Поз.
Артикул
Описание
44
HOSE BRAKE VALVE BLEEDING,5 939757
45
LINE PRESSURE REGULATOR BREATHING 1950 MM
45
LINE PRESSURE REGULATOR,ANTI-FREEZE DEVICE
47
CONNECTOR 75 DEGREES
47
CONNECTOR BRAKE POWER REGULATOR,CONNECTION: "30"
47
CONNECTOR 90 DEG. OFFSET
50
CONNECTOR BRAKE POWER REGULATOR,CONNECTION: "30"
50
CONNECTOR 75 DEGREES
50
CONNECTOR BRAKE POWER REGULATOR,CONNECTION: "30"
50
CONNECTOR BRAKE POWER REGULATOR,CONNECTION: "30"
53
SEALING CORD SUCTION LINE TO OIL PUMP
53
SEAL RING BLEEDING 19X4 MM
62
FITTING BRAKE POWER REGULATOR,CONNECTION: "30"
62
FITTING TRAILER CONTROL VALVE
80
CONNECTOR PRESSURE REGULATOR,CONNECTION: "30",5 720607
80
CONNECTOR BLEEDING
80
CONNECTOR BLEEDING
80
CONNECTOR BLEEDING
80
CONNECTOR VALVE BLEEDING
83
SEAL RING BLEEDING 19X4 MM
84
ANGLE LINE MOUNTING
85
SCREW BRACKET TO CROSS CONNECTION STRUT
85
SCREW , Replaced By: N304017008034
86
NUT , Replaced By: N913004008001
86
NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET, Replaced By: N910113008003
87
CLAMP , Replaced By: N916026016001
87
CLAMP , Replaced By: A0059970190
87
CLAMP , Replaced By: N000000000667
87
CLAMP HOSE TO SUCTION LINE AND TO OIL TANK 20-32X13 MM
87
CLAMP PRESSURE REGULATOR
87
HOSE CLAMP LINE MOUNTING
89
BREATHER PIPE PRESSURE REGULATOR
90
CLAMP , Replaced By: N916016015202
90
CLAMP DELIVERY AND SUCTION LINES TO ENGINE, FRONT
90
CLAMP LINE MOUNTING
91
SCREW CLAMP MOUNTING M 6X16
91
SCREW , Replaced By: N000000001146
92
NUT , Replaced By: N913004006001
92
NUT PUMP TO BRACKET
95
BRACKET COMPRESSED AIR LINE TO PRESSURE REGULATOR
98
SCREW FRONT AXLE REGULATING SOLENOID VALVE
98
SCREW , Replaced By: N000933008134
99
BRACKET DELIVERY AND SUCTION LINES TO ENGINE, TOP
101
BRACKET LINE MOUNTING
104
BRACKET COMPRESSED AIR LINE TO FOUR-CIRCUIT PROTECTIVE VALVE,5 720506
105
BRACKET LINE MOUNTING
107
BRACKET COMPRESSED AIR LINE TO FOUR-CIRCUIT PROTECTIVE VALVE
110
CLAMP , Replaced By: A6739950001
110
CLAMP DELIVERY AND SUCTION LINES TO STEERING
111
BRACKET FUEL LINES TO TRANSMISSION
113
BRACKET COMPRESSED AIR LINE TO LEFT SIDE MEMBER
113
BRACKET , Replaced By: A3812711340
113
BRACKET DELIVERY AND SUCTION LINES TO ENGINE, FRONT
114
BRACKET LINE MOUNTING
115
BRACKET COMPRESSED AIR LINE TO APPARATUS SUPPORT
116
BRACKET COMPRESSED AIR LINE TO LEFT SIDE MEMBER, NOT USED
119
BRACKET COMPRESSED AIR LINE TO CAB
119
BRACKET COMPRESSED AIR LINE TO CAB
120
BRACKET AT LEFT SIDE MEMBER
122
BRACKET COMPRESSED AIR LINE TO LEFT SIDE MEMBER
125
SCREW CLAMP MOUNTING M 6X16
125
SCREW COMPRESSED AIR LINE TO BRACKET
125
SCREW , Replaced By: N000000001146
128
SCREW , Replaced By: N304017006016
128
SCREW , Replaced By: N000933008337
128
SCREW , Replaced By: N304017008034
128
SCREW , Replaced By: N304017008033
128
SCREW , Replaced By: N304017008016
128
SCREW , Replaced By: A0099900101
128
SCREW PUMP TO BRACKET
128
SCREW CLAMP TO BRACKET AND TO PIPE
128
SCREW PROTECTIVE PLATE TO EXHAUST MUFFLER
128
SCREW OIL-DIPSTICK GUIDE TUBE TO BRACKET
128
SCREW END PIECE TO EXHAUST PIPE M 10X25
128
SCREW COMPRESSED AIR LINE TO LEFT SIDE MEMBER
128
HEXAGON HEAD BOLT. SCREW COMPRESSED AIR LINE TO LEFT SIDE MEMBER
128
SCREW BRACKET TO FRAME SIDE MEMBER
128
SCREW BRACKET TO CROSS CONNECTION STRUT
131
WASHER COMPRESSED AIR LINE TO BRACKET
131
WASHER COMPRESSED AIR LINE TO BRACKET
131
WASHER COMPRESSED AIR LINE TO BRACKET, Replaced By: N000125006449
131
WASHER , Replaced By: N009021006208
134
NUT , Replaced By: N913004006001
134
NUT PUMP TO BRACKET
134
NUT AT FILTER BRACKET
137
NUT STRAP TO BRACKET
137
NUT SUPPORT TO SIDE MEMBER
137
NUT COMPRESSED AIR LINE TO LEFT SIDE MEMBER
137
NUT , Replaced By: N913004006003
137
NUT , Replaced By: N910113006001
137
NUT , Replaced By: N913004008001
137
NUT , Replaced By: N910113010000
137
NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET, Replaced By: N910113008003
140
BRACKET , Replaced By: A6674710541
140
BRACKET AT CROSS MEMBER
140
BRACKET AT CROSS MEMBER
140
BRACKET AT CROSS MEMBER
143
SCREW BRACKET TO SIDE MEMBER
144
WASHER STRUT TO EXHAUST PIPE AND TO SIDE MEMBER
144
WASHER , Replaced By: N000125015019
146
NUT , Replaced By: N910113014001
146
NUT BRACKET TO SIDE MEMBER
149
MUFFLER VALVE BLEEDING
149
MUFFLER VALVE BLEEDING
149
MUFFLER , Replaced By: A0004302470
152
SEALING CORD SUCTION LINE TO OIL PUMP
157
CONNECTOR VALVE BLEEDING
158
MUFFLER TRAILER CONTROL VALVE
158
MUFFLER , Replaced By: A0004302370
164
SEAL RING LOAD/NO-LOAD VALVE,CONNECTIONS: "20,21",5 727400
165
EDGE GUARD SECTION AT SHOCK ABSORBER BRACKET, ORDER BY THE METER
165
EDGE GUARD SECTION , Replaced By: A0019872272
999
MUFFLER BRAKE VALVE
999
LINE PRESSURE REGULATOR,ANTI-FREEZE DEVICE
999
SCREW CLAMP TO BRACKET, Replaced By: N007985006581
999
SCREW CLAMP TO BRACKET
999
WASHER , Replaced By: N009021006208
999
NUT , Replaced By: N913004006001
999
CLAMP HOSE TO FLANGE AND TO VALVE
