Поз.
Артикул
Описание
5
STEERING BRACKET
5
STEERING SUPPORT (STEERING BRACKET)
5
STEERING SUPPORT (STEERING BRACKET),5 426402
5
STEERING BRACKET
8
PIN
11
SCREW , Replaced By: N308676016013
11
SCREW BEARING BRACKET TO REAR AXLE M 16X1.5X40
11
SCREW TRAILER COUPLING TO REAR CROSS MEMBER
14
NUT , Replaced By: N910113016001
14
NUT CONSOLE TO SUPPORT
20
SCREW , Replaced By: N308676016007
20
SCREW BEARING BRACKET TO REAR AXLE M 16X1.5X50
20
SCREW TRAILER COUPLING TO REAR CROSS MEMBER
32
PITMAN ARM ,5 426402
32
PITMAN ARM ,5 426402
32
PITMAN ARM ,5 426401
32
PITMAN ARM ,5 426401
35
NUT PITMAN ARM TO STEERING BOX ASSEMBLY
35
NUT PITMAN ARM TO STEERING BOX ASSEMBLY
38
DRAG LINKEHRENREICH,5 426401
38
DRAG LINKEHRENREICH,5 426401
38
DRAG LINKLEHMFOERDER,5 426402
38
DRAG LINK , Replaced By: A6754602605
38
DRAG LINK , Replaced By: A6754602705
38
DRAG LINK , Replaced By: A6754603205
38
DRAG LINK , Replaced By: A6754603305
38
DRAG LINKEHRENREICH,5 426402
38
DRAG LINKLEMFOERDER,5 426401
38
DRAG LINKEHRENREICH,5 426402
38
DRAG LINKLEMFOERDER,5 426402
38
DRAG LINKLEMFOERDER,5 426401
41
BOOT FIXED PART OF JOINT
41
BOOT , THIS NOTE OF REPLACEMENT APPLIES ONLY TO THE ITEM LISTED OPPOSITE, Replaced By: A0003300885
41
BOOT FIXED PART OF JOINT
44
DRAG LINK END ,K 055088
44
DRAG LINK END , THE OLD PART MUST NO LONGER BE INSTALLED, Replaced By: A0004602648
44
DRAG LINK END , Replaced By: A0004602748
44
DRAG LINK END TO BE SCREWED INTO DRAG LINK EHRENREICH
47
BOOT SCREWED PART OF JOINT
50
CLAMP DRAG LINK END TO DRAG LINK EHRENREICH
53
SCREW , Replaced By: N308676012017
53
HEXAGON HEAD BOLT. SCREW CLAMP TO DRAG LINK
59
NUT DRAG LINK TO LEVER,4 215305
59
NUT DRAG LINK TO STEERING ARM AND PITMAN ARM
62
COTTER PINROCKINGER TYP 260 G140
