Поз.
Артикул
Описание
59
MAIN SHAFT ,004015
59
MAIN SHAFT , UP TO TRANSMISSION 004014 DELIVER ADDITIONALLY:AS REQUIRED 1 X 000471 070000,1 X 002 994 20 41-002 994 23 41, Replaced By: A0002621705
62
NEEDLE BEARING 2ND AND 3RD SPEED
62
NEEDLE BEARING STEERING KNUCKLE,TOP AND BOTTOM
65
GEAR 3RD SPEED
68
FOLLOWER 1ST AND 2ND SPEED
71
SLIDING COLLAR 1ST THRU 4TH SPEED
71
SLIDING COLLAR , Replaced By: A0002621923
74
SYNCHRONIZER RING , Replaced By: A0002626834
74
SYNCHRONIZER RING 1ST THRU 4TH SPEED
74
SYNCHRONIZER RING 3RD THRU 6TH SPEED TO 336 262 04 35,10/20879180, 50/60880936
77
SYNCHRONIZER BODY , UP TO TRANSMISSION 004014 DELIVER ADDITIONALLY:AS REQUIRED 1 X 000471 070000,1 X 002 994 20 41-002 994 23 41, Replaced By: A0002622135
77
SYNCHRONIZER BODY 1ST AND 2ND SPEED
80
SPRING SPLITTER BOX
83
SPRING SPLITTER BOX
86
END PIECE SPLITTER BOX
89
LOCK AS REQUIRED 2.30 MM,10/20879179, 50/60880935
89
LOCK AS REQUIRED 2.40 MM,10/20879179, 50/60880935
89
LOCK , Replaced By: N000471070000
89
LOCK , Replaced By: N000471070000
89
LOCK , Replaced By: N000471070000
89
LOCK , Replaced By: N000471070000
89
LOCK RING AS REQUIRED 2.50 MM
89
LOCK RING AS REQUIRED 2.50 MM,10/20879179, 50/60880935
92
NEEDLE BEARING , Replaced By: A0079811910
92
NEEDLE BEARING 4TH SPEED GEAR
92
NEEDLE BEARING FIRST/SECOND/REVERSE SPEED GEARS,297251
95
GEAR 4TH SPEED
98
BUSHING 3RD SPEED GEAR
98
BUSHING , Replaced By: A0002620750
101
NEEDLE BEARING , Replaced By: A0129817810
101
NEEDLE BEARING 3RD SPEED GEAR
104
GEAR 5TH SPEED
104
GEAR , EXHAUST STOCK OF OLD PARTS NUMBER FIRST UP TO TRANSMISSION 021 003, Replaced By: A0002622215
107
FOLLOWER 5TH AND 6TH SPEED
110
SYNCHRONIZER BODY 5TH AND 6TH SPEED,10/20879180, 50/60880936
110
SYNCHRONIZER BODY , Replaced By: A0002622235
113
LOCK RING AS REQUIRED 45X2.5 MM
113
LOCK AS REQUIRED 45X2.25 MM
113
LOCK AS REQUIRED 45X2.45 MM
113
LOCK AS REQUIRED 45X2.35 MM
116
FOLLOWER
116
FOLLOWER , Replaced By: A0002621740
119
SPACER RING , Replaced By: A0002621551
119
SPACER RING , Replaced By: A0002621351
119
SPACER RING , Replaced By: A0002621151
119
SPACER RING , Replaced By: A0002620951
119
SPACER RING , Replaced By: A0002620651
119
SPACER RING , Replaced By: A0002620451
119
SPACER RING AS REQUIRED 4.40 MM,10/20879180, 50/60880936
119
SPACER RING AS REQUIRED 3.50 MM
119
SPACER RING AS REQUIRED 5.50 MM
119
SPACER RING AS REQUIRED 4.00 MM,10/20879180, 50/60880936
119
SPACER RING AS REQUIRED 3.00 MM,10/20879180, 50/60880936
119
SPACER RING AS REQUIRED 4.90 MM
119
SPACER RING AS REQUIRED 4.80 MM,10/20879180, 50/60880936
119
SPACER RING2.70 MM
119
SPACER RING AS REQUIRED 5.80 MM
119
SPACER RING AS REQUIRED 3.80 MM
122
CYLINDR. ROLLER BEARING
122
CYLINDR. ROLLER BEARING
125
LOCK RING
128
GEAR 2ND SPEED
131
FOLLOWER 1ST AND 2ND SPEED
134
SYNCHRONIZER RING 1ST AND 2ND SPEED TO 000 262 29 35
134
SYNCHRONIZER RING 1ST AND 2ND SPEED TO 336 262 02 35,10/20879180, 50/60880936
137
SYNCHRONIZER BODY 1ST AND 2ND SPEED
137
SYNCHRONIZER BODY , Replaced By: A0002622835
140
LOCK RING , Replaced By: A3872620673
140
LOCK MAINSHAFT, AS REQUIRED 2.35 MM
140
LOCK AS REQUIRED 1.98 MM
140
LOCK
143
SLIDING COLLAR 1ST AND 2ND SPEED
146
NEEDLE BEARING 1ST SPEED GEAR
149
GEAR 1ST SPEED
152
FOLLOWER REVERSE SPEED
155
BUSHING REVERSE SPEED GEAR
158
NEEDLE BEARING REVERSE SPEED GEAR
158
NEEDLE BEARING , Replaced By: A0109818410
161
GEAR REVERSE SPEED
164
CYLINDR. ROLLER BEARING , Replaced By: A0059815201
164
CYLINDR. ROLLER BEARING ,10/20879179, 50/60880935
167
SNAP RING ADDITIONAL GEAR CHLUSTER DRIVE SHAFT
170
DRIVE GEAR SPEEDOMETER DRIVE
182
SCREW BRACKET TO FRAME
185
THRUST WASHER. SEAL RING DRIVEN FLANGE TO DRIVE SHAFT, UP TO CHASSIS 4 277882 FROM CHASSIS 4 277883 SEE MICROFICHE,MODEL 750.402
188
LOCK SCREW
188
LOCK , Replaced By: A3859941032
