Поз.
Артикул
Описание
5
SHIFTING SHAFT
8
ROLLER SHIFTING SHAFT
14
WASHER SHIFTING SHAFT
14
SPACER RING SHIFTING SHAFT
14
WASHER , Replaced By: A0002671176
17
SHIFTING SEGMENT , Replaced By: A0002672446
17
SHIFTING SEGMENT SHIFTING SHAFT
20
FOLLOWER SHIFTING SHAFT
20
FOLLOWER , Replaced By: A0002670043
23
SHIFTING SEGMENT SHIFTING SHAFT
26
DOWEL PIN SHIFTING SEGMENT
29
SHIFTING SEGMENT SHIFTING SHAFT
32
PIN SHIFTING SHAFT
35
SPRING REAR SHIFTING ROD
38
SHIFTING SEGMENT SHIFTING SHAFT
41
SCREW SHIFTING SEGMENT TO SHIFTING SHAFT
44
NUT CAB FLOOR
44
NUT , Replaced By: N308675012000
47
SPACER WASHER SHIFTING SHAFT
50
LOCK SHIFTING SHAFT
53
SPACER WASHER SHIFTING SHAFT
56
SPRING SHIFTING SHAFT
59
SPRING SHIFTING SHAFT
62
SPACER WASHER SHIFTING SHAFT
65
WASHER SHIFTING SHAFT
68
SLOTTED GATE SHIFTING SHAFT
71
COVER SHIFT LEVER TO TRANSMISSION
74
LEVER SHIFT LEVER
77
SCREW SHIFTING ROD TO JOINT
80
NUT
80
NUT , Replaced By: N304032010002
83
JOINT FROM SHIFTING ROD TO CONNECTOR
86
HEXAGON NUT
86
NUT , Replaced By: A0002680472
86
NUT , Replaced By: N913004010010
86
NUT , Replaced By: N910113010002
89
CONNECTOR BRACING
92
NUT BRACKET TO SIDE MEMBER,K 035196
92
NUT , Replaced By: N308673014001
95
JOINT , Replaced By: A0002686189
95
JOINT TOP
95
BALL JOINT UPPER PULL ROD
98
NUT BRACKET TO TELESCOPIC TUBE,K 142858
101
SCREW , Replaced By: N308676014008
101
SCREW MOUNTING TO CONSOLE M 14X35
104
SPRING WASHER BEARING BRACKET TO SIDE MEMBER,4 207081
107
PULL ROD SHIFTING TRANSFER, TO BE ADAPTED DURING ASSEMBLYK 142858
110
NUT PULL ROD
113
NUT STRAP TO SUPPORT,5 149419
116
JOINT BOTTOM
116
JOINT , Replaced By: A0002686389
122
NUT BRACKET TO TELESCOPIC TUBE,K 142858
125
BEARING COVER SHIFTING DOME
128
GASKET SHIFTING SHAFT
128
GASKET , Replaced By: A0002672480
134
SCREW , Replaced By: N304017008034
134
SCREW BRACKET TO CROSS CONNECTION STRUT
146
SEAL RING SHIFTING SHAFT
149
BOOT SHIFTING SHAFT
152
COVER SHIFT CASE,SIDE
155
GASKET SHIFT CASE,SIDE
155
GASKET , Replaced By: A0002673080
158
SCREW , Replaced By: N304017008034
158
SCREW BRACKET TO CROSS CONNECTION STRUT
164
SPRING WASHER PROTECTIVE PLATE TO EXHAUST MUFFLER
164
SPRING WASHER , Replaced By: N000137008212
167
INTERLOCK PIN , Replaced By: A0002670148
167
INTERLOCK PIN SHIFT CASE,SIDE
170
SPRING SHIFT CASE,SIDE
173
SPRING SHIFT CASE,SIDE
176
SPRING SHIFT CASE,SIDE
179
PIN SHIFT CASE,SIDE
182
SCREW PLUG
185
SEAL RING SWITCH TO CASE COVER
188
ROLLER SHIFTING SHAFT
188
ROLLER , Replaced By: A0002670368
191
SPRING SHIFT CASE,SIDE
194
BUSHING SHIFTING SHAFT
197
COVER , 717.214 009286 717.210-213,219 TO 620 260 45 03,620 260 47 00,620 260 48 00,620 260 49 00,620 260 78 00,620 260 45 00 717.220-223,229 TO 620 260 86 00,620 260 28 01, Replaced By: A0002671822, +001A0002670442, +001A0002672380, +001A0009915860, +002N914126008054
197
COVER , Replaced By: A0002672222, +002N000933008153
197
COVER SHIFT CASE,BOTTOM
200
GASKET , Replaced By: A0002672880
200
GASKET SHIFT CASE,BOTTOM
203
SCREW 3/2-WAY VALVE TO BRACKET M 8X105
206
SPRING WASHER PROTECTIVE PLATE TO EXHAUST MUFFLER
206
SPRING WASHER , Replaced By: N000137008212
209
THREADED BUSHING NEUTRAL POSITION
212
PLATE TRANSMISSION CASE BOTTOM COVER
215
SEAL RING NEUTRAL POSITION
215
GASKET VALVE TO TRANSMISSION
215
GASKET , Replaced By: A0002672380
218
SCREW , Replaced By: N304017008021
218
SCREW PIPE CLAMP
221
DOWEL PIN , Replaced By: A0009916360
221
DOWEL PIN SHIFT CASE
221
DOWEL PIN SHIFT CASE,SIDE, 717.214,215,216,217 009287 717.210-213,219 ZU 620 260 41 03,620 260 42 03,620 260 44 03,620 260 45 03,620 260 46 03,620 260 48 03 717.220-223,229 TO 620 260 30 01
221
DOWEL PIN SHIFT CASE TO 620 260 17 01, 717.214 009286 717.210-213,219 TO 620 260 45 03,620 260 47 00,620 260 48 00,620 260 49 00,620 260 78 00,620 260 45 00 717.220-223,229 TO 620 260 86 00,620 260 28 01
224
SCREW PLUG SHIFT CASE
227
SEALING RING. SEAL RING
230
COVER SHIFT CASE,SIDE
230
COVER , Replaced By: A0002672622, +009N000933008145
233
GASKET , Replaced By: A0002672980
233
GASKET PLATE TO TRANSMISSION CASE
236
SCREW
239
SCREW CLAMP TO BRACKET AND TO PIPE
242
SPRING WASHER PROTECTIVE PLATE TO EXHAUST MUFFLER
242
SPRING WASHER , Replaced By: N000137008212
