Поз.
Артикул
Описание
5
FUEL COOLER FUEL COOLER, R 63003820040213563003820040213 A 92107220040730 V 00000120040730
5
RADIATOR
5
RADIATOR FUEL COOLER, A 92107120040730 TO BE PROCURED FROM MBA ONLY
5
COOLER. FUEL COOLER
5
FUEL COOLER FUEL COOLER
10
MOUNTING PLATE FUEL COOLER
15
BRACKET FUEL TANK
20
BRACKET FUEL TANK
25
HEXALOBULAR BOLT BRACKET TO CONSOLE M6X16,V 224423
30
PLASTIC PIPE AERATION, ORDER BY THE METER
35
SLEEVE LINE CONNECTION
40
GLAND LINE CONNECTION
45
UNION NUT LINE CONNECTION
46
HOSE FROM FEED LINE TO FILTER 240 MM
48
HOSE CLAMP HOSE ATTACHMENT
50
HOSE FROM ACTIVATED CHARCOAL FILTER TO BREATHER LINE, FROM MODEL YEAR '98
50
HOSE AT RADIATOR 140 MM
50
HOSE FROM FEED LINE TO FILTER 240 MM
51
HOSE CLAMP HOSE ATTACHMENT
52
PLASTIC PIPE FUEL SYSTEM 6X2 MM, ORDER BY THE METER
54
HOSE
56
CONNECTION. DISTRIBUTOR
58
LOOM TIE
60
HOSE BREATHER LINE TO BREATHER VALVE 45 MM
62
FUEL LINE
62
LINE RETURN LINE,R 241684
65
HOSE FROM FEED LINE TO FILTER 240 MM
65
HOSE RETURN LINE
70
LOOM TIE
70
HOSE CLAMP HOSE ATTACHMENT
75
CLAMP RETURN LINE TO FILTER 15.5-17.5 MM
80
BRACKET
80
BRACKET FUEL LINE MOUNTING
85
BRACKET FUEL LINES TO BRACKET
90
BRACKET FUEL LINE
90
BRACKET FUEL LINE MOUNTING
100
BRACKET AT CLUTCH BELL, P 503835 R 000001
103
BRACKET HOSE TO TRANSMISSION
105
BRACKET AT INTAKE MANIFOLD
110
SCREW CONDENSER TO CHARGE AIR INTERCOOLER M6 X 12
120
CLAMP. EXTENDABLE SPACER BREATHER LINE
125
CLAMP RETURN LINE TO CLUTCH HYDRAULIC LINE
130
RUBBER BUFFER TO PLUG THE MOUNTING HOLE USED FOR GROUND CONNECTION IN CASE OF R.H.D.
135
CABLE STRAP REAR SWIVEL DOOR
140
BRACKET OIL LINES
140
CLAMP. EXTENDABLE SPACER BREATHER LINE
145
HOSE WATER DRAIN 750 MM, TO BE ADAPTED DURING ASSEMBLY
