Поз.
Артикул
Описание
128
VALVE (FOUR-CIRCUIT PROTECTIVE VALVE) KNORR,5 7999995 800000 - 5 8127305 900000 - 5 936365
128
VALVE (FOUR-CIRCUIT PROTECTIVE VALVE) GRAU,5 7999995 800000 - 5 8127305 900000 - 5 936365
128
VALVE (FOUR-CIRCUIT PROTECTIVE VALVE) WABCO
128
VALVE (FOUR-CIRCUIT PROTECTIVE VALVE) BOSCH,5 7999995 800000 - 5 8127305 900000 - 5 936365 PART IS ONLY OR ALSO SUPPLIED AS RECONDITIONED PART
131
CUPBOSCH,5 7999995 800000 - 5 8127305 900000 - 5 936365
134
SPRINGBOSCH,5 7999995 800000 - 5 8127305 900000 - 5 936365
137
VALVE
146
REPAIR KITTO 001 431 47 06,WABCO 2210, 620.415 UP TO CHASSIS 5 014668 620.416 UP TO CHASSIS 5 000515 620.417 UP TO CHASSIS 4 972023
146
REPAIR KITTO 001 431 84 06,KNORR, 620.415 UP TO CHASSIS 5 014668 620.416 UP TO CHASSIS 5 000515 620.417 UP TO CHASSIS 4 972023
149
SCREW PIPE CLAMP
149
SCREW , Replaced By: N304017008021
152
LOCK WASHER CLAMP TO BRACKET AND TO PIPE
158
T-FITTING CHECK VALVE TO RELAY VALVE
161
T-FITTING COMBINATION CYLINDER,CONNECTION: "12"
164
NUT LOAD/NO-LOAD VALVE,CONNECTIONS: "10,20"
167
NUT CHECK VALVE TO AIR RESERVOIR
170
THRUST RING , THE OLD PART MUST NO LONGER BE INSTALLED, Replaced By: A0009940203
170
THRUST RING CHECK VALVE TO AIR RESERVOIR
173
THRUST RING LOAD/NO-LOAD VALVE,CONNECTION: "20"
176
O-RING CHECK VALVE TO AIR RESERVOIR
179
SEAL RING LOAD/NO-LOAD VALVE,CONNECTION: "20"
184
SCREW. UNION SCREW LINE CONNECTION
