Поз.
Артикул
Описание
78
ELECTRIC CABLE FROM SWITCH CLUSTER TO FRONT DOOR WINDOW REGULATOR MOTORS
78
ELECTRIC CABLE FROM SWITCH CLUSTER TO FRONT DOOR WINDOW REGULATOR MOTORS
150
PLUG. PIN BUSHING HOUSING ELECTRIC WINDOW REGULATOR SWITCH
156
PLUGTO 009 545 94 28
162
CONNECTOR SEAT HEATER SWITCH, 7-POLE, 107.042 011569 ALSO INSTALLED ON 010107,010328,010378,011305,011341,011348,011356,011418,011426,011434,011436,011444,011454,011455, 011464,011472,011473,011476,011480,011494,011496,011503,011504,011513,011514,011518,011519,011520, 011526,011528,011531,011533,011535,011537,011538,011539,011541-011567. 107.045 009132 ALSO INSTALLED ON 004581,007703,008068,008344,008400,008401,008455,008627,008724,008836,008842,008885,008911,008920, 008925,008958,008967,008989,008994,009001,009100,009128. 107.046 009987 ALSO INSTALLED ON 000518,000621,000841,000897,000899,000921,000933,000936,000938,000940,000942,000944,000956,000964, 000967,000970,000974-000985.
168
COVERTO 000 821 26 26
174
PIN BUSHING
180
ROUND PIN BUSHING4 MM2
306
BRACKET TRANSMISSION TUNNEL
312
RELAY , 123.003,028 105805 123.026 106004 123.030 032306 123.033 090757 123.053 023337 123.086 007202 123.093 009553 123.120 262872 123.102,103,125 255626 123.123 254722 123.105,132 240923 123.130 240457 123.183 016222 123.190 022642 123.200 040194 123.220 031448 123.223 040309 123.243 006912 123.280 001558 123.283 005502
312
RELAY , 107.042 011568 EXCEPT FOR 010107,010328,010378,011305,011341,011348,011356,011418,011426,011434,011436,011444,011454,011455, 011464,011472,011473,011476,011480,011494,011496,011503,011504,011513,011514,011518,011519,011520, 011526,011528,011531,011533,011535,011537,011538,011539,011541-011567. 107.045 009131 EXCEPT FOR 004581,007703,008068,008344,008400,008401,008455,008627,008724,008836,008842,008885,008911,008920, 008925,008958,008967,008989,008994,009001,009100,009128. 107.046 000986 EXCEPT FOR 000518,000621,000841,000897,000899,000921,000933,000936,000938,000940,000942,000944,000956,000964, 000967,000970,000974-000985.
318
FUSEA16
324
COMBINATION BOLT CABLE TO FUSE BOX
360
LOOM TIE , UP TO CHASSIS: 108.012 UNTIL PRODUCTION STOP 108.016 042417 108.018,019 043374 109.016 002452
402
CABLE CONNECTOR , FROM CHASSIS:108.016 050831 108.018 053598 108.019 054235
408
TAPPING SCREW
414
RIVET
420
SHEET METAL SCREW
426
SCREW STEERING COLUMN MOUNTED SWITCH TO STEERING COLUMN BRACKET M4X10
432
LOCK WASHER T-FITTING TO BRACKET
438
INSULATING HOSE BLACK 9X0.7 MM, ORDER BY THE METER
438
INSULATING HOSE PRESSURE REGULATOR,ANTI-FREEZE DEVICE, ORDER BY THE METER
