Поз.
Артикул
Описание
17
FILLER CAP
17
FILLER CAP , Replaced By: A0004700305
20
SEAL RING
23
CHAIN FILLER CAP
26
FILLER CAP LESS BREATHING
26
FILLER CAP LESS BREATHING
26
FILLER CAP , Replaced By: A0004718430
29
SEAL RING
29
SEAL RING , Replaced By: A3049970340
32
KEYTO 000 471 67 30, STATE LOCK NUMBER WHEN ORDERING
35
SCREW PLUG FUEL TANK
35
SCREW PLUG , Replaced By: N007604014110
38
SEAL RING FUEL LINE TO FEED PUMP
110
SCREW BRACKET TO CAB CONSOLE M14X1.5X40
110
SCREW BRACKET TO SIDE MEMBER M 14X1.5X35
110
SCREW , Replaced By: N308676014020
125
PAD FUEL TANK TO SUPPORT, ORDER BY THE METER
125
PAD , Replaced By: A3634750220
126
PAD FUEL TANK TO SUPPORT, ORDER BY THE METER
126
PAD FUEL TANK TO CONSOLE
137
WASHER
170
FUEL STRAINER FUEL TANK,K 169123
170
FUEL STRAINER FUEL TANK,K 169122
173
SEAL RING FUEL GAUGE SENDER UNIT TO FUEL TANK
176
CONNECTOR FEED LINE AND RETURN LINE 8X1 MM
176
CONNECTOR FEED LINE AND RETURN LINE 11X1,5 MM
176
CONNECTOR FEED LINE AND RETURN LINE 12,5X1,25 MM
179
GASKET KIT CONNECTION ON FUEL GAUGE SENSOR
182
LOCK FUEL GAUGE SENDER UNIT CONNECTION
