Поз.
Артикул
Описание
5
20
20
25
30
30
CLAMP FLEXIBLE METAL TUBE TO EXHAUST PIPE
45
HEXAGON HEAD BOLT. SCREW BRACKET MOUNTING M8 X 30
45
HEXALOBULAR BOLT CLAMP ON BRACKET M8X45
60
NUT HORN TO BRACKET M8
70
75
CLAMP INTERMEDIATE PIPE TO PARTICLE FILTER
75
80
SCREW BRACKET TO CAB REAR PANEL M 8X20
80
SCREW BRACKET TO SIDE MEMBER M8X20
90
HEXAGON HEAD BOLT BRACKET TO BRACKET M10X35
90
SCREWM 10X20
90
SCREW BRACKET TO SIDE MEMBER M10X35
95
NUT EXHAUST PIPE AND PIPE CLAMP TO BRACKET
100
SCREW BRACKET TO SIDE MEMBER M8X20
100
HEXAGON HEAD BOLT. SCREW CLUTCH TO FLYWHEEL M8X16 MM
160
160
CLAMP EXHAUST PIPE TO MUFFLER 104.5 MM
170
HEXALOBULAR BOLT BRACKET TO BRACKET M 10X30
170
HEXAGON HEAD BOLT RESONATOR TO TRANSMISSION CASE,K 138633
180
NUT EXHAUST PIPE AND PIPE CLAMP TO BRACKET
205
CLAMP TAIL PIPE TO EXHAUST MUFFLER
210
SCREW BRACKET TO SIDE MEMBER M10X35
210
HEXAGON HEAD BOLT BRACKET TO BRACKET M10X35
220
NUT EXHAUST PIPE AND PIPE CLAMP TO BRACKET
230
EXHAUST MUFFLER ROAD VEHICLE, FOR COMPONENT PARTS SEE SPARE PARTS LIST
230
EXHAUST MUFFLER CONSTRUCTION SITE VEHICLE
270
HEXAGON HEAD BOLT BRACKET TO DISTRIBUTOR
275
HEXAGON HEAD BOLT BRACKET TO SIDE MEMBER M12X1.5X35
290
NUT EXHAUST PIPE AND PIPE CLAMP TO BRACKET
295
300
305
SCREW PIPE ELBOW TO BRACKET M8X12
305
SCREW SPEED SENSOR TO REAR AXLE
310
PROTECTIVE PLATE FRONT EXHAUST MUFFLER
320
PROTECTIVE PLATE AT MUFFLER
330
NUT RETAINER PROTECTIVE PLATE TO EXHAUST MUFFLER
330
SOCKET NUT. NUT RETAINER EXHAUST MUFFLER TO SUPPORT
330
NUTM8
335
SCREW PIPE ELBOW TO BRACKET M8X12
335
SCREW SPEED SENSOR TO REAR AXLE
340
350
BRACKET EXHAUST MUFFLER TO SIDE MEMBER,FRONT, NO.7390 IIIII
370
HEXAGON HEAD BOLT. SCREW GUSSET PLATE TO FRAME M14 X 1.5 X 70
370
HEXAGON HEAD BOLT BRACKET TO SPRING SADDLE M14X1.5X110
370
HEXAGON HEAD BOLT BEARING BRACKET TO SIDE MEMBER M14X1.5X100
370
HEXAGON HEAD BOLT. SCREW SUPPORT TO FRAME M 14X1.5X90
380
NUT BATTERY/APPARATUS SUPPORT TO FRAME SIDE MEMBER
390
BRACKET EXHAUST MUFFLER TO SIDE MEMBER,REAR
405
HEXAGON HEAD BOLT. SCREW MOUNTING PARTS M 14X1.5X35
420
NUT SUPPORT TO FRAME
420
NUT BATTERY/APPARATUS SUPPORT TO FRAME SIDE MEMBER
570
600
HEXAGON HEAD BOLT BATTERY/APPARATUS SUPPORT TO FRAME SIDE MEMBER M14X1.5X40
610
NUT BATTERY/APPARATUS SUPPORT TO FRAME SIDE MEMBER
