Поз.
Артикул
Описание
91
PUMP (HAND PUMP) WEBER
91
PUMP , Replaced By: A0005537901
97
PUMP (HAND PUMP) POWER PACKER,4 733732
100
LEVERTO 000 553 37 01,000 553 39 01,WEBER
103
PISTONTO 000 553 39 01,WEBER
103
PISTONTO 000 553 23 01,000 553 37 01,
109
VALVETO 000 553 23 01,000 553 37 01,
109
VALVETO 000 553 39 01,WEBER
115
SEAL RINGTO 000 553 23 01,000 553 37 01,
118
BUSHINGTO 000 553 37 01,000 553 39 01,WEBER
121
SEAL RINGTO 000 553 23 01,000 553 37 01,
127
CLAMPING SLEEVE4X28 MM,TO 000 553 23 01,,4 250876
133
CLAMPING SLEEVE4X12 MM,TO 000 553 23 01,
139
SCREW
139
SCREW , Replaced By: N000000000190
145
LOCK WASHER CLAMP TO BRACKET AND TO PIPE
148
GASKETTO 000 553 23 01,000 553 37 01,
151
FILTER
157
BOOTTO 000 553 23 01,000 553 37 01,
163
SEAL RINGTO 000 553 23 01,000 553 37 01,,4 250876
169
SEAL RINGTO 000 553 23 01,000 553 37 01,
175
SEAL RINGTO 000 553 37 01,000 553 39 01,WEBER,4 250876
178
GASKET KIT HAND PUMP TO 000 553 37 01,000 553 39 01,WEBER
178
GASKET KIT , Replaced By: A0005502583
178
GASKET KIT HAND PUMP
181
REPAIR KIT HAND PUMP TO 000 553 65 01,000 553 69 01,
181
REPAIR KIT , Replaced By: A0005502355
181
REPAIR KIT , Replaced By: A0005530880
193
BRACKET HAND PUMP
199
SCREW BRACKET TO SIDE MEMBER
199
SCREW , Replaced By: N304017010002
205
NUT STRAP TO BRACKET
205
NUT , Replaced By: N910113010000
210
SCREW. HEXAGON HEAD BOLT , Replaced By: N910143008005
210
SCREW BRACKET TO SIDE MEMBER
210
SCREW , Replaced By: N304017008040
210
HEXALOBULAR BOLT. SCREW MANUAL PUMP BRACKET TO FENDER BRACKET
304
BRACKET AT CAB SIDE MEMBER
402
BRACKET HIGH PRESSURE HOSE TO CAB
406
RIVET , NOT USED
410
LINE FROM FITTING TO VALVE 6X1 MM, LENGTH AVAILABLE 3000 MM
414
UNION NUT
418
SEAL CONE
418
GLAND , Replaced By: A0019901667
422
ELBOW FITTING CAB FLOOR
426
NUT OIL LINE TO FRAME
430
WASHER
999
FITTED WASHER
999
LOCK RING
999
SCREW
999
SCREW OIL FILLING TO 000 553 89 01
999
PISTONTO 000 553 79 01,WEBER
999
GUIDEWEBER
999
GUIDETO 001 553 49 05
999
FITTINGWEBER,TO 001 553 35 05
999
SCREWTO 000 553 65 01,000 553 69 01,
999
GASKET KIT HYDRAULIC CYLINDER WEBER
