Поз.
Артикул
Описание
59
VALVE BODY ASSEMBLY PISTON
62
BALL (CHECK VALVE),SECONDARY PUMP
65
INTERMEDIATE PLATE PISTON, UP TO TRANSMISSION 004074 EXCEPT FOR 004049,004054-004056,004073
65
INTERMEDIATE PLATE PISTON, FROM TRANSMISSION 015028 ALSO INSTALLED ON 014908,014913,014975,014994,014995,014998,015005
68
PISTON PISTON
71
SPRING PISTON,INSIDE 1.40X17.00X163.50 MM, UP TO TRANSMISSION 015027 EXCEPT FOR 014908,014913,014975,014994,014995,014998,015005 BUT NOT FOR AUSTRALIA
74
SPRING PISTON,OUTSIDE 2.00X22.50X149 MM
77
GUIDE PISTON
80
PISTON LOCK-UP COUPLING
83
SPRING PISTON,INSIDE 2.00X15.50X97 MM
86
SPRING PISTON,OUTSIDE 3.00X23.50X95.50 MM
95
LOCKING SHEET RELAY VALVE
98
SCREW PROTECTION PLATE TO BRACKET
101
PIN LOCK-UP SHIFT VALVE
104
SPRING DOWNSHIFT RELAY VALVE 2-1 0.80X11.30X28 MM
107
SHIFT VALVE REVERSE SPEED,017762
110
LOCK REGULATOR VALVE
113
SHIFT VALVE DOWNSHIFT RELAY VALVE 4-3
116
SPRING DOWNSHIFT RELAY VALVE 4-3 0.80X6.60X51 MM
119
PIN LOCK-UP SHIFT VALVE
125
SCREW PLUG
128
LOCKING SHEET
