Поз.
Артикул
Описание
70
AIR CLEANER , Replaced By: A3080947302
70
AIR CLEANER , Replaced By: A3080947002
70
AIR CLEANERFRAM
70
AIR CLEANERMANN
70
AIR CLEANERKNECHT
75
FILTER ELEMENTTO 308 094 75 02
75
FILTER ELEMENT , Replaced By: A3080947004
75
FILTER ELEMENTTO 308 094 71 02
79
NUT
79
NUTTO 345 094 79 02,345 094 77 02
83
CYCLONE PRE-FILTER BOWL CYCLONE TO 308 094 74 02
87
SEPARATORTO 308 094 76 02
87
VALVETO 688 094 72 02, 73 02
91
SEPARATORTO 308 094 75 02
95
RETAINING RINGTO 007 094 62 02,007 094 97 02,
99
FILTER BOWLTO 007 094 62 02,007 094 97 02,
99
FILTER BOWLTO 308 094 76 02
103
LOCKTO 345 094 78 02,308 094 76 02
107
FILTER BOWLTO 308 094 73 02
111
FASTENERTO 376 090 96 01
115
NUTTO 308 094 76 02
119
NUT PARTS KIT TO 386 090 81 01
123
SWITCH
123
VACUUM BOX , Replaced By: A0000940368
123
VACUUM BOX
123
VACUUM BOX
123
SWITCH INCLUDED IN RANGE OF DELIVERY OF: TO 376 090 98 04
127
SUPPORT OIL BATH AIR CLEANER TO BRACKET AT FIRE WALL
131
SCREW , Replaced By: N304017010040
135
NUT BRACKET TO SIDE MEMBER,XB209706
139
SCREW SCREENING PLATE TO BRACKET,K 142858
143
LOCK WASHER RAIL TO BATTERY SUPPORT
147
WASHER TRAILER PLUG SOCKET TO BRACKET
151
MUD APRON
151
MUD APRON , Replaced By: A3085207081
155
SCREW BRACKET TO CROSS MEMBER 5X18
159
WASHER FUSE TO FUSE BOX
163
LOCK WASHER PLUG SOCKET
167
NUT
219
BUFFER ,627511
219
BUFFER ,627511
219
BUFFER ,627511
227
SHIM RUBBER BUFFER TO BODY
227
SHIM RUBBER MOUNTING TO BODY
231
SCREW RUBBER BUFFER TO BODY,627510
231
SCREW BRACKET TO APPARATUS SUPPORT
239
LOCK WASHER PROPELLER SHAFT TO REAR AXLES I AND II
243
SHIM RUBBER MOUNTING TO FRAME
247
SCREW CROSS MEMBER TO SIDE MEMBERS
249
NUT BRACKET TO SIDE MEMBER,XB209706
251
BUFFER , Replaced By: A3083100077
251
BUFFER REAR
255
SCREW AIR DEHYDRATOR TO BRACKET M12X1.5X25
259
LOCK WASHER SHIFT LEVER UPPER PART TO SHIFT LEVER LOWER PART
263
SHIM AT FRAME
267
SCREW SENSOR CABLE TO PROTECTIVE PLATE
271
LOCK WASHER , Replaced By: N912004010102
275
COVER AT CONSOLE,627511
279
SHEET METAL SCREW BRACKET TO CAB 4,2X13
281
SPRING WASHER CABLE TO ALTERNATOR
999
NUT , Replaced By: A3089907051
999
EDGE GUARD SECTION , Replaced By: A3097230495
999
OIL FILLER NECK ,B 848396
999
NUTTO 344 094 70 02
999
LOOM TIE , Replaced By: N916018032000
999
LOOM TIE PIPE ELBOW TO COMPRESSOR
