Поз.
Артикул
Описание
40
FUEL TANK , Replaced By: A3874700701
40
FUEL TANK400 L.,4 399369
56
FILLER CAP
56
FILLER CAP , Replaced By: A0004700305
56
FILLER CAP , Replaced By: A0004700305
56
FILLER CAP , Replaced By: A0004700305
56
FILLER CAP , Replaced By: A0004717930
72
SEAL RING
88
SENDER UNIT , FIRST EXHAUST STOCK OF OLD PARTS UP TO IDENT NO. K 169122, Replaced By: A0115426517, +001A0005409917
88
SENDER UNIT , Replaced By: A0085428117
104
FUEL STRAINER FUEL TANK,K 169122
120
SEAL RING FUEL GAUGE SENDER UNIT TO FUEL TANK
136
SUPPORT FRONT
136
SUPPORT FRONT
136
SUPPORT FUEL TANK TO FRAME
136
SUPPORT REAR TANK,5 758497
136
SUPPORT FUEL TANK TO FRAME
136
SUPPORT , Replaced By: A3894700242
136
SUPPORT FUEL TANK TO FRAME
136
SUPPORT FUEL TANK TO FRAME
136
SUPPORT FUEL TANK
136
SUPPORT FRONT
136
SUPPORT FUEL TANK TO FRAME
152
SCREW REAR SPRING REAR BRACKET AND STRUT TO SIDE MEMBER
152
SCREW STEERING SUPPORT TO FRAME M 14X55
152
SCREW BRACKET TO FRAME
168
NUT STEERING SUPPORT TO FRAME
168
NUT , Replaced By: N910113014000
184
LOCK WASHER BRACKET TO SIDE MEMBER,5 703114
200
SUPPORT REAR
200
SUPPORT FUEL TANK
200
SUPPORT , Replaced By: A6564701042
200
SUPPORT FUEL TANK TO FRAME
200
SUPPORT , Replaced By: A6244700442
200
SUPPORT REAR
200
SUPPORT REAR
200
SUPPORT REAR
200
SUPPORT FUEL TANK TO FRAME
200
SUPPORT FUEL TANK
200
SUPPORT FUEL TANK
200
SUPPORT REAR
200
SUPPORT REAR
200
SUPPORT REAR
216
SCREW ROD TO TRANSFER CASE M 14X65
216
SCREW , Replaced By: N308676014013
216
SCREW MOUNTING TO CONSOLE M 14X35
216
SCREW , Replaced By: N308676014008
216
SCREW STEERING SUPPORT TO FRAME M 14X55
216
SCREW CROSS MEMBER TO FRONT SPRING REAR BRACKET M 14X1.5X70
216
SCREW , Replaced By: N308676014014
216
SCREW , Replaced By: N000961014158
216
SCREW REAR SPRING REAR BRACKET AND STRUT TO SIDE MEMBER
216
SCREW BRACKET TO SIDE MEMBER M 14X1.5X50,5 543914
216
SCREW STEERING SUPPORT TO FRAME M 14X50
216
SCREW SUPPORT TO SIDE MEMBER M 14X45
216
SCREW , Replaced By: N308676014012
216
SCREW APPARATUS SUPPORT TO FRAME
216
SCREW , Replaced By: A9429901304
232
NUT STEERING SUPPORT TO FRAME
232
NUT , Replaced By: N910113014000
248
STRAP FUEL TANK TO SUPPORT
264
NUT STRAP TO SUPPORT
280
PIN STRAP TO SUPPORT
296
PAD FUEL TANK TO CONSOLE, ORDER BY THE METER
312
PAD FUEL TANK TO SUPPORT, ORDER BY THE METER
328
REINFORCEMENT REINFORCEMENT RAIL TO CONSOLE
328
REINFORCEMENT , Replaced By: A3504750126
328
REINFORCEMENT , Replaced By: A6994750726
328
REINFORCEMENT FUEL TANK SUPPORT
328
REINFORCEMENT , Replaced By: A3954750126
344
SCREW CONSOLE TO SIDE MEMBER
360
NUT SUPPORT TO SIDE MEMBER
376
WASHER
392
GROMMET LINE THRU FRAME
999
CHAIN FILLER CAP
999
PAD FUEL TANK TO CONSOLE
999
STRAP ,5 149419, Replaced By: A6204700340, +001N000934012022
999
FUEL TANK , Replaced By: A3874701301
999
SUPPORT , Replaced By: A3874703342
999
PAD FUEL TANK TO CONSOLE
999
COTTER PIN STRAP TO SUPPORT
999
SEAL RING FUEL LINE TO FEED PUMP
