Поз.
Артикул
Описание
5
PLANETARY CARRIER FRONT, 720.103 000013 720.103 000043
5
PLANETARY CARRIER , 720.103 000012 720.103 000042, Replaced By: A3092701343, +001A3092720462
8
LOCK
11
LOCK
14
SNAP RING ,031316
17
GUARD PLATE
20
SPACER WASHER AS REQUIRED 0.2 MM
20
SPACER WASHER AS REQUIRED 0.1 MM
20
SPACER WASHER 0.5 MM,AS REQUIRED
23
SPACER WASHER DRIVE SHAFT,AS REQUIRED 0.20 MM
23
SPACER WASHER DRIVE SHAFT,AS REQUIRED 0.10 MM
23
SPACER WASHER 0.5 MM,AS REQUIRED
29
PLANETARY CARRIER DRIVE SHAFT
32
NEEDLE BEARING , Replaced By: A0009811411
32
NEEDLE BEARING
38
GUARD PLATE , 013131 EXCEPT FOR 010364-010763
41
FLANGE FIRST CLUTCH
41
FLANGE , Replaced By: A3092700320, +001A1152707332
44
NEEDLE BEARING , Replaced By: A0069814210
44
NEEDLE BEARING FIRST CLUTCH
44
NEEDLE BEARING
47
SNAP RING
50
BOOT
50
BOOT , Replaced By: A1152721292
50
BOOT , THE OLD PART MUST NO LONGER BE INSTALLED, Replaced By: A3162720792
53
PISTON
53
PISTON FIRST CLUTCH
56
SPRING
59
BOOT , Replaced By: A1152721492
59
BOOT
62
BRACKET
65
SNAP RING
68
OUTER DISC
68
OUTER DISC AS REQUIRED 3.00 MM, 103 FROM TRANSMISSION 000100, 104 FROM TRANSMISSION 000140 LESS PARKING INTERLOCK
71
INNER DISC AS REQUIRED 2.10 MM
74
OUTER DISC , WITH 108 270 09 01: FROM TRANSMISSION 025698-033564 ALSO INSTALLED ON 020066-023715, WITH 108 270 13 01: FROM TRANSMISSION 000 001
77
LOCK
83
PLANETARY CARRIER , Replaced By: A3092701843, +002A0099811210
83
PLANETARY CARRIER DRIVE SHAFT,007348
86
NEEDLE BEARING
89
NEEDLE BEARING , Replaced By: A0079813910
89
NEEDLE BEARING
89
NEEDLE BEARING PLANETARY CARRIER,007348
95
GUARD PLATE , FROM TRANSMISSION 019700 ALSO INSTALLED ON 009817-010986
95
GUARD PLATE PLANETARY CARRIER, 720.103 000013 720.103 000043
95
GUARD PLATE
98
BALL BEARING
101
GUARD PLATE DRIVE SHAFT
104
SPACER WASHER AS REQUIRED 0.5 MM
104
SPACER WASHER AS REQUIRED 0.1 MM
104
SPACER WASHER AS REQUIRED 0.2 MM
107
FLANGE
110
SCREW SWITCH TO FLOOR PLATE M6X16,5 220373
113
NEEDLE BEARING
116
NEEDLE BEARING ,043589
119
LOCK
122
DRIVE SHAFT REAR
125
SEAL RING DRIVE SHAFT
125
SEAL RING DRIVE SHAFT
128
SNAP RING ,031316
131
GUARD PLATE
134
NEEDLE BEARING
137
DRIVE SHAFT WITH FREEWHEEL
140
NEEDLE BEARING
143
LOCK ,022986
