Поз.
Артикул
Описание
10
HEATER CASE
14
HEAT EXCHANGER
17
INTERMEDIATE PIECE
19
COVER , UP TO CHASSIS: 115.010 118594 115.015 115810 115.110,112 318429 115.115 155810 FROM CHASSIS,SEE SA 55959
21
ELEMENT , Replaced By: A0008001775
24
ELEMENT , Replaced By: A0008000875
26
ROD , FROM CHASSIS:114.011 017604 114.015 131834 114.023 009936 115.010 112908 115.015 145989 115.110 299410 FROM CHASSIS: 115.115 153338
28
LOCK ROD TO CONTROL LEVER
30
CLAMPING SPRING
30
LOCK , Replaced By: N918002004000
32
ROD , FROM CHASSIS:114.011 017604 114.015 131834 114.023 009936 115.010 112908 115.015 145989 115.110 299410
35
CLAMP WIRE CABLE TO FIRE WALL
41
INTERMEDIATE PIECE (FRONT AND REAR SPACE HEATING), FROM CHASSIS: 010 026147 110 057164
52
SCREW , Replaced By: A0009905233
52
SCREW
65
BLOWER
67
CARBON BRUSH SET
70
SWITCH
72
SEAL
79
RUBBER RING EMERGENCY LANTERN TO CAB
79
SEAL RING
84
DUCT LEFT
89
DEFROSTER NOZZLE LEFT
89
DEFROSTER NOZZLE , Replaced By: A1158300119
93
SEAL
95
VALVE
97
WATER PASSAGE
104
CONTROL VALVE
108
SEAL
111
SEAL INSIDE
111
SEAL , Replaced By: A0008354898
115
BRACKET , FROM CHASSIS: 059325, ALSO INSTALLED ON: 058958,058963,059023,059025,059137,059138,059145,059147,059152,059155,059159,059160,059164-059177, 059179-059182,059185,059187-059199,059298-059321,059323.
117
SHEET METAL SCREW BRACKET TO CAB FLOOR
119
WASHER , FROM CHASSIS: 005,007,008,015,017 10/50,12/52 009573, ALSO INSTALLED ON: 009319,009323,009404,009444,009449,009450,009454-009456,009458,009459,009461-009472,009475-009477, 009479-009494,009496-009571. 010 10/50,12/52 013397, ALSO INSTALLED ON: 013289,013348,013354,013356,013358,013361-013367,013370-013381,013384-013388,013390-013395. 005,007,008,015,017 20/60,22/62 012727 010 20/60,22/62 015672
123
SHEET METAL SCREW
126
WASHER , FROM CHASSIS: 005,007,008,015,017 10/50,12/52 009573, ALSO INSTALLED ON: 009319,009323,009404,009444,009449,009450,009454-009456,009458,009459,009461-009472,009475-009477, 009479-009494,009496-009571. 010 10/50,12/52 013397, ALSO INSTALLED ON: 013289,013348,013354,013356,013358,013361-013367,013370-013381,013384-013388,013390-013395. 005,007,008,015,017 20/60,22/62 012727 010 20/60,22/62 015672
226
HOSE , Replaced By: A1158300096
228
RIVET
234
NOZZLE LEFT, FROM CHASSIS: 002562, ALSO INSTALLED ON: 002452,002468,002474,002489,002522,002537,002540,002541,002545,002548-002552,002554,002556-002559, 002561-002563.
237
BALL INSERT
239
HANDLE
241
WAVE RING
244
HOSE 485 MM
245
HOSE485 MM
277
GROMMET EXPANSION PLUG
278
GROMMET
280
HOSE BETWEEN WATER FAUCET AND HEATER CASE
294
HOSE BETWEEN FAUCET AND FEED LINE
305
RUBBER RING
999
CLAMP PRESSURE REGULATOR
999
CLAMP , Replaced By: N000000000667
999
CLAMP , Replaced By: A0059970190
999
COMBINATION BOLT RESERVOIR TO WHEELHOUSE, UP TO CHASSIS: 107.022 005200, EXCEPT FOR: 005190-005192,005194-005199 107.023 012496 107.024 021803, EXCEPT FOR: 021794,021802 107.042 004221, EXCEPT FOR: 004213,004215-004218,004220 107.043 013576 107.044 047067, EXCEPT FOR: 047057,047061,067062,047064-047066
999
LOCK PLATE CONSOLE TO REAR PANELLING,TOP
999
LOCK WASHER CONTROL LEVER TO INJECTION PUMP LEVER
999
DUO CLIP , Replaced By: N912010005001
999
NUT
999
SCREW COVER PLATE TO COVER PLATE M 6 X 12
999
BULB , Replaced By: A6885447093
999
WASHER COMPRESSED AIR LINE TO BRACKET
999
WASHER , Replaced By: N009021006208
999
SCREW , Replaced By: N000000001933
999
SCREW STEERING COLUMN MOUNTED SWITCH TO STEERING COLUMN BRACKET M4X10
999
SHEET METAL SCREW CABLE CONNECTOR TO RIGHT WHEEL ARCH PANEL
999
SHEET METAL SCREW BRACKET TO FLOOR PLATE, Replaced By: N000000000460
999
SHEET METAL SCREW BRACKET TO CAB 4,2X13
999
SHEET METAL SCREW CABLE CONNECTOR TO BRACKET
999
SHEET METAL SCREW FENDER TO BODY
999
SHEET METAL SCREW
999
TOOTHED WASHER MASKED STOP LAMP
999
NUT , Replaced By: N304032008006
999
NUT BALL PIVOT TO LEVER
999
SCREW , ALSO APPLICABLE TO VERSION 55705/11-/62
999
SCREW , Replaced By: N304017006018
999
SCREW BRACKET TO AIR INTAKE PIPE
999
WASHER BOOT TO CAB FLOOR
999
SPRING WASHER , Replaced By: N000137008212
999
SPRING WASHER ALTERNATOR CONNECTION D+
999
LOCK WASHER 3/2-WAY SOLENOID VALVE TO BRACKET
999
WASHER COMPRESSED AIR LINE TO BRACKET
999
WASHER COMPRESSED AIR LINE TO BRACKET, Replaced By: N000125006449
999
WASHER , UP TO CHASSIS: 017 029988 114 000523 117 064694
999
WASHER , Replaced By: N000433005304
999
CLAMP HOSE TO SUCTION LINE AND TO OIL TANK 20-32X13 MM
999
SHEET METAL SCREW BRACKET TO FLOOR PLATE
999
CLAMP , Replaced By: A1149950335
999
CLAMP , 116.020 071390 ALSO INSTALLED ON 071392,071396,071400,071402,071416. 116.024,025 068051 ALSO INSTALLED ON 068099,068265 EXCEPT FOR 055714,055888,057629,058694,066624,066628,066632,066803,067088,067089,067410,067542,067578-067580, 067860-067862,067865,067924,067928-067943,067945,067948,067952,067953,067955-067969,067971-068001, 068005,068007-068019,068024,068026-068029,068031-068033,068035-068048,068050.
999
REPAIR KIT , Replaced By: A1158300033
999
BLOWER , Replaced By: A1158350207
999
CONDENSER , Replaced By: A1158300270, +001A1156200685
999
BLOWER , Replaced By: A1158350407
999
ESCUTCHEON , FROM CHASSIS: 023 009210
999
WIRE CABLE , UP TO CHASSIS: 000,002,010 007271 015 004377 100,102,103,110,112 017437 115 007951, Replaced By: A1158300331, +001A1158351514
999
WIRE CABLE , UP TO CHASSIS: 000,002,010 007271 015 004377 100,102,103,110,112 017437 115 007951, Replaced By: A1158300231, +001A1158351514
999
HOSE , Replaced By: A1158313794
999
SEAL RIGHT, NO LONGER AVAILABLE INDIVIDUALLY, BUT ONLY IN CONNECTING DUCT ASSEMBLY
999
DUCT RIGHT
999
SEAL LEFT, NO LONGER AVAILABLE INDIVIDUALLY, BUT ONLY IN CONNECTING DUCT ASSEMBLY
999
HOSE , Replaced By: A1148312394
999
HEATER CASE , Replaced By: A1158304462
999
WIRE CABLE , Replaced By: A1158301131
999
DEFROSTER NOZZLE , Replaced By: A1158300219
999
BRACKET RIGHT
999
ESCUTCHEON , Replaced By: A1158301189
999
OPERATING UNIT , Replaced By: A1158300785
999
CONDENSER
999
NOZZLE RIGHT, FROM CHASSIS: 010 034089, ALSO INSTALLED ON: 033673,033706,033709,033716,033736,033765,033914,033922,033926,033930,033931,033934,033936,033938, 033939,033941-033951,033953,033955,033956,033959,033960,033962,033964,033966,033967,033969-033998, 034000-034010,034012-034022,034024-034087.
999
WIRE CABLE RIGHT, FROM CHASSIS: 000,002,010 013352 EXCEPT FOR: 013355,013825 015 010341 EXCEPT FOR: 010347,010405,010406 100,102,103,110,112 029021 EXCEPT FOR: 029562 115 013141
999
BRACKET RIGHT, ALSO APPLICABLE TO VERSION 55705/11-/62
999
ESCUTCHEON , UP TO CHASSIS: 073 000332
999
DEFROSTER NOZZLE RIGHT
999
HOSE
999
REPAIR KIT LEFT,MAKE KAMMERER
999
INTERMEDIATE PIECE , Replaced By: A1148300024
999
PLUG , EXHAUST STOCK OF OLD PART NUMBERS FIRST UP TO CHASSIS: 005,017 028049 015 238752 100,102,103,110,112 431300 105,107,108,117,119 060601 114 000208 115 248583, Replaced By: A1158211951
999
KNOB , FROM CHASSIS: 023 009210
999
REPAIR KIT , Replaced By: A1238300133
999
BRACKET , UP TO CHASSIS: 114.060 005816 114.062 005545 114.072 004088 114.073 001146, Replaced By: A1148350314, +001A1149950320
999
HOSE , Replaced By: A0009972352
999
HOSE , Replaced By: A0009973552
999
PIPE LINE , FROM CHASSIS: 073 103729, FEDERAL, ALSO INSTALLED ON: 103388,103528,103535,103585,103608,103707,103715,103717,103722. FROM CHASSIS: 073 103836, CALIFORNIA, ALSO INSTALLED ON: 103522,103523,103542,103557,103582,103727,103741,103742,103758-103760,103778,103786,103791,103799, 103800,103803,103809-103815,103819,103820,103822,103824,103830-103834. EXHAUST STOCK OF OLD PART NUMBERS FIRST UP TO CHASSIS: 073 105922, Replaced By: A1148302015
999
PIPE LINE
999
PIPE LINE FROM EVAPORATOR TO COMPRESSOR, FOR USE IN CALIFORNIA ONLY FROM CHASSIS: 073 100001 UP TO CHASSIS: 073 103835, CALIFORNIA, EXCEPT FOR: 103522,103523,103542,103557,103582,103727,103741,103742,103758-103760,103778,103786,103791,103799, 103800,103803,103809-103815,103819,103820,103822,103824,103830-103834.
999
WIRE CABLE , Replaced By: A1158301131
999
HOSE , Replaced By: A0009978482
999
HOSE , Replaced By: A0009971752
999
HOSE , Replaced By: A0189975982, +001A0009970168, +001A0009975168
999
HOSE CLAMP LINE MOUNTING
999
HOSE RESERVOIR DE-AERATION,4 238841 ORDER BY THE METER
999
SWITCH , Replaced By: A0008353706
999
SWITCH , Replaced By: A1158211851
999
LOOM TIE , Replaced By: A0019974390
999
HOSE , Replaced By: A0189971882, +001A0009970668, +001A0019978468
999
HOSE FROM COMPRESSOR TO EVAPORATOR 1500 MM, LESS HOSE CONNECTIONS
999
HOSEN.W.: 10 6000 MM, LESS HOSE CONNECTIONS
999
HOSE FROM LIQUID TANK TO EXPANSION VALVE 430 MM, LESS HOSE CONNECTIONS
999
HOSE , LESS HOSE CONNECTIONS, Replaced By: A0009973552
999
SWITCH , Replaced By: A0018352606
999
HEAT EXCHANGER , Replaced By: A0018353001
999
CARBON BRUSH SET , Replaced By: A0008352575
999
LEVER RIGHT,MAKE R. & S.
999
LEVER LEFT, MAKE REITER & SCHEFENACKER
999
LEVER , Replaced By: A0008352843
999
LEVER , Replaced By: A0008352743
999
SEAL , Replaced By: A0008350598
999
SWITCH , Replaced By: A1158211851
999
SCREW PLUG , Replaced By: A1158320098, +001A1159971540
