Поз.
Артикул
Описание
7
T-FITTING , Replaced By: N074317000100
7
FITTING PRESSURE REGULATOR,CONNECTION "2.1",4 967998
13
VALVE
13
VALVE , Replaced By: A0014295244
19
DIAPHRAGMTO 344 429 73 44
19
DIAPHRAGMTO 000 429 63 44
25
VALVE SEAT RINGWABCO,5 433388
31
SPRINGTO 000 429 63 44,000 429 59 44
37
SPRING RETAINERTO 000 429 63 44,000 429 59 44
40
REPAIR KITTO 000 429 63 44,000 429 59 44
43
ELBOW FITTING AT OVERFLOW VALVE
43
FITTING AIR RESERVOIR
43
ELBOW FITTING CHECK VALVE TO AIR RESERVOIR
43
ELBOW FITTING AT OVERFLOW VALVE
49
NUT CHECK VALVE TO AIR RESERVOIR
55
O-RING CHECK VALVE TO AIR RESERVOIR
61
THRUST RING CHECK VALVE TO AIR RESERVOIR
61
THRUST RING , THE OLD PART MUST NO LONGER BE INSTALLED, Replaced By: A0009940203
64
FITTING
67
FITTING AIR RESERVOIR,CONNECTION: "13"
67
FITTING AIR RESERVOIR,CONNECTION: "2"
73
SEAL RING LINE CONNECTION
79
LINE FROM AIR RESERVOIR TO OVERFLOW VALVE
85
UNION NUT BUTT SCREW CONNECTION
91
GLAND LINE CONNECTION
97
THRUST RING BUTT SCREW CONNECTION
103
SEAL RING , Replaced By: N007603012121
109
BRACKET , Replaced By: A3184280240
115
SCREW BRACKET TO INTAKE MANIFOLD
121
LOCK WASHER RAIL TO BATTERY SUPPORT
127
NUT LEVER TO SHIFTING SHAFT
133
CLAMP , Replaced By: A3129952420
133
CLAMP LINE MOUNTING
139
SCREW CABLE TO ALTERNATOR
145
LOCK WASHER EXTENSIBLE BRAKE VALVE TO CAB
157
CLAMPING PIECE LINE MOUNTING
163
CLAMP COMPRESSED AIR LINE MOUNTING
169
SCREW CONTROL UNIT
175
LOCK WASHER PLUG SOCKET
181
NUT TACHOGRAPH TO BRACKET
187
CONNECTION FITTING , Replaced By: A0039979172
189
FITTING
189
T-FITTING CONTROL UNLOCKING MECHANISM HIGHPRESSURE HOSE TO OIL DELIVERY LINE, 415 5 014669 416 5 000516 417 4 9720245 144227, Replaced By: N000000006204
191
LINE FROM T-FITTING TO THREE-WAY VALVE
191
LINE FROM T-FITTING TO THREE-WAY VALVE
191
LINE FROM T-FITTING TO THREE-WAY VALVE
191
LINE FROM T-FITTING TO THREE-WAY VALVE
193
LINE FROM AIR RESERVOIR TO DOUBLE FITTING
193
LINE FROM AIR RESERVOIR TO DOUBLE FITTING 6X0.7 MM
199
LINE FROM DOUBLE FITTING TO THREE-WAY VALVE
205
UNION NUT
211
GLAND , Replaced By: A0019901667
212
LINE700 MM
214
BUSHING , Replaced By: N915062004000
214
SLEEVE LEAK LINE
215
UNION NUT
216
GLAND , Replaced By: A0019901667
217
VALVE , Replaced By: A0029975836
217
VALVE , Replaced By: A0039971736
223
REPAIR KIT , Replaced By: A0024302260
223
REPAIR KITTO 003 997 14 36,WABCO 472 123 19 80
229
CONNECTOR SOLENOID VALVE,CONNECTION: "2" TOA388 997 81 36 / 88 36
235
FITTING LINE CONNECTION, Replaced By: N000000006446
235
SCREW-IN FITTING LINE CONNECTION
241
SEAL RING PRESSURE CONNECTION TO AIR COMPRESSOR
247
BRACKET THREE-WAY VALVE
248
ELBOW FITTING AT CYLINDER
249
NUT LOAD/NO-LOAD VALVE,CONNECTION: "20",5 727400
250
SEALING CORD COMPRESSED-AIR-LINE PLUG-CONNECTION
251
THRUST RING , THE OLD PART MUST NO LONGER BE INSTALLED, Replaced By: A0009940103
251
THRUST RING LOAD/NO-LOAD VALVE,CONNECTION: "20",5 727400
253
SCREW 3/2-WAY VALVE TO BRACKET M8X55
259
SCREW PLUG SOCKET TO FRAME
265
WASHER TRAILER PLUG SOCKET TO BRACKET
271
NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET, Replaced By: N910113008003
278
HOSE
278
HOSE FROM THREE-WAY VALVE TO COMPRESSED AIR CYLINDER
285
UNION NUT LINE CONNECTION
291
GLAND LINE CONNECTION
297
BRACKET LINE MOUNTING
303
SCREW PLUG SOCKET TO FRAME
315
NUT
321
CLAMP LINE MOUNTING
327
SCREW , Replaced By: N304017006018
339
NUT
345
FITTING LINE CONNECTION, Replaced By: N000000006446
345
SCREW-IN FITTING LINE CONNECTION
351
SEAL RING PRESSURE CONNECTION TO AIR COMPRESSOR
519
LINE6X0.7 MM, LENGHT AVAILABLE 6000 MM
525
LINE15X1.5 MM, LENGTH AVAILABLE 3000 MM
999
CAP TO PLUG THE FREE BORES USED FOR SWITCHES IN INSTRUMENT PANEL,071184
999
EXPANSION PLUG
999
PLUG TELL-TALE LAMP
999
BUSHING , Replaced By: N915062004000
999
REPAIR KITTO 003 429 02 44
