Поз.
Артикул
Описание
1
HEXALOBULAR BOLT. SCREW STAY TO CYLINDER HEAD M 6X23
2
WATER PUMP
3
CARRIER SEAL WATER PUMP
4
COLLAR SCREWTORX M8 X 45S - 8.8
5
HEXALOBULAR BOLT. SCREW STAY TO CYLINDER HEAD M 6X23
6
O-RING
7
WATER CONNECTION SOCKET , 20011212
8
BASIC CARRIER
9
BOLT TO PLUG COOLING-WATER BORE
9
WATER DRAIN PLUG CRANKCASE WATER DRAIN, FIRST EXHAUST STOCK OF OLD PARTS UP TO IDENT NO. 20020701, Replaced By: A1129900901
10
SCREW. HEXALOBULAR BOLT MOUNTING FRAME TO SUPPORT M 8X30
11
SEAL BASE CARRIER
12
CABLE TIE COOLING WATER HOSE TO ENGINE
13
WATER HOSE BETWEEN THERMOSTAT AND WATER PUMP
13
SHORT-CIRCUIT LEAD
14
THERMOSTAT
15
SENDER UNIT TEMPERATURE GAUGE SENDER UNIT, Replaced By: A0009050700
16
O-RING THERMOSTAT
17
CLIP TEMPERATURE GAUGE SENDER UNIT
18
HEXALOBULAR BOLT. SCREW STAY TO CYLINDER HEAD M 6X23
19
GASKET
20
HOSE AGB WATER PUMP
21
HOSE CLAMP COOLANT HOSE TO COOLANT LINE
22
CLIP CLIC E270 BEHR REAR MODULE
22
HOSE CLAMP BEHR CORE PRODUCTION
