Поз.
Артикул
Описание
30
PRESSURE REGULATING UNIT , ORDER DETACHABLE PARTS AS WELL
65
FITTING DELIVERY LINE 8-9/16-18
85
MALE STUD COUPLING DELIVERY LINE
155
BRACKET AIR CONDITIONER CABLE HARNESS
180
CLAMP
190
CLAMP6/14-15 MM
200
LINE HOLDER FASTENING, GAS LINE
210
CLAMP
220
DAMPING STRIP FUEL LINES TO VEHICLE FLOOR
230
GAS PIPE PRESSURE VALVE AT PRESSURE REGULATOR
240
GAS PIPE PRESSURE REGULATOR
280
BOOT BOOT
300
FUEL HOSE ENGINE COMPARTMENT
310
LINE FILLER NECK TO RESERVOIR
320
LINE CONNECTION IN GAS TANK PACKAGE
330
LINE FROM RESERVOIR TO T-FITTING
340
LINE FROM RESERVOIR TO T-FITTING
350
LINE FROM T-FITTING TO PRESSURE REGULATOR
360
LINE CONNECTION IN GAS TANK PACKAGE
370
MALE STUD COUPLING LINE MOUNTING 8MM
380
HOSE , Replaced By: N073379008200
400
PIPE PRESSURE REDUCING VALVE TO ENGINE
400
LINE FROM PRESSURE REGULATOR TO CONNECTOR
410
MALE STUD COUPLING DELIVERY LINE
420
SCREW CONNECTION
430
T-CONNECTOR T-FITTING
450
FITTING AT PRESSURE REGULATOR
455
SEAL RING FITTING TO AXLE HOUSING
460
COVER AT PRESSURE REGULATOR
470
VALVE CHECK VALVE
480
SEALING RING
490
HEXALOBULAR BOLT DELIVERY LINE TO PUMP M6X25
500
BREATHER PIPE IM LUGGAGE COMPARTMENT 445 MM
500
BREATHER PIPE IM LUGGAGE COMPARTMENT 356 MM
500
BREATHER PIPE IM LUGGAGE COMPARTMENT 179 MM
500
BREATHER PIPE IM LUGGAGE COMPARTMENT 1186 MM
500
BREATHER PIPE IM LUGGAGE COMPARTMENT 728 MM
510
PRESSURE VALVE LOW-PRESSURE GAS SHUTOFF VALVE Y107/3
520
CAP BOLT PRESSURE VALVE M6X10
525
FITTING VALVE 10-BG1/4
530
FITTING PRESSURE VALVE M16X1.5
535
SEALING RING. SEAL RING DELIVERY LINE TO PUMP
540
SEAL RING
550
LOOM TIE HOSE TO RADIATOR AND TO EXPANSION TANK
550
CLAMP HOSE FASTENING 28-35 MM,V 207570
610
PIPE FLANGE CLAMP TO MOUNT FUEL LINES
700
GUIDE SIGN NATURAL GAS FUELING LABEL
710
CLAMP
800
PIN BUSHING HOUSING OUTBOARD TEMPERATURE FEELER 2-PIN CODE A,B4,126373
805
CONTACT BUSHING WITH SINGLE-WIRE SEAL 0.5MM2,126373
810
CLUTCH. PIN BUSHING HOUSING SIREN
815
FEMALE CONTACT SWITCH, POWER WINDOW, DRIVER 0.25-0.5 MM2 MQS,S20
830
PIN BUSHING HOUSING2-PIN,H2,TO A0065427220
835
FEMALE CONTACT0.5-1.0 MM2 MINI MIC
