Поз.
Артикул
Описание
18
TANK AT CAB REAR PANEL, 415 5 014668 416 5 000515 417 4 972023
21
RADIATOR CAP
24
RADIATOR CAP FILLER NECK
24
RADIATOR CAP FILLER NECK
27
BRACKET EXPANSION TANK, 415 5 014668 416 5 000515 417 4 972023
30
SCREW BRACKET TO SIDE MEMBER
32
WASHER BRACKET TO RIGHT FENDER, 415 5 014668 416 5 000515 417 4 972023
34
NUT , Replaced By: N910113010000
34
NUT STRAP TO BRACKET
40
BRACKET (STRAP), 415 5 014668 416 5 000515 417 4 972023
43
PAD FUEL TANK TO SUPPORT, ORDER BY THE METER
46
SHIM STRAP, 415 5 014668 416 5 000515 417 4 972023
49
SCREW END PIECE TO EXHAUST PIPE M 10X25
51
NUT , Replaced By: N910113010000
51
NUT STRAP TO BRACKET
53
WASHER , Replaced By: N000125010532
53
WASHER RADIATOR TO RUBBER MOUNTING
114
CONNECTOR AT WATER PUMP
116
GASKET CONNECTOR
116
GASKET CONNECTOR, Replaced By: A0002011280
116
GASKET CONNECTOR, Replaced By: A0002011180
116
GASKET CONNECTOR, Replaced By: A0002011080
116
GASKET , Replaced By: A4422010480
119
SCREW END PIECE TO EXHAUST PIPE M 10X25
119
SCREW END PIECE TO EXHAUST PIPE M 10X25
121
SPRING WASHER STEERING COLUMN BRACKET TO CAB
124
HOSE FROM WATER PUMP TO EXPANSION TANK AND TO HEATING PIPE
127
COOLING WATER PIPE FROM WATER PUMP TO EXPANSION TANK
130
HOSE FROM WATER PUMP TO EXPANSION TANK, 415 5 014668 416 5 000515 417 4 972023 FOR USE WITH SHORT MERCEDES-BENZ CAB
133
CLAMP
133
CLAMP
133
CLAMP , Replaced By: N000000000670
136
BRACKET COOLING WATER LINE TO FRAME
136
BRACKET , Replaced By: A3834929141
139
CLAMP COOLING WATER LINE TO BRACKET,5 022370
142
SCREW OIL-DIPSTICK GUIDE TUBE TO BRACKET
142
SCREW , Replaced By: N304017008016
145
HEXAGON NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET
145
NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET, Replaced By: N910113008003
145
NUT , Replaced By: N913004008001
148
BRACKET DELIVERY AND SUCTION LINES TO ENGINE, FRONT
151
CLAMP COOLING WATER LINE TO BRACKET,5 022370
154
SCREW PIPE CLAMP
154
SCREW , Replaced By: N304017008021
156
HEXAGON NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET
156
NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET, Replaced By: N910113008003
156
NUT , Replaced By: N913004008001
159
FLANGE HEATING AND BREATHING, 415 5 014668 416 5 000515 417 4 972023
162
GASKET. SEAL DE-AERATION PIPE TO ENGINE
165
SCREW END PIECE TO EXHAUST PIPE M 10X25
167
LOCK WASHER BRACKET TO SUPPORT AND TO END PIECE
169
BRACKET ENGINE CABLE HARNESS PLUG-CONNECTION,5 452356
169
BRACKET ENGINE CABLE HARNESS PLUG-CONNECTION,5 452356
171
CLAMP COOLING WATER LINE TO FIRE WALL
171
CLAMP COOLING WATER LINE TO FIRE WALL
171
CLAMP FEED LINE TO THERMOSTAT
173
SCREW COVER PLATE TO BRACKET
175
NUT PUMP TO BRACKET
175
NUT , Replaced By: N913004006001
177
HOSE FROM ENGINE CONNECTION FLANGE TO HEATING PIPE AT RADIATOR, 415 5 014668 416 5 000515 417 4 972023
180
CLAMP , Replaced By: N000000000667
180
CLAMP HOSE TO SUCTION LINE AND TO OIL TANK 20-32X13 MM
183
LINE HEATING,MOUNTED TOGETHER WITH RADIATOR AT RUBBER BUFFER, 415 5 014668 416 5 000515 417 4 972023
189
HOSE FROM HEATING PIPE AT RADIATOR TO CAB HEATING PIPE
192
CLAMP , Replaced By: N000000000667
192
CLAMP HOSE TO SUCTION LINE AND TO OIL TANK 20-32X13 MM
195
HOSE , Replaced By: A3635060235
195
HOSE FROM ENGINE CONNECTION FLANGE TO HEATING PIPE AT RADIATOR,5 534803
197
CLAMP INTERMEDIATE PIPE TO PARTICLE FILTER
197
CLAMP25-40X13 MM
200
CLAMP , Replaced By: N000000000667
200
CLAMP HOSE TO SUCTION LINE AND TO OIL TANK 20-32X13 MM
203
HOSE VENTILATION, FROM RADIATOR TO EXPANSION TANK, 415 5 014668 416 5 000515 417 4 972023
206
BREATHER PIPE VENTILATION, FROM RADIATOR TO EXPANSION TANK, 415 5 014668 416 5 000515 417 4 972023 FOR USE WITH SHORT MERCEDES-BENZ CAB
206
BREATHER PIPE VENTILATION, FROM RADIATOR TO EXPANSION TANK, 415 5 014668 416 5 000515 417 4 972023 FOR USE WITH SHORT MERCEDES-BENZ CAB
210
HOSE PRESSURE REGULATOR,ANTI-FREEZE DEVICE, ORDER BY THE METER
214
CLAMP , Replaced By: N000000000667
214
CLAMP HOSE TO SUCTION LINE AND TO OIL TANK 20-32X13 MM
218
BREATHER PIPE FROM ENGINE TO EXPANSION TANK, 415 5 014668 416 5 000515 417 4 972023
220
HOSE PRESSURE REGULATOR,ANTI-FREEZE DEVICE, ORDER BY THE METER
220
HOSE PRESSURE REGULATOR,ANTI-FREEZE DEVICE, ORDER BY THE METER
223
CLAMP , Replaced By: N000000000667
223
CLAMP HOSE TO SUCTION LINE AND TO OIL TANK 20-32X13 MM
223
CLAMP HOSE TO SUCTION LINE AND TO OIL TANK 20-32X13 MM
227
BRACKET RADIATOR AND ENGINE BREATHING,AT ENGINE,4 635938
228
BRACKET FUEL LINE TO BELL HOUSING
230
BRACKET RADIATOR AND ENGINE BREATHING,AT ENGINE,4 367399 FOR USE WITH MERCEDES-BENZ CAB4 635938
231
BRACKET , Replaced By: A3524290740
231
BRACKET DELIVERY AND SUCTION LINES TO ENGINE, FRONT, TO BE ADAPTED DURING ASSEMBLY
236
SCREW EXHAUST PIPE TO BRACKET
239
WASHER , Replaced By: N000125010532
239
WASHER RADIATOR TO RUBBER MOUNTING
241
NUT , Replaced By: N910113010000
241
NUT STRAP TO BRACKET
245
CLAMP , Replaced By: N916016011202
245
CLAMP AT BRACKET
248
CLAMP OIL-DIPSTICK GUIDE TUBE TO BRACKET
251
SCREW , Replaced By: N304017008016
251
SCREW OIL-DIPSTICK GUIDE TUBE TO BRACKET
254
NUT , Replaced By: N913004008001
254
NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET, Replaced By: N910113008003
254
HEXAGON NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET
999
TANK ON RADIATOR
999
DRAIN PIPE EXPANSION TANK
999
GASKET O.D., 52 MM
999
GASKET O.D., 37 MM
999
RADIATOR CAP CENTRAL
999
RADIATOR
999
CLIP CABLE HARNESS TO ROOF RAIL
999
HOSE , Replaced By: A0219977682
999
HOSE OVERFLOW, EXPANSION TANK
999
HOSE
999
SHIM , Replaced By: A3815010495
999
BRACKET HEATING PIPE TO FAN SHROUD BRACKET
999
CONNECTOR , Replaced By: A3875010423
999
BRACKET , Replaced By: A6454310740
999
HOSE , Replaced By: A3635060135
999
BRACKET , FIRST EXHAUST STOCK OF OLD PARTS UP TO IDENT NO. 5 121160, Replaced By: A4220100240
999
SCREW EXHAUST PIPE TO BRACKET
999
BREATHER PIPE (DE-AERATION LINE) FROM RADIATOR TO EXPANSION TANK
999
BREATHER PIPE , Replaced By: A6205010725
999
BRACKET DE-AERATION LINE TO CAB
999
BRACKET EXPANSION TANK
999
BRACKET EXPANSION TANK
999
TANK (EXPANSION TANK)
999
LINE HEATING AND BREATHING
999
LINE HEATING AND BREATHING
999
LINE (HEATING PIPE) FROM ENGINE TO HEATING PIPE AT RADIATOR
999
SHIM EXPANSION TANK TO BRACKET
999
SHIM EXPANSION TANK TO BRACKET
999
STRAP EXPANSION TANK TO BRACKET
999
STRAP EXPANSION TANK TO BRACKET
999
PIPE ELBOW , Replaced By: A6205010556
999
HOSE FROM WATER PUMP TO EXPANSION TANK AND TO HEATING PIPE
999
HOSE (DE-AERATION LINE) FROM RADIATOR TO EXPANSION TANK
999
HOSE , Replaced By: A6205012882
999
HOSE FROM HEATING PIPE AT RADIATOR TO CAB HEATING PIPE
999
BRACKET HEATING PIPE
999
HOSE FROM ENGINE CONNECTION FLANGE TO HEATING PIPE AT RADIATOR
999
HOSE FROM WATER PUMP TO EXPANSION TANK
999
CLAMP IDLING ADJUSTMENT WIRE CABLE,K 147121
999
CLAMP HOSE TO RADIATOR AND TO EXPANSION TANK 12-22X13 MM
999
WASHER EXHAUST MUFFLER TO STRAP
999
SPRING WASHER , Replaced By: N000137008212
999
SPRING WASHER PROTECTIVE PLATE TO EXHAUST MUFFLER
999
SCREW , Replaced By: A4609900601
999
SCREW PLUG WATER DRAIN
999
HOSE DE-AERATION LINE, LENGTH AVAILABLE: 1000 MM
999
HOSE FROM BUBBLE SEPARATOR TO HEATING PIPE 18X27 MM, ORDER BY THE METER
999
LOCK WASHER CLAMP TO BRACKET AND TO PIPE
999
GASKET HEATING PIPE TO ENGINE
