANSMISSION CASE COVER , Replaced By: A1152603713, +001A1152603873
999
SYNCHRONIZER BODY , UP TO CHASSIS: 000,002,010 111709 015 143890 100,102,103,110,112 295608 115 151032 FROM CHASSIS SEE UNIT MICROFISCHE,359, Replaced By: A1152604345, +002A1152622934
999
DETENT , Replaced By: A1152603873, +001A0049815510
999
SYNCHRONIZER BODY , UP TO CHASSIS: 000,002,010 111709 015 143890 100,102,103,110,112 295608 115 151032 FROM CHASSIS SEE UNIT MICROFISCHE,359, Replaced By: A1152604445, +002A1152623034
999
SHIFT LEVER , FROM CHASSIS: LESS POWER STEERING 000,002,010 10/50 085059 015 10/50 099480 100,102,103,110,112 10/50 216012 115 10/50 106668 FROM CHASSIS: WITH POWER STEERING 000,002,010 10/50 086622 015 10/50 101629 100,102,103,110,112 10/50 220100 115 10/50 108872 FROM CHASSIS: LESS POWER STEERING 000,002,010 12/52 086675 015 12/52 101862 100,102,103,110,112 12/52 220490 115 12/52 109122 FROM CHASSIS: WITH POWER STEERING 000,002,010 12/52 083151 015 12/52 097115 100,102,103,110,112 12/52 211906 115 12/52 104334 UP TO CHASSIS: 000,002,010 095001 015 115530 100,102,103,110,112 244262 115 122227, Replaced By: A1152604439, +001A1152680550, +001A1152680172, +001N007346005000
999
TRANSMISSION CASE COVER , UP TO CHASSIS: 000,002,010 111709 015 143890 100,102,103,110,112 295608 115 151032 FROM CHASSIS SEE UNIT MICROFISCHE,359, Replaced By: A1152604713, +001A1152603873, +001A1152610166, +001A1152610080
999
SHIFT LEVER , FROM CHASSIS: 000,002,010 056142 015 060262 100,102,103,110,112 139361 115 065086 UP TO CHASSIS: LESS POWER STEERING 000,002,010 12/52 086674 015 12/52 101861 100,102,103,110,112 12/52 220489 115 12/52 109121 UP TO CHASSIS: WITH POWER STEERING 000,002,010 12/52 083150 015 12/52 097114 100,102,103,110,112 12/52 211905 115 12/52 104333, Replaced By: A1152604439, +001A1152681442, +001A1152680172
999
GEAR (GEAR SET),CONSTANT, UP TO CHASSIS 017058 UP TO TRANSMISSION 766040
999
SHIFTING ROD , FROM CHASSIS: 015 200001 011,060 100001
999
SHIFTING ROD , 200000
999
SHIFT LEVER , FROM CHASSIS: 000,002,010 007281-056141 015 004404-060261 100,102,103,110,112 017471-139360 115 007979-065085, Replaced By: A1152604439, +001A1152670114, +001A1152680550, +001A1152680172, +001A1152691242, +001N007346005000
999
SEAL RING , UP TO CHASSIS: 000,002,010 111709 015 143890 100,102,103,110,112 295608 115 151032 FROM CHASSIS SEE UNIT MICROFISCHE,359
999
NEEDLE BEARING , Replaced By: A0059815610
999
NEEDLE BEARING , Replaced By: A0059815610
999
NEEDLE BEARING , UP TO CHASSIS: 000,002,010 111709 015 143890 100,102,103,110,112 295608 115 151032 FROM CHASSIS SEE UNIT MICROFISCHE,359 OPTIONAL WITH 004 981 05 10,003 981 03 10,003 981 08 10
999
NEEDLE BEARING , UP TO CHASSIS: 000,002,010 111709 015 143890 100,102,103,110,112 295608 115 151032 FROM CHASSIS SEE UNIT MICROFISCHE,359 OPTIONAL WITH 004 981 05 10,003 981 03 10,003 981 09 10
999
NEEDLE BEARING , UP TO CHASSIS: 000,002,010 111709 015 143890 100,102,103,110,112 295608 115 151032 FROM CHASSIS SEE UNIT MICROFISCHE,359 OPTIONAL WITH 004 981 05 10,003 981 08 10,003 981 09 10
999
NEEDLE BEARING , UP TO CHASSIS: 000,002,010 111709 015 143890 100,102,103,110,112 295608 115 151032 FROM CHASSIS SEE UNIT MICROFISCHE,359
999
BALL BEARING , UP TO CHASSIS 017058 UP TO TRANSMISSION 766040
999
BALL SOCKET
999
SWITCH
