Поз.
Артикул
Описание
5
HYDRAULIC CLUTCHFICHTEL & SACHS
8
BUSHING CONVERTER COVER
11
KEY CONVERTER HOUSING,REAR
14
SEAL RING CONVERTER HOUSING,REAR 67 MM
17
SCREW BOX COVER TO 000 553 79 01,000 553 89 01
17
SCREW , Replaced By: N000912008201
20
SPRING WASHER , Replaced By: N000137008212
20
SPRING WASHER PROTECTIVE PLATE TO EXHAUST MUFFLER
23
PISTON LOCK-UP COUPLING
26
OUTER DISC
29
CLUTCH DISC
32
THRUST WASHER
35
SCREW OUTER DISC SUPPORT TO CONVERTER COVER
38
GROOVED BALL BEARING TORSIONAL VIBRATION DAMPER
41
TURBINE WHEEL , COMPONENT PARTS NOT AVAILABLES
44
NEEDLE BEARING TORSIONAL VIBRATION DAMPER
47
BALL BEARING TORQUE CONVERTER
47
BALL BEARING TORQUE CONVERTER
50
BUSHING TORQUE CONVERTER
53
FREEWHEEL UNIT TORQUE CONVERTER
56
GUIDE WHEEL TORQUE CONVERTER
59
SCREW PLUGTO 000 553 03 05,000 553 18 05,
59
SCREW PLUG , Replaced By: N000908014009
62
SEAL RINGTO 000 553 03 05,000 553 18 05,
65
GASKET KIT CONVERTER COVER F+S
65
GASKET KIT CONVERTER F+S,014963
