Поз.
Артикул
Описание
5
RADIO SET ASSEMBLYALPINE, FROM MODEL YEAR '91
5
RADIO SET ASSEMBLY
5
RADIO SET ASSEMBLYALPINE, FROM MODEL YEAR `89 UP TO END OF MODEL YEAR '90
7
FUSE2 A
23
ELECTRIC CABLE RADIO CURRENT SUPPLY, UP TO END OF MODEL YEAR'85 FROM CHASSIS,SEE STANDARD MICROFICHE
27
ELECTRIC CABLE FRONT LOUDSPEAKER AND FADER CONTROL
43
LOUDSPEAKER FRONT LOUDSPEAKER
59
SHEET METAL SCREW MODULE TO HOUSING
59
SHEET METAL SCREW , Replaced By: N000000000453
67
ELECTRIC CABLE REAR END LOUDSPEAKER CONNECTION
83
LOUDSPEAKER FRONT LOUDSPEAKER
83
LOUDSPEAKER LOUDSPEAKER
95
SHACKLE LOUDSPEAKER WITH COVERING TO HAT TRAY
99
SHEET METAL SCREW PIN BUSHING HOUSING
99
SHEET METAL SCREW LOUDSPEAKER WITH COVERING TO HAT TRAY, 126.021 023660 126.022,023 082900 126.032,033 042271 126.036,037 030668 126.043 005732 126.044 005197 126.120 041479
131
SWITCH. FADER CONTROL
135
LOCK RADIO SET FIXTURE IN HOUSING, FROM CHASSIS 107.022 009534 107.025 001705 107.026 002281 107.042 009860 107.045 003233 107.046 000489
143
SCREW COVER PLATE TO COVER PLATE M 6 X 10
147
LOCK WASHER CONTROL LEVER TO INJECTION PUMP LEVER
155
COVERING REAR LOUDSPEAKER, NO.9051 INO.5076 INO.8316 INO.8326 INO.8336 INO.6086 INO.3076 INO.7101 INO.9051 INO.5076 INO.8316 I
162
CLAMP BOWDEN CABLE TO CAB
