Поз.
Артикул
Описание
55
FLEXIBLE METAL TUBE FRONT LEFT
56
COLLAR (SLIDING COLLAR)
59
CLAMP FLEXIBLE METAL TUBE TO CONNECTOR AND TO COLLAR
62
SCREW , Replaced By: N304017008028
62
SCREW FLEXIBLE METAL TUBE TO CONNECTOR AND TO COLLAR
65
NUT , Replaced By: N913004008001
65
NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET, Replaced By: N910113008003
65
HEXAGON NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET
77
BRACKET LEFT
92
SCREW FRONT SPRING REAR BRACKET TO CROSS MEMBER
92
SCREW BRACKET TO SIDE MEMBER
92
SCREW EXHAUST PIPE TO BRACKET
92
HEXAGON HEAD BOLT , Replaced By: A0029902704
92
SCREW , Replaced By: N308676012013
95
HEXAGON NUT EXHAUST PIPE TO BRACKET ON SIDE MEMBER
95
NUT BRACKET TO SIDE MEMBER
95
NUT , Replaced By: N910113010000
95
NUT , Replaced By: N910113014001
95
NUT , Replaced By: N910113012003
95
NUT STRAP TO BRACKET
98
CLAMP INTERMEDIATE PIPE TO PARTICLE FILTER
98
CLAMP , Replaced By: N071555100501
98
CLAMP INTERMEDIATE PIPE TO PARTICLE FILTER
101
SCREW , Replaced By: N304017010002
101
SCREW BRACKET TO SIDE MEMBER
104
NUT STRAP TO BRACKET
104
NUT , Replaced By: N910113010000
155
PROTECTIVE PLATE TAIL PIPE
158
CLAMP HEAT SHIELD MOUNTING
999
SCREW BRACKET TO SPRING BRACKET AND TO CROSS MEMBER,5 953233K 027550
