Поз.
Артикул
Описание
3
CONNECTG.PARTS,DELY.RANGE P.T.O.
3
CONNECTG.PARTS,DELY.RANGE , Replaced By: A0002606305, +001A0002640357
3
CONNECTG.PARTS,DELY.RANGE P.T.O.
7
CONNECTG.PARTS,DELY.RANGE , Replaced By: A0002609405
7
CONNECTG.PARTS,DELY.RANGE P.T.O.
7
CONNECTG.PARTS,DELY.RANGE P.T.O.
11
SLIDING COLLAR
23
LOCKING CAP CONNECTING PARTS
23
LOCKING CAP COVERING,019226
27
LOCK RING AS REQUIRED 2.00 MM,019226
27
LOCK RING SHAFT TO TRANSMISSION CASE
27
LOCK RING DRIVE GEAR
27
LOCK RING AS REQUIRED 3.00 MM,019226
27
LOCK RING AS REQUIRED 45X2.5 MM
31
GROOVED BALL BEARING SLIP RING SIDE TO 003 154 52 02
31
GROOVED BALL BEARING (INTERMEDIATE SPINDLE)
35
GROOVED BALL BEARING CONNECTING PARTS
39
BUSHING , Replaced By: A0002645850
39
BUSHING INTERMEDIATE SHAFT
43
BUSHING SHAFT TO TRANSMISSION CASE
43
BUSHING , Replaced By: A0002645650
47
LOCK , Replaced By: N900055045302
47
LOCK RING SHAFT TO TRANSMISSION CASE
51
P.T.O.N 70/2C N0.61X N MOTOR
51
P.T.O. , Replaced By: A6202600905
51
P.T.O.N 71/2 C
51
P.T.O. , PART IS ONLY OR ALSO SUPPLIED AS RECONDITIONED PART
55
HOUSING P.T.O.
55
TRANSMISSION CASE , Replaced By: A0002641428
55
HOUSING , Replaced By: A0002642228
55
HOUSING , Replaced By: A0002642028
55
HOUSING
59
CYLINDRICAL PIN
59
DOWEL PIN
63
BUSHING LATERAL P.T.O
65
HOUSING
65
HOUSING , Replaced By: A0002643428
67
GASKET , Replaced By: A0012641580
67
GASKET , Replaced By: A0002649680
67
GASKET TRANSMISSION CASE
67
GASKET P.T.O.
71
STUD SHIFT CASE TO TRANSMISSION
71
STUD COVER TO P.T.O. CASE
75
STUD
75
STUD
79
STUD P.T.O.
83
LOCK WASHER FITTING TO BRACKET
85
WASHER COVER TO P.T.O. CASE
87
NUT COVER TO FLANGE
87
NUT
91
GASKET
91
GASKET ,290281, Replaced By: A0002642980, +001A0002642111
91
GASKET CASE,REAR
95
NEEDLE BEARING P.T.O.
99
SLIDING COLLAR , Replaced By: A0002641423
99
SLIDING COLLAR , Replaced By: A0002641423
99
SLIDING COLLAR
99
SLIDING COLLAR P.T.O.
113
DRIVE SHAFT , Replaced By: A0002641206
113
DRIVE SHAFT P.T.O.
117
SPRING
121
BALL
125
THRUST WASHER P.T.O.
129
NEEDLE BEARING P.T.O.
129
NEEDLE BEARING REAR DRIVE SHAFT
133
LOCK RING. RETAINING RING OIL PUMP TO TRANSMISSION CASE
137
GEAR P.T.O.
141
GASKET CASE,REAR
141
GASKET
145
SCREW PLUG P.T.O. HOUSING
153
SHIFT LEVER
153
SHIFT LEVER TRANSMISSION CASE
154
LOCK RING SHIFT LEVER UPPER PART
155
EXPANSION PLUG ROD END
157
SLIDE P.T.O. SHIFT LEVER
161
SEAL RING P.T.O. SHIFT LEVER
165
SCREW SUPPORT TO FENDER
165
SCREW , Replaced By: N304017008018
169
SPRING WASHER , Replaced By: N000137008212
169
SPRING WASHER PROTECTIVE PLATE TO EXHAUST MUFFLER
173
NUT
174
SWITCH , Replaced By: A0025458114
174
SWITCH , Replaced By: A0035451614
174
SWITCH GEAR CLUSTER INDICATION
175
BALL10 MM
176
SEAL RING SWITCH TO CASE COVER
177
SPRING , Replaced By: A0002600069
177
SPRING , Replaced By: A0002600069
177
SPRING , Replaced By: A0002600069, +001A0002649680
179
SEAL RING P.T.O. SHIFTING CYLINDER
182
SEAL RING P.T.O. SHIFTING CYLINDER
185
PISTON P.T.O. SHIFTING CYLINDER
185
PISTON , Replaced By: A0002641315, +001A0002601039, +001A0002640127
188
SHIFT LEVER , Replaced By: A0002601039, +001A0002641315, +001A0002640127
188
SHIFT LEVER P.T.O.
191
CYLINDER , Replaced By: A0002640127, +001A0002601039, +001A0002641315
191
CYLINDER P.T.O.
194
SCREW CONNECTOR
197
SPRING WASHER LICENSE PLATE TO BRACKET
198
SHIFTING CYLINDER P.T.O. SHIFTING CYLINDER
198
REPAIR KIT SHIFTING CYLINDER
200
SHIFT LEVER
203
SHIFT LEVER P.T.O. CONTROL
203
SHIFT LEVER P.T.O. TO N 70/2C
209
SCREW SUPPORT TO FENDER
209
SCREW , Replaced By: N304017008018
212
NUT , Replaced By: N913004008001
212
NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET, Replaced By: N910113008003
215
SHIFTING CYLINDER PNEUMATIC SHIFTING CYLINDER
215
SHIFTING CYLINDER , Replaced By: A0002606263
215
SHIFTING CYLINDER , Replaced By: A0002606663
215
SHIFTING CYLINDER , EXHAUST STOCK OF OLD PARTS NUMBER FIRST UP TO CHASSIS 836824, Replaced By: A0002605063
215
SHIFTING CYLINDER , Replaced By: A0002606763
215
SHIFTING CYLINDER PNEUMATIC SHIFT MECHANISM USED FOR LATERAL P.T.O. TO N 70/1C
215
SHIFTING CYLINDER P.T.O. CONTROL
220
SEAL RING
223
SPRING
226
SPRING
229
STOP RING
232
SNAP RING
235
BOOT
235
BOOT , Replaced By: A0002640696
238
NUT , Replaced By: N304035010001
238
NUT
241
YOKE , Replaced By: A0009962801
241
YOKE
244
PINM 8 X 16
244
PIN , Replaced By: N918001008002
250
WASHER
253
STRAINER
256
PIN PULL ROD TO SHIFT LEVER
259
WASHER EXHAUST MUFFLER TO STRAP
259
WASHER , Replaced By: N000125008443
260
COTTER PIN LEVER TO ROD, Replaced By: N000094002060
260
COTTER PIN LEVER TO ROD
262
SEAL RING OIL DISTRIBUTOR BLOCK
265
SCREW PLUG
268
SWITCH
268
SENDER UNIT , Replaced By: A0105421217, +002A0045453926
268
SENDER UNIT , Replaced By: A0025452014
270
REPAIR KIT PNEUMATIC SHIFTING CYLINDER TO 000 260 66 63
271
BRACKET SHIFTING CYLINDER TO TRANSMISSION CASE TO N 70/1B
271
BRACKET
271
BRACKET SHIFTING CYLINDER TO TRANSMISSION CASE TO N 70/1B
271
BRACKET PNEUMATIC SHIFTING CYLINDER TO N 70/2C
273
SCREW REAR EXHAUST PIPE TO MUFFLER
277
LOCK WASHER BRACKET TO SUPPORT AND TO END PIECE
281
SCREW STRAP TO BRACKET
281
SCREW BRACKET TO FRAME SIDE MEMBER
285
LOCK WASHER BRACKET TO SUPPORT AND TO END PIECE
999
SHIFTING CYLINDER
999
COVER P.T.O.
999
SHAFT , NO LONGER AVAILABLE, ORDER RANGE OF DELIVERY
