Поз.
Артикул
Описание
90
COVERING SHOCK ABSORBER 7C52
90
COVERING , AS OF PRODUCTION BREAKPOINT (DISCONTINUATION DATE FOR BCS)01.02.2010....... I NR.7E86 I ....... I ....... I ....... II
93
SERVICING COVER
93
SERVICING COVER , Replaced By: A6286837610
125
COVERING
126
CLAMPING DISC30X23X3,5X0,4MM
127
SEALING TAPE SELF-ADHESIVE, ORDER BY THE METER TO BE ADAPTED DURING ASSEMBLY
130
COVER , AS OF PRODUCTION BREAKPOINT (DISCONTINUATION DATE FOR BCS)01.10.2008
130
COVERING ENGINE MAINTENANCE,101354 ALSO INSTALLED ON 101259-101267,101283-101288,101295,101304,101306,101307,101310-101317,101319,101323-101348. EXCEPT FOR 101354-101358,101359,101360,300140-300144.
130
COVER ENGINE MAINTENANCE,101354 ALSO INSTALLED ON 101259-101267,101283-101288,101295,101304,101306,101307,101310-101317,101319,101323-101348. EXCEPT FOR 101354-101358,101359,101360,300140-300144.
130
COVER , AS OF PRODUCTION BREAKPOINT (DISCONTINUATION DATE FOR BCS)01.10.2008
131
INSULATION , UP TO PRODUCTION BREAKPOINT (DISCONTINUATION DATE FOR BCS) 30.09.2008
132
CLAMPING DISC30X23X3,5X0,4MM
133
DAMPING , TO BE ADAPTED DURING ASSEMBLY
135
FASTENER COVERING TO FLOOR
137
SEAL , ORDER BY THE METER TO BE ADAPTED DURING ASSEMBLY
137
SEAL , ORDER BY THE METER TO BE ADAPTED DURING ASSEMBLY
140
RUBBER SEAL , ORDER BY THE METER TO BE ADAPTED DURING ASSEMBLY
140
ADHESIVE TAPE , ORDER BY THE METER
142
NUTM10
145
SERVICING COVER , AS OF PRODUCTION BREAKPOINT (DISCONTINUATION DATE FOR BCS)01.10.2008
145
SERVICING COVER , UP TO PRODUCTION BREAKPOINT (DISCONTINUATION DATE FOR BCS) 30.09.2008
146
DAMPING , TO BE ADAPTED DURING ASSEMBLY
147
FASTENER COVERING TO FLOOR
148
CLAMPING DISC30X23X3,5X0,4MM
149
NUTM10
150
ADHESIVE TAPE , ORDER BY THE METER
152
SEAL , ORDER BY THE METER TO BE ADAPTED DURING ASSEMBLY
155
COVERING LEFT ENGINE SUPPORT
176
COVERING SECONDARY SWITCHBOARD, Replaced By: A6286838110
176
COVERING
176
SERVICING COVER SECONDARY SWITCHBOARD
178
SERVICING COVER REAR AXLE
178
COVERING LONGITUDINAL CONTROL ARM
181
COVERING SECONDARY SWITCHBOARD, Replaced By: A6286838510
181
SERVICING COVER SECONDARY SWITCHBOARD
