Поз.
Артикул
Описание
5
CABLE HARNESS FRAME SIDE MEMBER
5
ELECTRICAL WIRING HARNESS . , BM375.850, WHEN ORDERING, SPECIFY THE VARIANT NUMBER XVK.. ...... FROM VEDOC STATE IDENT NO. WHEN ORDERING
5
CABLE HARNESS FRAME SIDE MEMBER
5
ELECTRICAL WIRING HARNESS FRAME SIDE MEMBER ,GLOBAL COCKPIT, BLUE TEC EURO4/5
5
ELECTRICAL WIRING HARNESS FRAME SIDE MEMBER ,GLOBAL COCKPIT, BLUE TEC EURO4/5
5
CABLE HARNESS FRAME SIDE MEMBER
7
ELECTRIC CABLE TWISTED 4X1MM2, ORDER BY THE METER
7
ELECTRIC CABLE WITH CASING 2X2.5 + 2X1MM2, ORDER BY THE METER
7
ELECTRIC CABLE TWISTED 3X0.75MM2, ORDER BY THE METER
7
ELECTRIC CABLE TWISTED 2X1MM2, ORDER BY THE METER
7
ELECTRIC CABLE WITH CASING 4X1MM2, ORDER BY THE METER
8
RECEPTACLE HOUSING. PIN BUSHING HOUSING 18-POLE,GREY X1,X2,X3, ST1,ST2, INEVENT OF REPAIR, REPLACE CONNECTOR COMPLETELY
11
CONTACT BUSHING LESS DETENT,BUT WITH CATCH FOR HOUSING 0.5-1.0 MM2
11
CONTACT BUSHING LESS DETENT,BUT WITH CATCH FOR HOUSING 1.0-2.5 MM2
14
PLUG HOUSING PLUG CONNECTION,WIRING HARNESS FOR DRIVER + CO-DRIV. DOOR/INSTR. SUPPORT X22,X23, 18PIN
17
FLAT PLUG LESS DETENT,BUT WITH CATCH FOR HOUSING 1.0-2.5 MM2
17
FLAT PLUG LESS DETENT,BUT WITH CATCH FOR HOUSING 0.5-1.0 MM2
20
PIN BUSHING HOUSING PLUG CONNECTION,WIRING HARNESS FOR ENGINE/INSTRUMENT SUPPORT X2.4, 2PIN
23
CONTACT SPRING LESS DETENT,BUT WITH CATCH FOR HOUSING 0.5-1.0 MM2
23
FEMALE CONTACT. CONTACT SPRING4.0 MM2
23
CONTACT SPRING LESS DETENT,BUT WITH CATCH FOR HOUSING 4.0-6.0 MM2
23
CONTACT SPRING1-2.5 MM2
26
PLUG HOUSING PLUG CONNECTION,WIRING HARNESS FOR ENGINE/INSTRUMENT SUPPORT X2.4, 2PIN
29
FLAT PLUG TERMINAL. FLAT PLUG LESS DETENT,BUT WITH CATCH FOR HOUSING 4.0-6.0 MM2
32
PARTS KIT FUEL GAUGE SENDER UNIT, THIS CABLE HARNESS IS A COMPONENT OF FRAME MOUNTED CABLE HARNESS ASSEMBLY AND CAN BE MADE AVAILABLE AS A SPARE ATTENTION: WHEN PLACING ORDERS, PLEASE QUOTE VEHICLE IDENT NO. ONLY IF FRAME MOUNTED CABLE HARNESS IS REQUIRED AS AN ASSEMBLYK 171434
35
PLUG SOCKET BRANCH-OFF TO FUEL GAUGE SENDER UNIT
38
ROUND PIN BUSHING0.5-1.0 MM2
38
WIRE SEAL GREY 0.5-1.0 MM2
38
GASKET. BLIND PLUG
38
CORE BUNDLE SEALING1.0-2.5 MM2
38
CONTACT SPRING. CONTAKT SOCKET BRANCH-OFF TO FUEL GAUGE SENDER UNIT 1.0 - 2.5 MM2
41
BOOT 180 DEGREE OUTLET FOR CORRUGATED TUBE NW 8.5 GGVS
54
PARTS KIT FUEL GAUGE SENDER UNIT, THIS CABLE HARNESS IS A COMPONENT OF FRAME MOUNTED CABLE HARNESS ASSEMBLY AND CAN BE MADE AVAILABLE AS A SPARE ATTENTION: WHEN PLACING ORDERS, PLEASE QUOTE VEHICLE IDENT NO. ONLY IF FRAME MOUNTED CABLE HARNESS IS REQUIRED AS AN ASSEMBLYK 171434
56
PLUG SOCKET BRANCH-OFF TO FUEL GAUGE SENDER UNIT
59
ROUND PIN BUSHING0.5-1.0 MM2
59
WIRE SEAL GREY 0.5-1.0 MM2
59
CONTACT SPRING. CONTAKT SOCKET BRANCH-OFF TO FUEL GAUGE SENDER UNIT 1.0 - 2.5 MM2
59
GASKET. BLIND PLUG
59
CORE BUNDLE SEALING1.0-2.5 MM2
62
BOOT PLUG-IN CONNECTION,FUEL GAUGE SENSOR
62
BOOT 90 DEGREE OUTLET FOR CORRUGATED TUBE NW 8.5 GGVS
67
TS SOCKET PARTS KIT. PARTS KIT PRESSURE SENDER UNIT 7 PIN, TO BE ADAPTED DURING ASSEMBLY
68
SOCKET HOUSING. PLUG SOCKET 7-POLE
71
ROUND PIN BUSHING LESS DETENT,BUT WITH CATCH FOR HOUSING 0.5.1.0 MM2
71
WIRE SEAL
71
GASKET. BLIND PLUG
71
ROUND PIN BUSHING LESS DETENT,BUT WITH CATCH FOR HOUSING 1.0-2.5 MM2
71
CORE BUNDLE SEALING. WIRE SEAL WITHE 1.0-2.5 MM2, PIN 57 - 62
74
BOOT 90 DEGREE OUTLET FOR CORRUGATED TUBE NW 8.5 GGVS
74
BOOT PLUG-IN CONNECTION,FUEL GAUGE SENSOR
75
BOOT TO PLUG DUMPER PLATFORM CONTROL CONNECTION
76
PIN BUSHING HOUSING BIPOLAR
77
PIN BUSHING WITH DETENT AND WITH CATCH FOR HOUSING 0.5-1.0 MM2
77
FEMALE DISCONNECT WITH DETENT AND WITH CATCH FOR HOUSING 2.5-4.0 MM2
77
PIN BUSHING WITH DETENT AND WITH CATCH FOR HOUSING 4-6 MM2
77
PIN BUSHING WITH DETENT AND WITH CATCH FOR HOUSING 2.5 MM2
77
PIN BUSHING WITH DETENT AND WITH CATCH FOR HOUSING 2.5-4.0 MM2, Replaced By: A0009827926
85
ELECTRIC CABLE (SENSOR CABLE) BRAKE WEAR INDICATOR, FRONT,AXLE,RIGHT 1000 MM,2 083115
85
ELECTRICAL CABLE (SENSOR CABLE) BRAKE WEAR INDICATOR, FRONT AXLE,LEFT 1350 MM,2 083116 TO BE ADAPTED DURING ASSEMBLY
90
SEAL RING12.0X2.0 MM
92
BOLT. SCREW LINE MOUNTING
95
ELECTRIC CABLE SPECIAL LINE FOR ABS, REAR AXLE LEFT
95
ELECTRIC CABLE (SENSOR CABLE) BRAKE WEAR INDICATOR, REAR,AXLE RIGHT
95
ELECTRIC CABLE SPECIAL LINE FOR ABS,FRONT AXLE RIGHT
95
ELECTRIC CABLE (SENSOR CABLE) BRAKE WEAR INDICATOR, REAR, AXLE, LEFT
95
ELECTRIC CABLE (SENSOR CABLE) BRAKE WEAR INDICATOR, FRONT,AXLE,RIGHT
95
ELECTRIC CABLE (SENSOR CABLE) BRAKE WEAR INDICATOR, REAR,AXLE RIGHT 1250 MM,2 083115
95
ELECTRIC CABLE SPECIAL LINE FOR ABS,FRONT AXLE LEFT
95
ELECTRIC CABLE SPECIAL LINE FOR ABS, REAR AXLE RIGHT
95
ELECTRICAL CABLE (SENSOR CABLE) BRAKE WEAR INDICATOR, REAR,AXLE RIGHT 1500 MM,2 083116 TO BE ADAPTED DURING ASSEMBLY
95
ELECTRIC CABLE (SENSOR CABLE) BRAKE WEAR INDICATOR, FRONT AXLE,LEFT
100
O-RING. SEAL RING BRAKE WEAR SENSOR,HIGHLY FLEXIBLE, ORANGE 10.0X2.0, 3PIN
100
SEAL RING ENGINE SPEED SENSOR, ORANGE 9.25X1.8, 2PIN
100
O-RING. SEAL RING BRAKE WEAR SENSOR,HIGHLY FLEXIBLE, BLACK 9.5X1.8, 3PIN
100
SEAL RING ENGINE SPEED SENSOR, BLACK 10.0X2.0, 2PIN
110
BRACKET SENSOR LINE MOUNTING
120
ELECTRIC CABLE CAB LOCKING MECHANISM
