Поз.
Артикул
Описание
3
HOUSING ,30 044708
8
HEAT EXCHANGER FUEL
11
SEAL INSIDE
14
GASKET ,30 044707
17
HOUSING HEAT EXCHANGER
20
SEAL RING CONNECTION FOR HOT WATER FEED
21
CONNECTOR
22
SCREW MOUNTING OF INSTRUMENT PANEL
23
COVER PLATE
26
HEXALOBULAR BOLT. SCREW
29
HEXALOBULAR BOLT LINE MOUNTING M6 X 25
41
HOSE FROM HEAT EXCHANGER TO FUEL FILTER
41
HOSE , Replaced By: A6110783581
41
HOSE , Replaced By: A6110783681
41
HOSE , Replaced By: A6110783581
74
FUEL FILTER ,30 044708 EXCEPT FOR 612.963 30 044992
74
FILTER
80
BRACKET FUEL FILTER
104
HEXALOBULAR BOLT. SCREW
116
LINE FROM FUEL FILTER TO FEED PUMP, 962 RL 30 368193 962 LL 30 37181340 062099
116
LINE FROM FUEL FILTER TO FEED PUMP, 962 RL 30 368194 962 LL 30 37181440 062100
116
LINE FROM FUEL FILTER TO FEED PUMP, 962 RL 30 368194 962 LL 30 37181440 062100
116
LINE FROM FUEL FILTER TO FEED PUMP, 962 RL 30 368193 962 LL 30 37181340 062099
118
O-RING
167
PLASTIC PIPE AERATION, ORDER BY THE METER
185
LINE LEAK LINE
185
LINE LEAK LINE, Replaced By: A6110706032
185
LINE LEAK LINE, Replaced By: A6460701132
197
INSULATING HOSE ELECTRONICS AT SUPPORT, ORDER BY THE METER
215
BANJO UNION LEAK LINE AT FUEL DISTRIBUTOR
221
SEAL RING WITH OIL BORE LOCK
227
SCREW DE-AERATION LINE TO TRANSMISSION COOLING WATER LINE
242
LINE FASTENER FUEL LINE TO WATER PUMP HOUSING
251
CLAMP
275
FUEL COOLER
281
EDGE GUARD SECTION , ORDER BY THE METER
287
HEXALOBULAR BOLT BRACKET TO BRACKET M8X16
302
HOSE COMMON-RAIL TO FUEL COOLER
302
HOSE COMMON-RAIL TO FUEL COOLER
305
HOSE CLAMP FUEL LINE TO FUEL FILTER
305
CLAMP RETURN LINE TO FILTER 15.5-17.5 MM
308
CLAMP , Replaced By: A0004760436
308
BRACKET LINE MOUNTING 11 MM
311
CLAMP6/14-15 MM
314
LOOM TIE , Replaced By: A1249972090
344
CLAMP
395
BRACKET FUEL LINE TO CYLINDER HEAD,30 044707
398
HEXALOBULAR BOLT. SCREW BRACKET TO TRANSMISSION M 6X15
