Поз.
Артикул
Описание
433
PLASTIC PIPE. HOSE AERATION 6X8 MM, ORDER BY THE METER
437
FITTING , Replaced By: A0029905971
437
FITTING (PARTS KIT),LINE RUPTURE
441
BANJO UNION HOSE WIDTH, / I.D., 6/12 MM
443
HOLLOW SCREW LINE CONNECTION
444
SEAL RING LINE CONNECTION
446
HOLLOW SCREW LINE CONNECTION
447
SEAL RING , Replaced By: N007603010110
449
SLEEVE , Replaced By: N915062006000
449
SLEEVE LINE CONNECTION
457
GLAND LINE CONNECTION
460
UNION NUT LINE CONNECTION
465
ELBOW FITTING SUPPLY LINE FOR TRANSMISSION
465
ELBOW FITTING SUPPLY LINE FOR TRANSMISSION
473
SEAL RING LINE CONNECTION
479
HOSE LEAK LINE 4X6 MM, ORDER BY THE METER
485
GLAND BLEEDING, FROM IDENT NO. 5 033767,EXCEPT FOR 5 039977
490
UNION NUT BLEEDING, FROM IDENT NO. 5 033767,EXCEPT FOR 5 039977
498
BANJO UNION HOSE WIDTH, / I.D., 4/12 MM
498
BANJO UNION HOSE WIDTH, / I.D., 4/10 MM
499
SLEEVE LEAK LINE
509
LOOM TIE , Replaced By: A0019978390
509
HOLLOW SCREW LINE CONNECTION
512
SEAL RING LINE CONNECTION
540
HOLLOW SCREW LINE CONNECTION
543
SEAL RING , Replaced By: N007603010110
550
HOSE FUEL LINE, ORDER BY THE METER
550
PLASTIC TUBE2X4MM, ORDER BY THE METER
555
BUSHING , Replaced By: N915062002000
555
SLEEVE LINE MOUNTING
558
GLAND LINE MOUNTING
562
UNION NUT LINE MOUNTING, Replaced By: N000000006521
564
PLASTIC PIPE. HOSE AERATION 6X8 MM, ORDER BY THE METER
566
BANJO UNION HOSE WIDTH, / I.D., 6/16 MM
566
BANJO UNION HOSE WIDTH, / I.D., 6/12 MM
570
VALVE GEAR CLUSTER SHIFT
572
CUP 3/2-WAY VALVE WABCO
573
HANDLETO 000 434 23 01
575
REPAIR KIT 3/2-WAY VALVE WABCO
592
BRACKET 3/2-WAY VALVE, UP TO IDENT NO.5 238024,FROM IDENT NO. SEE GROUP 29
592
BRACKET AT CLUTCH PEDAL UNIT
595
SCREW COVER PLATE TO BRACKET
600
LOCK WASHER CONTROL LEVER TO INJECTION PUMP LEVER
605
WASHER BRACKET TO HEAT SHIELD
610
NUT SUCTION LINE TO OIL PUMP
614
BRACKET LINE CONNECTIONS,5 075341
616
BRACKET LINE MOUNTING
616
BRACKET LINE TO BRACKET
618
SCREW COVER PLATE TO BRACKET
620
TAPPING SCREW. SHEET METAL SCREW FUEL LINE
622
LOCK WASHER CONTROL LEVER TO INJECTION PUMP LEVER
626
NUT , Replaced By: N910113006001
630
LOCK , Replaced By: A1409941045
630
LOCK FUEL LINE
635
SEAL RING SWITCH TO CASE COVER
635
SEAL RING VALVE TO VALVE,K 025179
640
SWITCH GEAR CLUSTER INDICATION
640
SWITCH GEAR CLUSTER INDICATION
642
SWITCH
643
SEAL RING NEUTRAL POSITION SWITCH,4 920019
645
SWITCH , Replaced By: A0005459009
645
SWITCH , FIRST EXHAUST STOCK OF OLD PARTS UP TO IDENT NO. 5 360728, Replaced By: A0005457909
646
SEAL RING IDLE POSITION SWITCH TO THREADED BUSHING, AS REQUIRED 2.20 MM
646
SEAL RING IDLE POSITION SWITCH TO THREADED BUSHING, AS REQUIRED 2.40 MM
646
SEAL RING IDLE POSITION SWITCH TO THREADED BUSHING, AS REQUIRED 2.80 MM
646
SEAL RING IDLE POSITION SWITCH TO THREADED BUSHING, AS REQUIRED 1.80 MM
646
SEAL RING IDLE POSITION SWITCH TO THREADED BUSHING, AS REQUIRED 3.00 MM
646
SEAL RING IDLE POSITION SWITCH TO THREADED BUSHING, AS REQUIRED 2.00 MM
646
SEAL RING IDLE POSITION SWITCH TO THREADED BUSHING, AS REQUIRED 2.60 MM
646
SEAL RING IDLE POSITION SWITCH TO THREADED BUSHING, AS REQUIRED 1.60 MM
648
SEAL RING NEUTRAL POSITION
650
PIN NEUTRAL POSITION
652
THREADED BUSHING NEUTRAL POSITION
654
SWITCH , Replaced By: A0035451614
654
SWITCH , Replaced By: A0025458114
654
SWITCH GEAR CLUSTER INDICATION
654
SENDER UNIT OVERREVVING
658
SEAL RING SWITCH TO CASE COVER
658
SEAL RING , Replaced By: N007603018100
999
TS DOUBLE FITTING (PARTS KIT),LINE RUPTURE 4MM
