Поз.
Артикул
Описание
5
DIFFERENTIAL GEAR LESS RING GEAR AND PINION,751870
5
DIFFERENTIAL GEAR LESS RING GEAR AND PINION,751870
8
DIFFERENTIAL CASETO 615 350 25 23
8
DIFFERENTIAL CASETO 615 350 19 23
11
SCREW DIFFERENTIAL SPIDER,PIVOT: 29 MM
11
SCREW , Replaced By: A0059905104
14
DIFFERENTIAL SPIDER DIFFERENTIAL GEAR,3 325902
15
ROLLER DIFFERENTIAL GEAR BEARING,3 325902
17
DIFFERENTIAL PINION , ONLY REPLACEABLE BY THE SET446113 TOGETHER WITH 617 353 01 15 EXCHANGEABLE FOR 345 353 07 14, Replaced By: A3453530714, +002A3453531015
17
DIFFERENTIAL PINION
20
THRUST WASHER DIFFERENTIAL GEAR BEARING,N 078316
21
SPACER RING DIFFERENTIAL PINION,BOTTOM
21
SPACER RING DIFFERENTIAL GEAR BEARING
23
SIDE GEAR , FIRST EXHAUST STOCK OF OLD PARTS UP TO REAR AXLE N 078315, Replaced By: A6153530115, +004A6153530214
23
SIDE GEAR
26
THRUST WASHER DIFFERENTIAL GEAR,AS REQUIRED 1.80 MM -MS-, ONLY INSTALL PARTS MADE OF THE SAME MATERIAL
26
THRUST WASHER DIFFERENTIAL GEAR,AS REQUIRED 1.70 MM -MS-, ONLY INSTALL PARTS MADE OF THE SAME MATERIAL
26
THRUST WASHER DIFFERENTIAL GEAR,AS REQUIRED 1.65 MM -MS-, ONLY INSTALL PARTS MADE OF THE SAME MATERIAL
26
THRUST WASHER AS REQUIRED, BRASS 1.60 MM, ONLY INSTALL PARTS MADE OF THE SAME MATERIAL
26
THRUST WASHER AS REQUIRED, BRASS 1.55 MM, ONLY INSTALL PARTS MADE OF THE SAME MATERIAL
26
THRUST WASHER AS REQUIRED, BRASS 1.50 MM, ONLY INSTALL PARTS MADE OF THE SAME MATERIAL
26
THRUST WASHER AS REQUIRED, BRASS 1.45 MM, ONLY INSTALL PARTS MADE OF THE SAME MATERIAL
29
REPAIR KIT PARTS KIT COM ROLETES
32
RING GEAR AND PINION47:12
35
SCREW RING GEAR TO DIFFERENTIAL CASE
35
SCREW , Replaced By: A3859902401
38
TAPERED ROLLER BEARING REAR SPRING SADDLE
38
TAPERED ROLLER BEARING
38
TAPERED ROLLER BEARING
38
TAPERED ROLLER BEARING
41
SCREW COLLAR DIFFERENTIAL GEAR ADJUSTMENT M 145X1.5
44
LOCK SCREW COLLAR,3 261697
47
SCREW HOLDER ON RADIATOR SHROUD M 8X16
50
CYLINDR. ROLLER BEARING DRIVE SHAFT,REAR
50
CYLINDR. ROLLER BEARING DRIVE SHAFT,REAR
53
SNAP RING
56
SNAP RING DRIVE SHAFT,REAR
59
SPACER WASHER DRIVE SHAFT BEVEL GEAR/CROWN WHEEL, REAR,AS REQUIRED 0.50 MM
59
SPACER WASHER DRIVE SHAFT BEVEL GEAR/CROWN WHEEL, REAR,AS REQUIRED 0.25 MM
59
SPACER WASHER DRIVE SHAFT BEVEL GEAR/CROWN WHEEL, REAR,AS REQUIRED 0.20 MM
59
SPACER WASHER DRIVE SHAFT BEVEL GEAR/CROWN WHEEL, REAR,AS REQUIRED 0.15 MM
59
SPACER WASHER
62
TAPERED ROLLER BEARING ON PINION END
62
TAPERED ROLLER BEARING DRIVE SHAFT BEVEL GEAR/CROWN WHEEL, REAR
62
TAPERED ROLLER BEARING DRIVE SHAFT BEVEL GEAR/CROWN WHEEL, REAR
65
THRUST WASHER
68
SPACER WASHER DRIVE SHAFT BEVEL GEAR/CROWN WHEEL, FRONT,AS REQUIRED 6.60 MM
68
SPACER WASHER AS REQUIRED, BRASS 6.62 MM
68
SPACER WASHER AS REQUIRED, BRASS 6.64 MM
68
SPACER WASHER DRIVE SHAFT BEVEL GEAR/CROWN WHEEL, FRONT,AS REQUIRED 6.66 MM
68
SPACER WASHER AS REQUIRED, BRASS 6.68 MM
68
SPACER WASHER DRIVE SHAFT BEVEL GEAR/CROWN WHEEL, FRONT,AS REQUIRED 6.70 MM
68
SPACER WASHER DRIVE SHAFT BEVEL GEAR/CROWN WHEEL, FRONT,AS REQUIRED 6.72 MM
68
SPACER WASHER AS REQUIRED, BRASS 6.74 MM
68
SPACER WASHER DRIVE SHAFT BEVEL GEAR/CROWN WHEEL, FRONT,AS REQUIRED 6.76 MM
68
SPACER WASHER AS REQUIRED, BRASS 6.78 MM
68
SPACER WASHER AS REQUIRED, STEEL 6.60 MM
68
SPACER WASHER AS REQUIRED, STEEL 6.62 MM
68
SPACER WASHER AS REQUIRED, STEEL 6.64 MM
68
SPACER WASHER AS REQUIRED, STEEL 6.66 MM
68
SPACER WASHER AS REQUIRED, STEEL 6.68 MM
68
SPACER WASHER AS REQUIRED, STEEL 6.70 MM
68
SPACER WASHER AS REQUIRED, STEEL 6.72 MM
68
SPACER WASHER AS REQUIRED, STEEL 6.74 MM
68
SPACER WASHER AS REQUIRED, STEEL 6.76 MM
68
SPACER WASHER AS REQUIRED, STEEL 6.78 MM
68
SPACER WASHER AS REQUIRED, BRASS 7.40 MM
68
SPACER WASHER DRIVE SHAFT BEVEL GEAR/CROWN WHEEL, FRONT,AS REQUIRED 7.36 MM
68
SPACER WASHER DRIVE SHAFT BEVEL GEAR/CROWN WHEEL, FRONT,AS REQUIRED 7.32 MM
68
SPACER WASHER DRIVE SHAFT BEVEL GEAR/CROWN WHEEL, FRONT,AS REQUIRED 7.28 MM
68
SPACER WASHER DRIVE SHAFT BEVEL GEAR/CROWN WHEEL, FRONT,AS REQUIRED 7.24 MM
68
SPACER WASHER AS REQUIRED, BRASS 7.20 MM
68
SPACER WASHER AS REQUIRED, BRASS 7.16 MM
68
SPACER WASHER DRIVE SHAFT BEVEL GEAR/CROWN WHEEL, FRONT,AS REQUIRED 7.12 MM
68
SPACER WASHER DRIVE SHAFT BEVEL GEAR/CROWN WHEEL, FRONT,AS REQUIRED 7.08 MM
68
SPACER WASHER DRIVE SHAFT BEVEL GEAR/CROWN WHEEL, FRONT,AS REQUIRED 7.04 MM
68
SPACER WASHER DRIVE SHAFT BEVEL GEAR/CROWN WHEEL, FRONT,AS REQUIRED 7.00 MM
68
SPACER WASHER DRIVE SHAFT BEVEL GEAR/CROWN WHEEL, FRONT,AS REQUIRED 6.96 MM
68
SPACER WASHER DRIVE SHAFT BEVEL GEAR/CROWN WHEEL, FRONT,AS REQUIRED 6.92 MM
68
SPACER WASHER DRIVE SHAFT BEVEL GEAR/CROWN WHEEL, FRONT,AS REQUIRED 6.88 MM
68
SPACER WASHER DRIVE SHAFT BEVEL GEAR/CROWN WHEEL, FRONT,AS REQUIRED 6.84 MM
68
SPACER WASHER DRIVE SHAFT BEVEL GEAR/CROWN WHEEL, FRONT,AS REQUIRED 6.80 MM
68
SPACER WASHER AS REQUIRED, STEEL 7.40 MM
68
SPACER WASHER AS REQUIRED, STEEL 7.38 MM
68
SPACER WASHER AS REQUIRED, STEEL 7.36 MM
68
SPACER WASHER AS REQUIRED, STEEL 7.34 MM
68
SPACER WASHER AS REQUIRED, STEEL 7.32 MM
68
SPACER WASHER AS REQUIRED, STEEL 7.30 MM
68
SPACER WASHER AS REQUIRED, STEEL 7.28 MM
68
SPACER WASHER AS REQUIRED, STEEL 7.26 MM
68
SPACER WASHER AS REQUIRED, STEEL 7.24 MM
68
SPACER WASHER AS REQUIRED, STEEL 7.22 MM
68
SPACER WASHER AS REQUIRED, STEEL 7.20 MM
68
SPACER WASHER AS REQUIRED, STEEL 7.18 MM
68
SPACER WASHER AS REQUIRED, STEEL 7.16 MM
68
SPACER WASHER AS REQUIRED, STEEL 7.14 MM
68
SPACER WASHER AS REQUIRED, STEEL 7.12 MM
68
SPACER WASHER AS REQUIRED, STEEL 7.10 MM
68
SPACER WASHER AS REQUIRED, STEEL 7.08 MM
68
SPACER WASHER AS REQUIRED, STEEL 7.06 MM
68
SPACER WASHER AS REQUIRED, STEEL 7.04 MM
68
SPACER WASHER AS REQUIRED, STEEL 7.02 MM
68
SPACER WASHER AS REQUIRED, STEEL 7.00 MM
68
SPACER WASHER AS REQUIRED, STEEL 6.98 MM
68
SPACER WASHER AS REQUIRED, STEEL 6.96 MM
68
SPACER WASHER AS REQUIRED, STEEL 6.94 MM
68
SPACER WASHER AS REQUIRED, STEEL 6.92 MM
68
SPACER WASHER AS REQUIRED, STEEL 6.90 MM
68
SPACER WASHER AS REQUIRED, STEEL 6.88 MM
68
SPACER WASHER AS REQUIRED, STEEL 6.86 MM
68
SPACER WASHER AS REQUIRED, STEEL 6.84 MM
68
SPACER WASHER AS REQUIRED, STEEL 6.82 MM
68
SPACER WASHER
71
TAPERED ROLLER BEARING DRIVE SHAFT,FRONT
71
TAPERED ROLLER BEARING DRIVE SHAFT BEVEL GEAR/CROWN WHEEL, FRONT
71
TAPERED ROLLER BEARING
74
SPACER RING DRIVE PINION
77
SCREW COLLAR DIFFERENTIAL GEAR ADJUSTMENT
80
LOCK AXLE HOUSING
83
SCREW
86
SEAL RING
86
SEAL RING
86
SEAL RING DRIVE SHAFT,REAR
89
FLANGE FLANGE TO DRIVE PINION GEAR, DIAMETER:150 MM
92
NUT COUPLING FLANGE TO DRIVE SHAFT,5 298189
92
NUT FOLLOWER FLANGE TO PROPELLER SHAFT
