Поз.
Артикул
Описание
75
UNION SCREW , Replaced By: A0004280072
75
ROHRVERSCHRAUBUNG EM. UNION SCREW LINE MOUNTING
80
CLAMP LINE TO HOSE
82
SCREW HOSE TO BRAKE LINE
83
NUT AIR INTAKE PIPE TO AIR INTAKE PIPE,937184
85
BRACKET OIL LINE MOUNTING
90
BRAKE HOSE
90
BRAKE HOSE
90
BRAKE HOSE
99
ROHRVERSCHRAUBUNG EM. UNION SCREW LINE MOUNTING
105
BRACKET. LOCK , Replaced By: A6525040038
105
BREMSSCHLAUCHHALTER. LOCK , Replaced By: A0004280473
106
BRACKET , THE OLD PART MUST NO LONGER BE INSJTALLED, Replaced By: A3834280140
117
LINE FROM DISTRIBUTOR TO LEFT REAR WHEEL
133
ROHRVERSCHRAUBUNG EM. UNION SCREW LINE MOUNTING
999
THRUST RING BUTT SCREW CONNECTION
999
SEAL RING LINE CONNECTION
999
UNION NUT , 10/20 UP TO CHASSIS 4 191895,50/60 UP TO CHASSIS 4 189545
999
UNION NUT BUTT SCREW CONNECTION
999
LOCK WASHER BRACKET TO SUPPORT AND TO END PIECE
999
LOCK WASHER
999
LOCK WASHER CLAMP TO BRACKET AND TO PIPE
999
LOCK WASHER T-FITTING TO BRACKET
999
SCREW
999
FITTING ,4 667210
999
FITTING LINE CONNECTION
999
NUT CHECK VALVE TO AIR RESERVOIR
999
ELBOW FITTING
999
THRUST RING , Replaced By: N915065018101
999
UNION SCREW , Replaced By: A0004280072
999
SCREW PLUG AT TANK
999
SCREW PLUGROCKINGER TYP 59 G140,59 G150, Replaced By: N007604012105
999
SEAL RING LINE CONNECTION
999
SEALING RING. SEAL RING ENGINE BREATHING
999
SEAL RING
999
GLAND , Replaced By: A0019901167
999
GLAND LINE CONNECTION
999
SCREW BRACKET TO FRAME,4 439997
999
NUT TRAILER COUPLING TO FRAME
999
NUT PULL ROD
999
HEX. NUT. NUT FUEL TANK TO CONSOLE,167609
999
NUT BRACKET TO RETARDER
999
NUT , 005,006,007,011,012,021,031,106,108,FROM CHASSIS A 012137,014,016,018 FROM CHASSIS A 007627
999
NUT , Replaced By: N304032008006
999
NUT LEVER TO SHIFTING SHAFT
999
NUT BALL PIVOT TO LEVER
999
SCREW TAIL LAMP BRACKET TO FRAME M 10X28
999
SCREW , Replaced By: N304017010002
999
HEX. HEAD SCREW. SCREW ELECTRIC CABLE TO SIDE MEMBER, 032,033,040,041,132,133,140,141 FROM CAB 1606715
999
SCREW ENGINE CROSS MEMBER TO SIDE MEMBERS M 10X25
999
SCREW PRESSURE REGULATOR WITH TIRE INFLATOR CONNECTION TO SUBSTRUCTURE
999
SCREW BRACKET TO PARTITION PANEL,1.9.89 B 065822 F 122353
999
SCREW COMPRESSED AIR ELBOW
999
SCREW IGNITION COIL TO BRACKET
999
SCREW
999
SCREW
999
LOCK WASHER RAIL TO SUBSTRUCTURE
999
LOCK WASHER BRACKET TO SUPPORTING ARM
999
LOCK WASHER REINFORCEMENT ANGLE TO SIDE MEMBER, 005,006,007,011,012,021,031,106,108,FROM CHASSIS A 012137,014,016,018 FROM CHASSIS A 007627
999
LOCK WASHER , Replaced By: N912004010102
999
LOCK WASHER CLAMP TO BRACKET
999
WASHER
999
WASHER , Replaced By: N000125010532
999
WASHER , Replaced By: N000125008443
999
WASHER COMPRESSED AIR LINE TO BRACKET, Replaced By: N000125006449
999
COTTER PIN
999
COTTER PIN STRAP TO CONSOLE 20 L
999
SCREW FUEL LINE TO BRACKET
999
REPAIR KIT , Replaced By: A0015869143
999
BRAKE CYLINDER"WESTINGHOUSE", USED WITH HYDRAULIC BRAKE,345.000-008,021,024,025,033 UP TO IDENT NO. FB588185
999
WASHER , Replaced By: A4219905440
999
ROD FROM BRAKE SHAFT TO BRAKE LEVER
999
ROD FROM BRAKE SHAFT TO BRAKE LEVER
999
BUSHING
999
ELECTRIC CABLE FROM FIRE WALL TO EMERGENCY RELEASE VALVE
999
BRACKET BRAKE MASTER CYLINDER
999
LINE , Replaced By: A3514207536
999
LINE , EXHAUST STOCK OF OLD PARTS NUMBER FIRST UP TO CHASSIS:A 040614, Replaced By: A3514298901
999
ELBOW FITTING AT LEFT AND RIGHT DIAPHRAGM CYLINDERS,A 069205
999
FITTING ,A 069205
999
BRACKET BRAKE LINE COUPLING TO REAR CROSS MEMBER
999
LOCK LEVER TO BRACKET
999
BANJO UNIONTO 345 430 77 01,345 430 74 01
999
SHIM BRACKET TO SIDE MEMBER, USED WITH HYDRAULIC BRAKE,UP TO CHASSIS 588185
999
BRAKE CYLINDER , Replaced By: A3454317214
999
LEVER , Replaced By: A3444300023
999
CONNECTOR SOLENOID VALVE,CONNECTION: "2" TOA388 997 81 36 / 88 36
999
HOLLOW SCREW , Replaced By: A3454287126
999
HOSE , Replaced By: A3769978182
999
REPAIR KIT , Replaced By: A3144200092
999
CLAMP
999
PLATE , Replaced By: A3145860142
999
PAWL , Replaced By: A3145860142
999
STRAINER
999
DRUCKFEDER. SPRING , Replaced By: A3145860142
999
BREATHER TRANSFER CASE
999
BRAKE MASTER CYLINDER , Replaced By: A0454300201
999
FILLER CAPTO 345 430 74 01
999
SEAL RINGTO 000 431 21 14,BOSCH, WITH BOSCH CHARACTERISTIC NUMBER 723
999
HOSE , Replaced By: A0089976082
999
SEAL RING
999
SPRINGTO 000 431 21 14
999
PISTON
999
SPRINGTO 000 431 21 14
999
CUP , Replaced By: A3454317286
999
PISTONTO 345 431 00 14
999
RESERVOIRTO 045 430 02 01,345 430 74 01
999
WASHER , Replaced By: A3454317376
999
WASHER , Replaced By: A3454317076
999
LOCK , Replaced By: A3454317194
999
RODTO 345 431 00 14
999
PROTECTIVE CAPTO 345 431 00 14
999
VALVE DISCTO 345 431 00 14
999
NUTTO 345 431 00 14
999
FILTER BOTTOMTO 345 431 00 14
999
FITTINGTO 002 430 31 01,044 430 02 01, 058 USED WITH HYDRAULIC BRAKE, UP TO CHASSIS 589554
999
SEAL RING
999
SEAL RINGTO 000 431 24 14
999
REPAIR KIT PRESSURE RATIO VALVE
999
BRAKE MASTER CYLINDER
999
BRAKE MASTER CYLINDER FRONT/REAR BRAKE CIRCUIT
999
VALVE
999
SPRINGTO 000 429 63 44,000 429 59 44
999
REPAIR KIT
999
SPRING , Replaced By: A0014316493
999
CUP , Replaced By: A0004312786
999
PRESSURE REGULATOR , Replaced By: A0024313406
999
BRAKE MASTER CYLINDER , Replaced By: A3454307501
999
THRUST RING CHECK VALVE TO AIR RESERVOIR
999
CAPTO 001 431 71 14
999
O-RING CHECK VALVE TO AIR RESERVOIR
999
REPAIR KIT , Replaced By: A0034304381
999
VALVE DISCTO 000 429 48 30
999
CUP , WITH BOSCH CHARACTERISTIC NUMBER 723, Replaced By: A0004312786, +001A0004318583
999
PRESSURE REGULATORBOSCH,4 208907 PART IS ONLY OR ALSO SUPPLIED AS RECONDITIONED PART
999
PROTECTIVE CAPTO 000 431 24 14
999
PISTONTO 000 431 21 14,BOSCH
999
CUP , Replaced By: A0015864342
999
PISTONTO 001 430 99 01, UP TO CHASSIS 47018
999
CUP , Replaced By: A0004319186
999
BRAKE CYLINDER , Replaced By: A0014311314
999
VALVE , Replaced By: A0014295244
999
STRAINERTO 001 430 99 01, UP TO CHASSIS 47018
999
BRAKE CYLINDER , Replaced By: A3644317014
999
RODTO 001 430 99 01, UP TO CHASSIS 47018
999
CUPTO 000 431 21 14,BOSCH, WITH BOSCH CHARACTERISTIC NUMBER 724
999
CUPTO 045 430 00 01
999
FILTER BOTTOMTO 000 431 24 14
999
SLIDETO 000 431 50 14,000 431 24 14
999
DIAPHRAGMTO 000 429 63 44
999
REPAIR KITTO 003 430 44 01
999
VALVE (OVERFLOW VALVE) WESTINGHOUSE
999
CONNECTOR OIL DELIVERY LINE
999
THRUST RING COMPRESSED AIR LINE TO AIR RESERVOIR AND TO T-FITTING
999
DIAPHRAGM
999
THRUST RING LOCKING VALVE TO TRAILER CONTROL VALVE,CONNECTION: "42"
999
DIAPHRAGM , Replaced By: A0004290745
999
SPRING RETAINERTO 000 429 63 44,000 429 59 44
999
THRUST RING , THE OLD PART MUST NO LONGER BE INSTALLED, Replaced By: A0009940203
999
DIAPHRAGMTO 344 429 73 44
999
VALVE SEAT RINGWABCO,5 433388
999
SCREWED NIPPLE. FITTING , Replaced By: A0084230084
999
SCREW FITTING (AT INTAKE). FITTING , TO TANDEM BRAKE MASTER CYLINDERS 001 430 51 01 AND 001 430 68 01
