Поз.
Артикул
Описание
224
COUNTERSHAFT
224
COUNTERSHAFT , Replaced By: A0002600224
229
GEAR 3RD AND 4TH SPEED
234
GEAR 5TH SPEED
239
GEAR 6TH SPEED,10/20879180, 50/60880936
239
GEAR , Replaced By: A0002631710
244
SPACER WASHER AS REQUIRED 4.80 MM
244
SPACER WASHER AS REQUIRED 5.00 MM,10/20879180, 50/60880936
244
SPACER WASHER AS REQUIRED 5.20 MM
244
SPACER WASHER AS REQUIRED 5.40 MM
244
SPACER WASHER AS REQUIRED 5,60 MM
244
SPACER WASHER AS REQUIRED 5.80 MM
251
CYLINDR. ROLLER BEARING COUNTERSHAFT,REAR
251
TAPERED ROLLER BEARING , Replaced By: A0099813301
251
TAPERED ROLLER BEARING , Replaced By: A0019809502
256
LOCK RING AS REQUIRED 3.20 MM
256
LOCK RING AS REQUIRED 3.10 MM
256
LOCK RING AS REQUIRED 3.00 MM
256
LOCK RING AS REQUIRED 2.90 MM
256
LOCK RING AS REQUIRED 2.80 MM
256
LOCK RING AS REQUIRED 2.70 MM
256
LOCK AS REQUIRED 2.70 MM
256
LOCK RING AS REQUIRED 2.60 MM
256
LOCK RING AS REQUIRED 2.50 MM
256
LOCK RING AS REQUIRED 2.40 MM
256
LOCK RING AS REQUIRED 2.30 MM
256
LOCK RING AS REQUIRED 2.20 MM
256
LOCK RING DRIVE GEAR
256
LOCK RING P.T.O.
256
LOCK RING AS REQUIRED 1.90 MM
261
TAPERED ROLLER BEARING REAR
261
TAPERED ROLLER BEARING , Replaced By: A0019809602
266
REVERSE IDLER GEAR
266
REVERSE IDLER GEAR , Replaced By: A0002632631
266
REVERSE IDLER GEAR , Replaced By: A0002630931
271
NEEDLE BEARING REVERSE IDLER GEAR
271
NEEDLE BEARING , Replaced By: A0109811010
271
NEEDLE BEARING , Replaced By: A0109811010
271
NEEDLE BEARING , Replaced By: A0108911010
276
BUSHING REVERSE SPEED
276
BUSHING , Replaced By: A0002630650
281
THRUST WASHER REVERSE IDLER SHAFT
286
REVERSE IDLER SHAFT
291
DRIVE SHAFT
296
CYLINDR. ROLLER BEARING MAIN SHAFT,REAR
296
CYLINDR. ROLLER BEARING , Replaced By: A0059818501
302
SNAP RING MAIN SHAFT,REAR
307
RING HALF , Replaced By: A0002620177
307
RING AS REQUIRED 7.20 MM, 11674310/50 792024, 20/60 766368
307
RING HALF , Replaced By: A0002622177
307
RING AS REQUIRED 7.10 MM
307
RING HALF , 116742, Replaced By: A0002643129, +001A0002642751
307
RING HALF , Replaced By: A0002643129
307
RING HALF , Replaced By: A0002648029
307
RING HALF AS REQUIRED 7.00 MM, 116743
307
RING HALF ,116742, Replaced By: A0002643229, +001A0002642751
307
RING HALF , Replaced By: A0002643229
307
RING HALF , Replaced By: A0012620030
307
RING HALF AS REQUIRED 6.90 MM,10/20879180, 50/60880936
307
RING HALF , 116742, Replaced By: A0002643329, +001A0002642751
307
RING HALF , Replaced By: A0002643329
307
RING HALF , Replaced By: A0002620277
307
RING AS REQUIRED 6.80 MM
307
RING HALF , 116742, Replaced By: A0002643429, +001A0002642751
307
RING HALF , Replaced By: A0002643429
307
RING HALF , Replaced By: A0002620377
307
RING AS REQUIRED 6.70 MM,10/20879180, 50/60880936
314
SPACER RING , 116742, Replaced By: A0002642751, +001A0002643129
314
SPACER RING , Replaced By: A0002642751
314
SPACER RING , 116743 DELIVER ADDITIONALLY AS REQUIRED 000 264 31 29-000 264 34 29
318
MAIN SHAFT , DELIVER ADDITIONALLY:AS RIQUIRED 1 X 003 994 14 41 - 17 41,1 X 002 994 87 41 - 88 41,1 X 001 994 88 41, Replaced By: A0002622405
318
MAIN SHAFT , DELIVER ADDITIONALLY:AS RIQUIRED 1X 003 994 14 41-1741,1X 002 994 87 41-8841,1X 001 994 88 41 WITH AK 6-90 UP TO TRANSMISSION 068147,WITH AK 6-80 UP TO TRANSMISSION 279573
318
MAIN SHAFT , DELIVER ADDITIONALLY:AS RIQUIRED 1X 003 994 14 41-1741,1X 002 994 87 41-8841,1X 001 994 88 41 ON AK 6-90 FROM TRANSMISSION 068148-190789, ON AK 6-80 FROM TRANSMISSION 279574-327508, Replaced By: A0002622305
318
MAIN SHAFT , ON AK 6-90 FROM TRANSMISSION 190790,ON AK 6-80 FROM TRANSMISSION 327509
324
NEEDLE BEARING , Replaced By: A0139819210
324
NEEDLE BEARING
324
NEEDLE BEARING , Replaced By: A0139819210
324
NEEDLE BEARING , Replaced By: A0139819210
328
GEAR 2ND SPEED
334
SYNCHRONIZER HUB , Replaced By: A0002621527
334
SYNCHRONIZER HUB 1ST AND 2ND SPEED
339
SLIDING COLLAR 1ST AND 2ND SPEED, WITH AK 6-90 UP TO TRANSMISSION 068147,WITH AK 6-80 UP TO TRANSMISSION 279573
339
SLIDING COLLAR 1ST AND 2ND SPEED, WITH AK 6-90 FROM TRANSMISSION 068148,WITH AK 6-80 FROM TRANSMISSION 279574
344
LOCK RING , Replaced By: A3872624373
344
LOCK HOLLOW SHAFT BEARING
344
LOCK AS REQUIRED 2.90 MM
344
LOCK AS REQUIRED 2.80 MM
349
NEEDLE BEARING
349
NEEDLE BEARING
349
NEEDLE BEARING
354
GEAR 1ST SPEED
359
FOLLOWER RING REVERSE SPEED
364
BUSHING REVERSE SPEED
369
NEEDLE BEARING REVERSE SPEED GEAR
374
GEAR REVERSE SPEED
379
BALL BEARING , Replaced By: N000625536314
379
GROOVED BALL BEARING DRIVE SHAFT
384
SNAP RING MAIN SHAFT,REAR
389
DRIVE GEAR SPEEDOMETER DRIVE, L.H. TURN,10/50 792024, 20/60 766368
389
DRIVE GEAR SPEEDOMETER DRIVE
394
FLANGE MAIN SHAFT OUTPUT, WITH AK 6-90 UP TO TRANSMISSION 068147,WITH AK 6-80 UP TO TRANSMISSION 279573
394
COUPLING FLANGE MAIN SHAFT OUTPUT, WITH AK 6-90 FROM TRANSMISSION 068148,WITH AK 6-80 FROM TRANSMISSION 279574
499
THRUST WASHER. SEAL RING DRIVEN FLANGE TO DRIVE SHAFT, UP TO CHASSIS 4 277882 FROM CHASSIS 4 277883 SEE MICROFICHE,MODEL 750.402
503
SCREW , Replaced By: N000933012130
503
SCREW BELL HOUSING TO CYLINDER CRANKCASE M 12X35
506
NEEDLE BEARING , Replaced By: A0129815910
506
NEEDLE BEARING FRONT,10/20879180, 50/60880936
506
NEEDLE BEARING , Replaced By: A0129815910
506
NEEDLE BEARING , Replaced By: A0129815910
509
GEAR 3RD SPEED
512
SYNCHRONIZER HUB 3RD AND 4TH SPEED
516
SLIDING COLLAR 3RD AND 4TH SPEED, WITH AK 6-90 UP TO TRANSMISSION 068147,WITH AK 6-80 UP TO TRANSMISSION 279573
516
SLIDING COLLAR REVERSE SPEED
521
SPRING
524
BALL P.T.O. SHAFT
527
LOCK AS REQUIRED 2.50 MM
527
LOCK , Replaced By: A3872626173
527
LOCK AS REQUIRED 2.40 MM
532
NEEDLE BEARING , Replaced By: A0139819110
532
NEEDLE BEARING
532
NEEDLE BEARING , Replaced By: A0139819110
532
NEEDLE BEARING , Replaced By: A0139819110
536
GEAR 4TH SPEED
540
BUSHING 5TH SPEED GEAR
543
NEEDLE BEARING
546
GEAR 5TH SPEED
549
SYNCHRONIZER HUB 5TH AND 6TH SPEED
553
SLIDING COLLAR 5TH AND 6TH SPEED, WITH AK 6-90 UP TO TRANSMISSION 068147,WITH AK 6-80 UP TO TRANSMISSION 279573
553
SLIDING COLLAR 5TH AND 6TH SPEED, WITH AK 6-90 FROM TRANSMISSION 068148,WITH AK 6-80 FROM TRANSMISSION 279574
558
SPRING MAIN SHAFT
563
BALL P.T.O. SHAFT
566
NUTTO 343 262 01 05,000 262 14 05, ON AK 6-90 FROM TRANSMISSION 190789,ON AK 6-80 FROM TRANSMISSION 327508
570
CYLINDR. ROLLER BEARING
573
LOCK RING
999
PIN SHIFTING SHAFT,10/20879180, 50/60880936
999
FOLLOWER REVERSE SPEED
999
SHIFTING FORK , Replaced By: A0002602430
999
CAP , Replaced By: A0002670214, +001A0019978490
999
COVERING SHIFT LEVER
999
GASKET , Replaced By: A0002673780
999
CAP , Replaced By: A0002670514, +001A3432640089
999
COVER , Replaced By: A0002684005, +001A0002670514, +001A0019978490
999
PIN SHIFTING SHAFT
999
CAP , Replaced By: A0002671714
999
SHIFT LEVER LOWER PART ,10/50 792025, 20/60 766369, Replaced By: A0002671002, +001A0002670514, +001A0002684005, +001A0039971990
999
SHIFT LEVER LOWER PART GEARSHIFT LEVER LOWER PART,10/50 792025, 20/60 766369
999
CAP SHIFTER COVER WITH SHIFTING PARTS
999
GASKET SHIFTER COVER WITH SHIFTING PARTS
999
SLIDE ADDITIONAL GEAR CLUSTER
999
COVER SHIFT CASE,BOTTOM,10/20879179, 50/60880935
999
GASKET , Replaced By: A3432650679
999
COVER LATERAL
999
PIN SHIFT CASE,BOTTOM
999
PIN SHIFTING SHAFT,BOTTOM
999
SPACER WASHER SHIFTING SHAFT
999
BUSHING SHIFTING DOME,TOP
999
GASKET , Replaced By: A0002685580
999
SHIFTING ROD , Replaced By: A3362600389
999
SHIFTING ROD , Replaced By: A3362680325
999
SHIFTING ROD REVERSE SPEED,10/20879179, 50/60880935
999
COVER , Replaced By: A0002685205
999
GASKET SHIFT CASE,TOP AND BOTTOM
999
COVER SHIFTER COVER WITH SHIFTING PARTS
999
SHIFTING ROD 1ST AND 2ND SPEED
999
GASKET LATERAL
999
REPAIR KIT , EXHAUST STOCK OF OLD PART NUMBERS FIRST UP TO TRANSMISSION 173083, Replaced By: A0002600296
999
WASHER SHIFTING FORK
999
SPRING SHIFTER COVER,TOP,10/20879180, 50/60880936
999
SCREW PLUG OIL FILLING, UP TO CHASSIS 4 277882 FROM CHASSIS 4 277883 SEE MICROFICHE,MODEL 750.402
999
NEEDLE BEARING SHIFT LEVER BEARING,10/50 792025, 20/60 766369
999
LOCK AS REQUIRED 2.30 MM,10/20879180, 50/60880936
999
LOCK , Replaced By: N900055045300
999
SCREW PLUG BREATHER
999
LOOM TIE , WITH AK 6-90 UP TO TRANSMISSION 068147,WITH AK 6-80 UP TO TRANSMISSION 279573
999
LOOM TIE LINE MOUNTING
999
SPACER WASHER AS REQUIRED 1.70 MM
999
SPACER WASHER AS REQUIRED 1.60 MM
999
SPACER WASHER AS REQUIRED 1.50 MM
999
SPACER WASHER AS REQUIRED 1.40 MM
999
SPACER WASHER AS REQUIRED 1.30 MM
999
SPACER WASHER AS REQUIRED 1.20 MM
999
SPACER WASHER AS REQUIRED 1.10 MM
999
SPACER WASHER AS REQUIRED 1.00 MM
999
NEEDLE BEARING , Replaced By: A0059810510
999
NEEDLE BEARING , THE OLD PART MUST NO LONGER BE INSTALLED THIS NOTE OF REPLACEMENT APPLIES ONLY TO THE ITEM LISTED OPPOSITE, Replaced By: A0002682150
999
NEEDLE BEARING SHIFTING FORK,10/20879180, 50/60880936
999
WASHER , Replaced By: N006902011100
999
SPRING SHIFTING SHAFT,10/20879180, 50/60880936
999
SPRING SHIFTING SHAFT,10/20879179, 50/60880935
999
SPRING , Replaced By: A0059933101
999
LOCK AS REQUIRED 2.40 MM,24243
999
LOCK AS REQUIRED 2.30 MM,24243
999
LOOM TIE , Replaced By: A0019978490
999
TRANSMISSION AK 6-80(HILL GEAR)1ST SPEED RATIO1:9.0,6TH SPEED RATIO1:1.0, FOR TYPE L-LK-LS 1621/1921,L/LA 1624 FOR COMPONENT PARTS,SEE SPARE PARTS LIST PART IS ONLY OR ALSO SUPPLIED AS RECONDITIONED PART
999
TRANSMISSION AK 6-80(HILL GEAR)1ST SPEED RATIO1:9.0,6TH SPEED RATIO1:1.0, FOR TYPES L-LK-LS 1621/1921 L/LA 1624 FOR COMPONENT PARTS,SEE SPARE PARTS LIST
999
NUT SPEEDOMETER
999
SPRING DETENT
999
LOCK AS REQUIRED 45X2.45 MM
999
LOCK AS REQUIRED 45X2.35 MM
999
LOCK AS REQUIRED 45X2.25 MM
