Поз.
Артикул
Описание
143
LINE FROM FEED PUMP TO FILTER, 616.912 10/50,20/60 063573 EXCEPT FOR 060283-060289,061120,061121,062724-062742,063163-063167,063273-063275,063425-063431,063561-063569. 616.912 12/52,22/62 021689 EXCEPT FOR 020732-020734,020893-020900,021578,021579,021583,021618,021619.
143
LINE FROM FEED PUMP TO FILTER, 616.912 10/50,20/60 063574 ALSO INSTALLED ON 060283-060289,061120,061121,062724-062742,063163-063167,063273-063275,063425-063431,063561-063569. 616.912 12/52,22/62 021690 ALSO INSTALLED ON 020732-020734,020893-020900,021578,021579,021583,021618,021619.
146
HOLLOW SCREW FUEL LINE TO FEED PUMP
146
HOLLOW SCREW , Replaced By: N915036010108
149
SEAL RING
155
LINE
164
HOLLOW SCREW DISTRIBUTOR
170
SEAL RING LINE CONNECTION
185
LINE RETURN LINE
185
LINE , Replaced By: A6150705632
194
FITTING , Replaced By: A6170700030
194
INTERMEDIATE PIECE
197
SEAL RING
200
VALVE
200
OVERFLOW VALVE. VALVE , Replaced By: A0000747284
203
SEAL RING LINE CONNECTION
206
HOSE FUEL RETURN LINE
209
CLAMP HOSE TO RADIATOR AND TO EXPANSION TANK 12-22X13 MM
209
CLAMP , Replaced By: N000000000665
212
HOSE , Replaced By: A6154760326
212
HOSE , Replaced By: A6050780581
212
HOSE , Replaced By: A6154760326
212
FUEL HOSE FROM NO.1 NOZZLE HOLDER TO FUEL RETURN LINE 245 MM, ORDER BY THE METER
215
RUBBER CAP NOZZLE HOLDER NO.4
215
LOCKING CAP
215
SCREENING NOZZLE HOLDER
215
SCREENING , Replaced By: A4030700055
215
RUBBER CAP , Replaced By: A6040700255
