Поз.
Артикул
Описание
5
CABLE HARNESS , Replaced By: A6555407005, +001A9425400136
5
CABLE HARNESS CAB MAIN CABLE HARNESS, FROM IDENT NO. K 074703ALSO INSTALLED ON K 062141K 157828
5
CABLE HARNESS TACHOGRAPH, DIESER LEITUNGSSATZ IST EIN TEIL DES KOMPLETTEN VARIANTENLEITUNGSSATZES UND KANN ALS ERSATZTEIL GELIEFERT WERDEN ACHTUNG: NUR WENN EIN KOMPLETTER VARIANTENLEITUNGSSATZ BENOETIGT WIRD,IST ER UNTER ANGABE DER IDENT-NR. ZU BESTELLEN
8
BRACKET ELECTRIC CABLE THRU CAB FLOOR
11
SEAL ELECTRIC CABLE THRU CAB FLOOR
14
SEAL RING ELECTRIC CABLE THRU CAB FLOOR
17
SHEET METAL SCREW ELECTRIC CABLE THRU CAB FLOOR
17
TAPPING SCREW BRACKET TO CAB FLOOR
20
WASHER , Replaced By: N009021005205
23
LOCK ELECTRIC CABLE THRU CAB FLOOR
38
SCREW BRACKET MOUNTING M 6X20
41
LOCK WASHER CONTROL LEVER TO INJECTION PUMP LEVER
44
WASHER COMPRESSED AIR LINE TO BRACKET, Replaced By: N000125006449
47
SWITCH STOP LIGHT
50
TOOTHED WASHER STOP LIGHT SWITCH TO PEDAL BEARING BRACKET
53
NUT SWITCH
56
SWITCH PRESSURE SWITCH
68
SWITCH,AUTOMATIC (ENGINE-SPEED SWITCH),K 041930
71
NUT CONTROL UNIT TO APPARATUS PANEL
71
NUT TWO-WAY VALVE TO BRACKET
74
SWITCH EXHAUST BRAKE,K 004388
77
NUT SUCTION LINE TO OIL PUMP
80
SERRATED WASHER EXHAUST BRAKE FOOT-OPERATED SWITCH
83
WASHER EXHAUST BRAKE FOOT-OPERATED SWITCH
86
BOOT EXHAUST BRAKE,K 004388
92
SHEET METAL SCREW CABLE MOUNTING IN CABLE DUCT, NOT USED
98
RUBBER RING ELECTRIC CABLE TO CABLE DUCT
107
CABLE HARNESS FROM CHASSIS/CAB PLUG CONNECTION TO CONSTANT THROTTLE SOLENOID VALVE,5 923012K 040530
999
ELECTRIC CABLE , USED WITH MERCEDES-BENZ PLATFORM, Replaced By: A6585405627
999
ELECTRIC CABLE ,K 157828, Replaced By: A6555403736
